LG LB651072 Manuale utente
Operating Instructions
Built in Oven
Please read this instruction manual carefully before using the oven.
This will ensure that you know the important safety information and the
correct operation of the oven.
Please keep this manual in a easily accessible place and refer to it
anytime. Please transfer this manual to new owner if you sell the oven.
LB65 072
www.lg.com
3828W5A8116
2
Contents
Safety ............................................................................... 4~8
Description of the feature ............................................... 9
Control panel ................................................................... 10~11
Accessories ..................................................................... 12~13
Telescopic runners ( eature not available in all countries.)
..... 14~15
Setting the clock ............................................................. 16
Prior cleaning ................................................................... 17
Operating the oven ......................................................... 18
Oven functions ................................................................ 19~20
Operation ......................................................................... 21~39
Changing the oven function ............................................ 21
Changing the oven temperature ..................................... 22
Switching off the oven ..................................................... 23
Cookware and their usages ............................................ 23
Maximum operation times for safety .............................. 24
Cooling fan operation Energy Label Directive ............... 24
Clock functions ............................................................... 25
Kitchen timer .................................................................. 26
Cook time ....................................................................... 27
End time ......................................................................... 28~29
Combining the cook time and end time functions ........... 30~31
Adjusting the clock time .................................................. 32
Child safety function ....................................................... 33
Memory cook .................................................................. 34~35
Speed grill Speed roast ............................................... 36
Changing the language .................................................. 37
Auto cook (Speed cook) .................................................. 38~39
Auto cooking table (Speed cook) ................................... 40~57
3
Fish ................................................................................. 40~41
Meat ............................................................................... 42~45
Pastry ............................................................................. 46~47
Potato products .............................................................. 48~49
Poultry and game ........................................................... 50~53
Snacks ............................................................................ 54~55
Vegetables ...................................................................... 56~57
Baking .............................................................................. 58~59
Baking table ..................................................................... 60~63
Roasting............................................................................ 64
Roasting table .................................................................. 65
Grilling............................................................................... 66
Grilling table ..................................................................... 67
Defrosting ......................................................................... 68
Yogurt ............................................................................... 69
Cleaning and care ........................................................... 70~73
Oven light ......................................................................... 74~76
Oven door ........................................................................ 77~83
What should I do if… ...................................................... 84~87
4
Safety
• This oven must only be installed by a licensed electrician.
• The installer is responsible for the correct electrical connection of
the appliances and the observance of the relative safety codes
and recommendations.
Electrical Safety
If the oven has been damaged in transport, do not connect it.
• This appliance must be connected to the mains power supply by a
specially licensed electrician only.
• In the event of a fault or damage to the appliance, and do not
attempt to operate it.
• Repairs of the appliance should be carried out by a licensed
technician only. Wrong repairs may result in considerable danger.
If you need repairs, contact an LG Service Center or your dealer.
• If the supply cord is defective, it must be replaced by a special
cord or assembly available from manufacturer or substance or its
service agent.
• If the appliance is supplied from a cord extension set or an
electrical portable outlet device, the cord extension set on
electrical portable outlet device must be positioned so that it is not
subject to splashing or ingress of moisture.
• Electrical leads and cables should not be allowed to touch the
oven.
• The oven should be connected to the electricity supply by means
of an approved circuit breaker or fuse.
Never use multiple plug adapters or extension leads.
5
• Rating plate is located on the left side of door or the cover-back.
• The power supply of the appliance should be turned off when it is
being repaired or cleaned.
• Be careful in connecting electrical appliances to sockets near to
this appliance.
• This connection may be achieved by having the plug accessible or
by incorporation a switch in the fixed wiring in accordance with the
wiring rules.
• Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
Warning: The appliance should be powered down before replacing
the lamp to avoid the possibility of electric shock.
Warning: When the oven operates, the interior parts will be very
hot.
6
Safety
Safety during Operation
• This oven has been designed only for the cooking of household
foods and for Domestic use.
• When in use, the oven interior surfaces become very hot!
Care should be taken to avoid touching heating elements inside
the oven.
• Never store flammable or easily deformable materials in the oven.
• The oven surfaces will become hot when the appliance is
operated at a high temperature for a long period of time.
• When cooking, take care when openning the oven door as hot air
and steam will escape rapidly.
• When cooking dishes that contain alcohol, the alcohol can
evaporate due to the high temperatures. The vapour can catch fire
if it comes into contact with a hot oven part.
• Do not use high-pressure water cleaners or steam jet cleaners for
safety reasons.
• When opening the door in the course of cooking, the upper
heating elements will remain on for 10 minutes if they were
already in operation prior to the door being opened. This reduces
heat loss and heating recovery time when the door remains
opened for longer periods.
7
• Children should be kept at a safe distance when the oven
operates.
• Frozen foods such as pizzas should be cooked on the wire grill.
If the Baking tray is used, it may become deformed due to the
great difference in temperature.
• Don’t pour water into the oven bottom when it is hot.
This could cause damage to the enamel surface and deform the
base.
• The oven door must be closed when the cooking is performing.
• Don’t spread aluminium foil on the bottom of the oven and do not
place any baking trays or tins on it.
The aluminium foil blocks the heat, which may result in damage to
the enamel surfaces and cause poor cooking results.
• Dripping fruit juices from the baking tray will leave stains, which
become indelible. When cooking very moist cakes, use the deep
pan.
• Do not use the oven door as a rest table for hot or cold
cookwares.
• The appliance is not intended for use by young children or infirm
persons without supervision.
• Young children should be supervised to ensure that they do not
play with the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
Warning!
• Accessible parts may become hot during use. Young children
should be kept away.
• Accessible parts may become hot when the grill is in use.
Children should be kept away.
8
Safety
Disposing of packaging material
• The appliance’s packaging is recyclable.
• Dispose of the packaging materials in the appropriate container at
your local waste disposal facilities.
Disposal of old appliances
Warning: Before disposing of old appliances please make them
inoperable so that they cannot be the source of danger.
To do this, disconnect the appliance from the main supply and
remove the main lead.
To protect the environment, it is important that worn-out appliances
are disposed of in the correct manner.
• The appliance must not be disposed of with household rubbish.
• You can obtain information about collection dates or public refuse
disposal sites from your local refuse department or council.
Structure
9
Description of the Feature
Top heating elements
Oven levels
Control panel
Door handle
Full glass
door
Oven light
Air outlet filter
Door seal
Rear wall heating
element
Fat Filter
Oven light
Level 5
Level 4
Level 3
Level 2
Level 1
Oven levels are numbered from the bottom up.
The 4 and 5 levels are mainly used for grill functions. Always grill
with the door closed.
The cooking tables throughout this operating instructions give you
suggested oven level (shelf positions), however you can change
these to suit yourself.
Side runner
Rating plate
10
Control Panel
34
12
1. Function display
2. Temperature display
3. Function selector
4. Temperature selector
