LIGHT OVEN “
S
olar DOM
”
OWNER’S MANUAL
PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING.
MP-9482SR
P/No: 3828W5A4715
Precautions
2
Precautions to avoid possible exposure to excessive microwave energy.
You cannot operate your oven with the door open due to the safety interlocks
built into the door mechanism. These safety interlocks automatically switch off
any cooking activity when the door is opened; which in the operation of
microwave function could result in harmful exposure to microwave energy.
It is important not to tamper with the safety interlocks.
Do not place any object between the oven front face and the door or allow
food or cleaner residue to accumulate on sealing surfaces.
Do not operate your oven if it was damaged. It is particularly important that
the oven door closes properly and that there is no damage to the: (1)
door(bent), (2) hinges and latches (broken or loosened), (3) door seals and
sealing surfaces.
Your oven should not be adjusted or repaired by anyone except qualified
service personnel.
Warning
When heating liquids, e.g. soups, sauces and beverages in your oven with
microwave function, delayed eruptive boiling can occur without evidence of
bubbling. This could result in a sudden boil over of the hot liquid. To prevent
this possibility the following steps should be taken:
1 Avoid using straight sided containers with narrow necks.
2 Do not overheat.
3 Stir the liquid before placing the container in the oven and again halfway
through the heating time.
4 After heating, allow to stand in the oven for a short time, stir or shake
them(especially the contents of feeding bottles and baby food jars) again
carefully and check the temperature of them before consumption to avoid
burns (especially, contents of feeding bottles and baby food jars).
Be careful when handling the container.
Warning
Always allow food to stand after being cooked by
waves and check the temperature of them before
consumption. Especially contents of feeding bottles
and baby food jars.
Please ensure cooking times are correctly set as
over cooking may result in the FOOD catching fire
and subsequent damage to your oven.
Contents
How the Microwave Function Works
Microwaves are a form of energy similar to radio and television waves and
ordinary daylight. Normally, microwaves spread outwards as they travel
through the atmosphere and disappear without effect. This ovens, however,
have a magnetron which is designed to make use of the energy in
microwaves. Electricity, supplied to the magnetron tube, is used to created
microwave energy.
These microwaves enter the cooking area through openings inside the oven.
A turntable or tray is located at the bottom of the oven. Microwaves cannot
pass through metal walls of the oven, but they can penetrate such materials
as glass, porcelain and paper, the materials out of which microwave-safe
cooking dishes are constructed.
Microwaves do not heat cookware, though cooking vessels will eventually get
hot from the heat generated by the food.
A very safe appliance
Your oven,
S
olar
DOM, is one of the safest of all home
appliances. When the door is opened, the oven
automatically stops producing microwaves. Microwave
energy is converted completely to heat when it enters
food, leaving no “left over” energy to harm you when
you eat your food.
Precautions 2
Contents 3
Unpacking & Installing 4 ~ 5
Control Panel 6
Setting the Clock 7
Child Lock 8
Convection Cooking 9
Speed Combi Cooking 10 ~ 12
Speed Auto Cooking 13 ~ 19
Auto Defrost 20 ~ 21
Grill Cooking 22
Micro Power Cooking 23
Micro Power Level 24
Two Stage Cooking 25
Favorite Cook 26 ~ 27
Quick Start 28
More or Less Cooking 29
Rotisserie Installation & Cooking 30 ~ 33
Rotisserie Assembly 34
Important safety instructions 35 ~ 36
Microwave - safe Utensils 37
Food characteristics & Microwave cooking 38 ~ 39
Questions & Answers 40
Plug Wiring Information/Technical Specifications 41
3
Unpacking &
Installing
4
By following the basic steps on these two pages you will be able to quickly check that your oven is operating
correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your
oven make sure you remove all accessories and packing. Check to make sure that your oven has not been
damaged during delivery.
Place the oven in the level location of your choice with
more than 85cm height but make sure there is at least
20cm of space on the top and 10cm at the rear for proper
ventilation. The front of the oven should be at least min. 8cm/max.
22cm from the edge of the surface to prevent tipping.
An exhaust outlet is located on bottom or side of the oven. Blocking
the outlet can damage the oven.
Unpack your oven and place it on a flat level surface.
* THIS OVEN SHOULD NOT BE USED FOR COMMERCIAL
CATERING PURPOSES.
* THIS OVEN CAN BE USED AS BUILT-IN TYPE .
* MUST USE THE BUILT-IN KIT THAT IS MADE BY LG ELECTRONICS.
HIGH RACK
(For grill mode)
LOW RACK
(For microwave and
convection mode)
ROTISSERIE
HANDLE
METAL TRAY
(For defrost)
5
The DISPLAY will count down from 3 minutes. When it
reaches 0, it will sound BEEPS. Open the oven door and
test the temperature of the water. If your oven is operating, the
water should be warm. Be careful when removing the container, it
may be hot.
YOUR OVEN IS NOW INSTALLED
Fill a microwave safe container with 300 ml (1/2 pint)
of water. Place on the METAL TRAY and close the oven
door. If you have any doubts about what type of container to use
please refer to page 37.
Open your oven door by pulling the DOOR HANDLE.
Place the METAL TRAY inside the oven.
Plug your oven into a standard household socket. Make
sure your oven is the only appliance connected to the
socket. If your oven does not operate properly, unplug it from the
electrical socket and then plug it back in.
The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
Press the STOP/CLEAR button, and press the
START button one time to set 30 seconds of
cooking time.
Control Panel
6
1. Display Window: You can show time of day, cooking time, power level
and cooking categories.
2. Enter: You can determine the selected cooking category, microwave power
level or temperature.
3. Micro: You can select five power level settings.
4. Grill: You can select the grill categories.
5. Conv.: You can select temperature and time of convection.
6. Speed Combi: You can select the combination categories.
7. Speed Auto Cook: Speed auto cook allows you to cook most of your
favorite food quickly by selecting the food type and the weight of the food.
8. Dial Knob:
• You can set cooking times, temperature, weight and cooking categories.
• While cooking with auto and manual function, you can lengthen or
shorten the cooking time at any point by turning the dial knob(except
defrost mode).
9. Defrost: You can select the food type and the weight of the food.
10. Favorite: The cooking program can be stored in the memory of your oven
up to 9 modes(FA-1~FA-9).
11. Clock: You can set the time of day.
12. Stop/Clear: You can stop over and clear all entries except time of day.
• Press Stop/Clear Button one time, all icons will be displayed on
window in time of day or clear mode.
• Press Stop/Clear Button one more time, all icons will be disappeared.
13. Start/Quick Start:
• In order to start cooking which is selected, press button one time.
• The quick start feature allows you to set 30 seconds intervals of HIGH
power cooking with a touch of the quick start button.
14. Icon: You can see all icons by pressing “Stop/Clear” button one time and
remove all icons by pressing one more time(all icons will disappear
automatically after 15 seconds).
Blink will guide to next step for setting while cooking, the icon of the
selected cooking mode will be displayed on window.
7
You can set either12 hour clock or 24 hour clock.
In the following example I will show you how to set the time for 14:35 when using the 24 clock.
Make sure that you have removed all packaging from your oven.
When your oven is plugged in for the
first time or when power resumes after a
power cut, a ‘0’ will be shown in the
display; you will have to reset the clock.
If the clock (or display) shows any
strange looking symbols, unplug your
oven from the electrical socket and plug
it back in and reset the clock.
NOTE: Information Blink
Make sure that you have correctly installed your oven as described earlier
in this book.
Press Stop/Clear.
Press Clock once.
(If you want to use a 12 hour clock, Press Clock once more.
If you want to change different option after setting clock,
you have to unplug and plug it back in.)
Turn Dial knob until display shows “14:00”.
Press Enter for hour confirmation
Turn Dial knob until display shows “14:35”.
Press Enter.
The clock starts counting.
For mode setting, blink will
guide to next step.
Setting the
Clock
8
Child
Lock
Press and hold Stop/Clear until “L” appears on the display and
BEEP sounds.
The CHILD LOCK is now set.
The time will disappear on the display but will reappear on
the display a few seconds later.
If any button is pressed, “L” will appear on the display
To cancel CHILD LOCK press and hold Stop/Clear until “L” disappears.
You will hear BEEP when it’s released.
Your oven has a safety feature that
prevents accidental running of the oven.
Once the child lock is set, you will be
unable to use any functions and no
cooking can take place.
However your child can still open the
oven door.
Press Stop/Clear.
9
Convection
Cooking
In the following example I will show you how to use the convection to cook some food for 50 minutes for 220˚C
temp.
Press Stop/Clear.
1. To Preheat 2. To Cook
Press Start.
Display shows “Pr-H”.
The convection oven has a temperature
range of 40°C and 100°C~250°C
The oven has a ferment function at the
oven temperature of 40°C. You should
wait until the oven is cool because you
cannot use a ferment function if the oven
temperature is over 40°C.
It is available to extend the cooking time
up to 9 hours in the condition of 40°C at
convection function for the operating
mwo.
Your oven will take a few minutes to
reach the selected temperature.
Once it has reached correct temperature,
your oven will BEEP to let you know that
it has reached the correct temperature.
Then place your food in your oven: then
tell your oven to start cooking.
The low rack must be used during
convection cooking.
Press Conv. to select convection
mode.
Turn Dial knob until display shows
“220˚C”.
Press Stop/Clear.
Turn Dial knob until display shows
“50:00”.
Press Start.
After cooking you must wear
gloves and container to take
metal tray out oven, because
metal tray is very hot.
Press Enter for temp. confirmation.
Press Conv. to select convection
mode.
Turn Dial knob until display shows
“220˚C”.
10
Speed combi
Cooking In the following example I will show you how to programme your oven with micro power 360W and grill for a
cooking time of 25 minutes.
Your oven has a combination cooking
feature which allows you to cook food
with heater and microwave at the same
time or alternately. This generally means
it takes less time to cook your food.
You can set three kinds of micro power
level(180W, 360W and 600W) in
speed combi mode.
Press Speed Combi to select grill combination mode(Co-1, 2, 3).
Press Stop/Clear.Speed Combi
(Co-1, 2, 3)
Turn Dial knob until display shows “Co-1”.
Press Enter for grill-1 confirmation.
Turn Dial knob until display shows “360W”.
Press Enter for power confirmation.
Turn Dial knob until display shows “25:00”.
Press Start.
After cooking you must wear gloves and container to take metal
tray out oven, because metal tray is very hot.
* Speed combi Category
* Grill mode: Refer to page 22
Co-1
Co-2
Co-3
Co-4
Co-5
Grill-1 + Microwave power
Grill-2 + Microwave power
Grill-3 + Microwave power
(Upper + Lower heater)
+ Microwave power
Convection + Microwave power
Indice
Altri manuali LG Forno
LG
LG WCEP6427 Series Manuale utente
LG
LG SolarDOM MP-9483SLA Manuale utente
LG
LG LWS3081ST Manuale utente
LG
LG LWS3081ST - 30in Single Electric Wall Oven Manuale utente
LG
LG EA790SP Manuale utente
LG
LG SolarDOM MA3884N Manuale utente
LG
LG LWS3081ST - 30in Single Electric Wall Oven Manuale utente
LG
LG MP9289JSCS Manuale utente
LG
LG SolarDOM MP9485SB Manuale utente
LG
LG WCES6428F Manuale utente
LG
LG MG-556EL Manuale utente
LG
LG WSEZM7225S2 Manuale utente
LG
LG LSWD306ST/00 Manuale utente
LG
LG WS9D76 Series Manuale utente
LG
LG EM780SP Manuale utente
LG
LG WDES9428F Manuale utente
LG
LG SolarDOM Manuale utente
LG
LG SolarDOM MP9485FRB Manuale utente
LG
LG WDES9428F Manuale utente
LG
LG LRE3027ST Manuale utente
