LG 55LM5800 Manuale utente
User Guide
This is a 「User Guide」 installed on TV.
The contents of this guide are subject to change without prior notice for quality
improvement.
GP2
GP2
GP2
kor
❐To set up the channels automatically
SETTINGS ➾ CHANNEL ➙ Auto Tuning
Memorizes automatically the channels being broadcast.
✎The channels will not be memorized properly if the antenna/cable is not
installed correctly.
✎Auto Tuning memorizes the channels that are currently being broadcast.
✎If Lock System is turned on, a pop-up window will appear asking for
password.
GP2
kor
❐To set up the channels at manually
SETTINGS ➾ CHANNEL ➙ Manual Tuning
Adjusts channels manually and saves the results.
For digital broadcasting, signal strength, etc. can be checked.
GP2
kor
❐To edit the channels
SETTINGS ➾ CHANNEL ➙ Channel Edit
Edits the saved channels.
GP2
enga
SETTINGS ➾ PICTURE ➙ Aspect Ratio
Selects the screen aspect ratio.
• 16:9:Resizes the image ratio to fit 16:9 screen.
• Just Scan:Displays high-quality image without loss.
✎Select the Just Scan at the input of DTV/Component/HDMI/DVI (720P or
higher).
• Set by Program:Depending on the input signal, screen aspect ratio changes
to 4:3 or 16:9
• 4:3:Resizes the image ratio to fit 4:3 screen.
• Zoom:Resizes the image to fit the screen width. The top and bottom parts of
the image may be cut off.
• Cinema Zoom:Formats an image to the cinemascope ratio (2.35:1) and zooms
in on the ratio.
GP2
enga
✎While viewing an external device, these cases may result in image burn:
- a video with stationary caption (such as network name)
- 4 : 3 aspect ratio mode for an extended period
Take caution when using these functions.
✎Available picture size may differ depending on the input signal.
✎At HDMI/RGB-PC input, select the image ratios of 4:3 and 16:9.
(Only for models supporting PC connection)
GP2
enga
❐To adjust pictures in PC input mode
SETTINGS ➾ PICTURE ➙ Screen (RGB-PC)
Adjusts picture in RGB-PC mode.
• Resolution:Sets the desired resolution.
✎Options may only be selected when the PC resolution is set to 1024 x
768, 1280 x 768, or 1360 x 768.
• Auto Cong.:Optimizes the picture.
• Position/Size/Phase:Adjusts screen size and position for optimum
viewing.
• Reset:Initializes the screen setups in PC input mode.
GP2
enga
❐To set PC resolution
1 Right-click on the PC’s desktop and select 「Properties」.
2 Click on 「Settings」 and refer to the supported format to set the resolution.
3 Select 「Advanced → Monitor → Monitor Setup」 on the setup window.
Refer to the supported formats to select the optimal vertical frequency.
✎In PC mode, 1920 x 1080 resolution delivers the optimum picture quality.
✎ Method to set up resolution diers depending on PC type.
