LG Flatron L3200TF Manuale utente
i
Table of Contents
ENGLISH
is a trademark of SRS Labs,Inc.
technology is incorporated under license from SRS Labs,Inc.
A1
A4
A5
A8
A9
A10
A11
A11
A13
A14
A15
A16
A17
A18
Safety Precautions
Accessories
Using the Remote Control
o arrange cables in order - Optional
Connecting the Speakers - Optional
Name and Function of the Parts
Connecting to External Devices
When Connecting to your PC
Connecting the VCR / DVD
Connecting the HD V (720p/1080i)
Connecting the DVD (480i)
When Watching DVI-D(HDCP) from the VCR/DVD/Set-top Box
Connecting the V
Connecting AV Outputs
A51
A54
Selecting and Adjusting the Screen
How to dajust the OSD(On Screen Display) Screen
Set/Selects the channel when using the VCR/DVD/HD V/ V
Adjusting Screen Color
Adjusting the audio function
Adjusting the timer function
Selecting the Options
o adjust the CAP ION & V CHIP function
Adjusting Screen CLOCK/PHASE and Position
Adjusting PIP/POP/PBP Mode (Multiple Screen) Functions
Controlling the Multiple Monitors (RS-232C protocol)
IR Codes
A19
A22
A23
A24
A25
A26
A28
A29
A35
A36
A38
A49
roubleshooting
Product Specifications
Installation
and
Connection
Input
Selection
and Tracking
iscellaneous
A1
Safety Precautions
Please read these safety precautions carefully before using the monitor.
Precautions in installing the onitor
If you ignore the caution message, you may be slightly injured or the product may be damaged
If you ignore the warning message, you may be seriously injured or there is a possibility of
accident or death.
Keep away from heat sources like electrical heaters.
- Electrical shock, fire, malfunction or deformation may occur.
Keep the packing anti-moisture material or vinyl packing out of the reach of children.
- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.
Do not put heavy objects on the monitor or sit upon it.
- If the monitor collapses or is dropped, you may be injured. Children must pay particular attention.
Do not leave the power or signal cable unattended on the pathway.
- he passerby can falter, which can cause electrical shock, fire, product breakdown or injury.
Install the monitor in a neat and dry place.
- Dust or moisture can cause electrical shock, fire or product damage.
If you can smell smoke or other odors or hear a strange sound unplug the power cord and contact the
service center.
- If you continue to use without taking proper measures, electrical shock or fire can occur.
If you dropped the monitor or the case is broken, turn off the monitor and unplug the power cord.
- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact the service
center.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire into the monitor, or inflammable
objects such as paper and matches. Children must pay particular attention.
- Electrical shock, fire or injury can occur. If a foreign object is dropped into the monitor, unplug the power cord and
contact the service center.
ake sure the monitor ventilation hole is not blocked. Install the monitor in a suitably wide place (more
than 10cm from the wall)
- If you install the monitor too close to the wall, it may be deformed or fire can break out due to internal heat.
Do not block the ventilation hole of the monitor by a tablecloth or curtain.
- he monitor can be deformed or fire can break out due to overheating inside the monitor.
Install the monitor on a flat and stable place that has no risk of dropping the monitor.
- If the monitor is dropped, you may be injured or the monitor may be broken.
Install the monitor where no E I occurs.
Keep the monitor away from direct sunlight.
- he monitor can be damaged.
Warning
Warning
Caution
Caution
A2A2
ENGLISH
Electrical Power Related Precautions
ake sure to connect the power cable to the grounded current.
- You may be electrocuted or injured.
Use the rated voltage only.
- he product can be damaged, or you may be electrocuted.
During a thunder or lightning storm, unplug the power cable or signal cable.
- You may be electrocuted or a fire can break out.
Do not connect several extension cords, electrical appliances or electrical heaters to a single outlet. Use a
power bar with a grounding terminal designed for exclusive use with the computer.
- A fire can break out due to overheating.
Do not touch the power plug with wet hands. Additionally, it the cord pin is wet or covered with dust, dry
the power plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.
If you don’t intend to use the product for a long time, unplug the power cable from the product.
- Covering dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.
Fix the power cable completely.
- If the power cable is not fixed completely, a fire can break out.
Hold the plug when pulling out the power cable. Do not bend the power cord with excessive force or put
heavy objects on the power cord.
- he power line can be damaged, which may cause electric shock or fire.
Do not insert a conductor (like a metal chopstick) into one end of the power cable while the other end is
connected to the input terminal on the wall. Additionally, do not touch the power cable right after
plugging into the wall input terminal.
- You may be electrocuted.
The power supply cord is used as the main disconnection device. Ensure that the socket-outlet is easily
accessible after installation.
Do not unplug the power cord while the product is in use.
- Electrical shock can damage the product.
Warning
Caution
Precautions in oving the Product
Warning
ake sure to turn off the product.
- You may be electrocuted or the product can be damaged.
ake sure to remove all cables before moving the product.
- You may be electrocuted or the product can be damaged.
A3
Safety Precautions
Caution
Precautions in Using the onitor
Warning
Do not put or store inflammable substances near the monitor.
- here is a danger of explosion or fire due careless handling of the inflammable substances.
When cleaning the brown tube surface, unplug the power cord and scrub with soft cloth to prevent
scratching. Do not clean with a wet cloth.
- he water can sink into the monitor, which can cause electric shock or serious malfunction.
Take a rest from time to time to protect your vision.
Keep the monitor clean at all times.
Take a comfortable and natural position when working with a monitor to relax the muscles.
Take a regular break when working with a monitor for a long time.
Do not press strongly upon the panel with a hand or sharp object such as nail, pencil or pen, or make a
scratch on it.
Keep proper distance from the monitor.
- Your vision may be impaired if you look at the monitor too closely.
Set the appropriate resolution and clock by referring to the User’s anual.
- Your vision can be impaired.
Use authorized detergent only when cleaning the monitor. (Do not use benzene, thinner or alcohol.)
- Monitor can be deformed.
he fluorescent lamp used in this product contains a small amount of mercury.
Do not dispose of this product with general household waste.
Disposal of this product must be carried out in accordance to the regulations of your local authority.
Caution
Do not shock the monitor when moving it.
- You may be electrocuted or the monitor can be damaged
Do not dispose the product-packing box. Use it when you move.
ake the panel face forward and hold it with both hands to move.
- If you drop the monitor, the damaged monitor can cause electric shock or fire. Contact with the service center for
repair.
Do not disassemble, repair or modify the monitor at your own discretion.
- Fire or electric shock accident can occur.
- Contact the service center for check, calibration or repair.
Do not spray water on the monitor or scrub with an inflammable substance (thinner or benzene). Fire or
electric shock accident can occur
Keep the monitor away from water.
- Fire or electric shock accident can occur.
On Disposal
A4A4
ENGLISH
Accessories
Speaker kit / Screws
(Applicable only for models
that support the speakers)
Remote Controller/
Batteries
Power Cord Audio Cable (PC)
Monitor
OR
Desktop Stand ype Free Mount ype
Please check the accessories in the product package.
* The monitor and the accessories can be different from the figures shown here.
15-pin D-Sub Signal
Cable
DVI-D Signal Cable
Optional
Wall-mount Rack
Please refer to the enclosed "Installation Guide" when
installing the wall-mount rack.
User's Guide/
Driver CD/Cards
1. Take out the battery cap.
2. Insert batteries with correct polarity (+/-).
3. Close the battery cap.
• You can use a remote controller 7 meter distance
and 30 degree (left/right) within the receiving unit
scope.
• Dispose of used batteries in the recycle bin to
prevent environmental pollution.
Inserting batteries into remote controller.
RCA-PC
Audio Cable
A5
Using the Remote Control
Power On/Off Button
Channel Up/Down Button
•
Input Select Button
•
TV/AV Button
(See next page)
Sleep Button
When watching TV/AV / S-Video /
Component 1 / Component 2
-
he monitor will be automatically turned off
after a certain period of time.
Press this button repetitively to select an
appropriate time duration.
EZ Video Button
When watching V/AV / S-Video /
Component 1 / Component 2
- Automatically adjusts the image.
Press this button repetitively to set
the intended screen. (See A24)
CAPTION Button - Optional
(See A30)
•
enu Button
•
Exit Button
Auto Channel Button
• V: Automatic V channel setup
(Applicable to the model equipped with
the V tuner)
• PC: Automatic adjustment function
(Operational for the analog signal only)
Channel Number Select
Button
Operational at the V mode only
SET Button
Sound ode Select
Select the sound mode
: MONO/S EREO/SAP
Video Operation Button
Applicable for LGE products only
Volume Button
ute button
Name of the Remote Controller Buttons
A6
ENGLISH
1. PIP (Picture in Picture) Button
he sub-screen moves to the next mode whenever you press this button.
: SMALL -> MEDIUM -> LARGE -> OFF
2. POP (Picture out Picture) Button
he sub-screen moves to the next mode whenever you press this button.
: POP ON -> PBP(FULL) -> PBP(4:3) -> OFF
POP ON PBP (FULL) PBP (4:3)
PIP
If you press the button once,
the following Input Signal
Window will appear. Select
the signal type you want
using the button.
his button will be enabled only
when you selected the V/AV
signal. he signal type will be
changed with the following order.
Set the signal type you want.
•
Input Select Button
•
TV/AV Button
TV AV S-Video Component 1
Component 2
A7
SWAP
SWAP
When 'Input Signal 1' comes on in the main screen, only 'Input Signal 2' can be displayed on the sub-screen. On
the contrary, if the main screen displays 'Input Signal 2', the sub-screen can display 'Input Signal 1' only. You can
swap 'Input Signal 1' and 'Input Signal 2' using the SWAP button.
*PIP function is not supported in 480i, 576i and 1080i modes.
3. SWAP Button
You can swap the main screen and the sub-screen when the PIP/POP/PBP function is used.
PIP
POP
PBP
Using the Remote Control
<Table of PIP/POP/PBP Function Support>
A8
ENGLISH
To arrange cables in order - Optional
1. Disassemble the stand cover. he cover may be easily disassembled by pressing
down on the base as shown in the figure.
2. After connecting the cables, correctly position the stand cover into the holes on the
stand. If securely connected, you will hear the latch click into place.
Stand cover
* Applicable only for models that support the stand
A9
Connecting the Speakers - Optional
Use the screws to secure the speakers on the rear side of the monitor as shown
in the below figure.
* Applicable only for models that support the speakers
When the speaker is installed.
Altri manuali per Flatron L3200TF
3
Indice
Altri manuali LG TV
LG
LG NANO77 Series Manuale utente
LG
LG LK61 Series Manuale utente
LG
LG 55EU960H Manuale utente
LG
LG 29FU1RS Manuale utente
LG
LG 21FK2RG Manuale utente
LG
LG 32LG35 Series Manuale utente
LG
LG 42LV3700 Manuale utente
LG
LG RZ-21FB55MX Manuale utente
LG
LG 42LA6200 Manuale utente
LG
LG CT-25Q20 Series Manuale utente
LG
LG 14CA8RB Manuale utente
LG
LG 50PC3D - - 50" Plasma TV Manuale utente
LG
LG LN57 Series Manuale utente
LG
LG RT-28FZ10RX Manuale utente
LG
LG 55EG9100 Manuale utente
LG
LG 42LM615T Manuale utente
LG
LG 43UV570H Manuale utente
LG
LG 47LX9500 Manuale utente
LG
LG Flatron M197WD Manuale utente
LG
LG 42PC3RA Series Manuale utente
