User Guide

This is a 「User Guide」 installed on the TV.

The contents of this guide are subject to change without prior notice for quality

improvement.

GP4

enga

 



Displays information about the current program and/or current time, etc.

✎ Image shown may differ from your TV.

Program name or external

device name

Detailed program information

(for digital broadcast)

Current time

PM 2:00 PM 4:30

Sat, Jan.1 12:02 AM

Prev./Next Ch. Change Schedule

GP4

enga

❐To set favorite channels

HOME ➾ Settings ➙ CHANNEL ➙ Channel Edit

1 Move to the desired channel on Wheel(OK) button. Channel is selected.

2 Press Set as Favorite.

3 Select the desired favorite channel group.

4 Select Enter. Favorite is set.

❐To use Favorite

HOME ➾ Ch. List

Channel list will appear. Select the desired preset favorite channel from

Favorite List A to D.

GP4

enga

❐To set Auto Tuning

HOME ➾ Settings ➙ CHANNEL ➙ Auto Tuning

Automatically tunes the channels.

✎Channels are not registered properly unless the antenna/cable is connected

correctly.

✎Auto Tuning only sets channels that are currently broadcasting.

✎If Lock System is turned on, a pop-up window will appear asking for

password.

GP4

enga

❐To set channels manually

HOME ➾ Settings ➙ CHANNEL ➙ Manual Tuning

Adjusts channels manually and saves the results.

For digital broadcasting, signal strength, etc. can be checked.

GP4

enga

❐To edit channels

HOME ➾ Settings ➙ CHANNEL ➙ Channel Edit

Edits the saved channels.

Set as favorite, block/unblock and skip etc. the selected channel.

GP4

enga

HOME ➾ Settings ➙ PICTURE ➙ Aspect Ratio

Selects the screen aspect ratio.

16:9 Resizes the image ratio to fit a 16:9 screen.

Just Scan

Displays high-quality image without loss.

✎ In DTV/HDMI/Component (over 720p) mode, Just Scan is

available.

Set by

Program

Depending on the input signal, screen aspect ratio changes to 4:3

or 16:9.

4:3 Resizes the image ratio to fit 4:3 screen.

Zoom Resizes the image to fit the screen width. The top and bottom

parts of the image may be cut off.

Cinema

Zoom

Formats an image to the cinemascope ratio (2.35:1) and zooms in

on the ratio.

GP4

enga

✎ While viewing an external device, these cases may result in image burn:

- a video with stationary caption (such as network name)

- 4 : 3 aspect ratio mode for an extended period

Take caution when using these functions.

✎ Available picture size may differ depending on the input signal.

✎ The screen aspect ratios on HDMI/RGB-PC input are available in 4:3 and 16:9

only.

✎ [For models supporting 2160p] When a 2160p signal is input or your PC

resolution is set to 3840 x 2160, the Aspect Ratio is fixed to Just Scan.

GP4

enga

 



Adjusts picture in RGB-PC mode.

Resolution

Sets the desired resolution.

✎ Resolution may only be selected when the PC resolution is

set to 1024x768, 1280x768 or 1360x768.

Auto

Configuration Optimizes picture.

Position/Size/

Phase

If screen size or location is distorted, user can directly adjust

the screen size and position.

Reset Resets all the changes on picture settings on PC input mode.

GP4

enga

 

1 Right-click on the desktop of PC and select 「Properties」.

2 Click on 「Settings」 and refer to supported formats to set the resolution.

3 Select 「Advanced → Monitor → Monitor Settings」 on the setting window.

Refer to supported formats to select the optimal vertical frequency.

✎ On PC mode, 1024X768 resolution delivers the optimum picture quality.

✎ Resolution settings differ depending on the type of PC.
