OWNER'S MANUAL

VACUUM CLEANER

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

A9N-WHITE / A9N-TWIN

MFL69883691

Rev.00_083121

www.lg.com

global_main.book.book Page 1 Tuesday, August 31, 2021 2:29 PM

TABLE OF CONTENTS

This manual may contain images or

content that may be different from the

model you purchased.

This manual is subject to revision by the

manufacturer.

SAFETY INSTRUCTION

READ ALL INSTRUCTIONS BEFORE USE...........................................................3

WARNING............................................................................................................3

CAUTION ...........................................................................................................10

INSTALLATION

Product Overview.............................................................................................11

Installing the Charging Station ......................................................................14

Storing the Accessories ...................................................................................15

OPERATION

Getting Started .................................................................................................16

Charging the Battery .......................................................................................17

Using the Nozzles and Tools...........................................................................18

MAINTENANCE

Cleaning the Appliance ...................................................................................21

Cleaning the Nozzles .......................................................................................24

TROUBLESHOOTING

Before Calling for Service................................................................................27

global_main.book.book Page 2 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

ENGLISH

SAFETY INSTRUCTION

READ ALL INSTRUCTIONS BEFORE USE

The following safety guidelines are intended to prevent unforeseen

risks or damage from unsafe or incorrect operation of the appliance.

The guidelines are separated into ‘

WARNING

’ and ‘

CAUTION

’ as

described below.

Safety Messages

WARNING

• To reduce the risk of explosion, fire, death, electric shock, injury or

scalding to persons when using this product, follow basic

precautions, including the following:

Technical Safety

• This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

This symbol is displayed to indicate matters and

operations that can cause risk. Read the part with this

symbol carefully and follow the instructions in order to

avoid risk.

WARNING

This indicates that the failure to follow the instructions can

cause serious injury or death.

CAUTION

This indicates that the failure to follow the instructions can

cause the minor injury or damage to the product.

global_main.book.book Page 3 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

responsible for their safety. Children should be supervised to ensure

that they do not play with the appliance.

• Do not allow the appliance to be used as a toy. Close attention is

necessary when used by or near children.

• Do not allow children to play with or hang on the appliance.

• Do not use the appliance with damaged power cord or plug. The cord

must be replaced. If the appliance is not working as it should, has

been dropped, damaged, left outdoors, or dropped into water, return

it to an LG Electronics service centre.

• Do not pull or carry by cord, use cord as a handle, close a door on

cord, or pull cord around sharp edges or corners. Do not run

appliance over cord. Keep cord away from heated surfaces.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not the

cord.

• Place the cords from other appliances out of the area to be cleaned.

Battery

• Never use the battery, adapter, and the charging station from other

appliances with this appliance. Use only the battery and the charging

station provided by LG Electronics.

• Never use the battery, adapter, and the charging station from this

appliance with other appliances.

• Unplug the power cord and remove the battery if the appliance will

not be used for an extended period of time.

• Do not use modified or damaged batteries.

• Do not disassemble, remove or short-circuit the battery.

• When disposing of the battery or the appliance, remove the battery

from the appliance and safely dispose of it.

• Have specifically designated battery packs replaced when it is no

longer able to hold a charge.

• Refer to the

Charging the Battery

section instructions for the

method of replacing the battery.

global_main.book.book Page 4 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

ENGLISH

• When disposing of this appliance, follow regulations for disposal of

rechargeable lithium-ion batteries.

• Follow all local ordinances and regulations when handling or

disposing of the battery.

• Prevent unintentional starting. Ensure the switch is in the off position

before connecting to the battery pack, picking up or carrying the

appliance.

• Disconnect the battery pack from the appliance before making any

adjustments, changing accessories, cleaning, serviing, or storing

appliance.

• When battery pack is not in use, keep it away from other metal

objects, like paper clips, coins, keys, nails, screws or other small metal

objects, that can make a connection from one terminal to another.

• Under abusive conditions, liquid may be ejected from the battery. If

this happens, avoid contact. If contact accidentally occurs, flush with

water. If liquid contacts eyes, additionally seek medical help.

• If the appliance is to be stored unused for a long period, the batteries

should be removed.

• Before removing the battery, you must turn off this appliance.

• When fitting the battery into the product body, insert it completely

until it clicks.

Battery Specifications

• One or two batteries are provided, the number of batteries varies

depending on the model purchased.

Model Name

: EAC63382204

Type

: Rechargeable Lithium-ion Battery

Rated Capacity

: 25.2 V

, 2400 mAh

Installation

• To avoid an electrical shock or fire, do not install, charge or store the

appliance where it may be exposed to water, rainfall or high

humidity.

global_main.book.book Page 5 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

• Install, charge and store the appliance in a well-ventilated place.

• Avoid operating the appliance in areas where there is a risk of

leakage of flammable gas, industrial oil or metallic dust.

• Do not store or install the appliance, power cord or plug near heating

devices or open flames.

• Install the charging station on a firm, level surface.

• Do not use or store the appliance at temperatures below 5 ℃ or

above 38 ℃.

• Do not store or install the appliance where it is exposed to

temperatures below freezing or exposed to outdoor weather

conditions.

• When installing or moving the appliance, be careful not to pinch,

crush, or damage the power cord or plug.

• Use the anchoring screws only when attaching to concrete or similar

solid surfaces.

• Never drill into a wall without first checking that the area behind it is

free from power conduits, plumbing, vents, or cables.

Operation

• Read all instructions before using the appliance, and save these

instructions.

• Use only as described in this manual. Use only manufacturer’s

recommended attachment.

• This appliance is designed for normal indoor domestic use only. It is

not to be used for any non-residential, commercial, or industrial

application.

• This product should only be used with a 100 - 240 V~ 50/60 Hz, 0.8

amp outlet. Make sure to check the power specifications of the place

where you intend to use the appliance.

• Do not handle the power cord, plug, or appliance controls with wet

hands.

• Wipe any moisture or dirt off the cord or plug with a dry cloth.

global_main.book.book Page 6 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

ENGLISH

• Never attempt to operate this appliance if it is damaged,

malfunctioning, partially disassembled, or has missing or broken

parts, including a damaged cord or plug. Take it to an authorized LG

Electronics service centre or dealer for assistance.

• Do not apply excessive force to the power cord to bend it, or place it

under a heavy object as this will damage it.

• Do not use multiple-outlet adapters with this appliance. Make sure to

use a power socket with a capacity of 10 A.

• Do not plug the appliance into a damaged or loose outlet.

• Make sure to unplug the power cord when the appliance is not to be

used for an extended period of time.

• Do not damage, alter, excessively bend, twist, pull, pinch or heat the

power cord.

• Before using the appliance, remove any wire or string on the floor.

• Avoid touching the prongs of the power plug with your finger(s) when

unplugging the power cord.

• Do not cover the power cord with a rug or carpeting.

• Push the power plug firmly into the wall outlet so that it is not loose.

• If the product has been submerged, contact an LG Electronics service

centre or dealer for instructions before resuming use.

• If the product makes a strange noise or emits an odour or smoke,

discontinue use and contact an LG Electronics customer information

centre.

• Only qualified technicians or service personnel from LG Electronics

may disassemble, repair or modify the appliance.

• Never insert a sharp metallic object such as a pin, nail or knife in a

hole or gap in the appliance or the charging station.

• Do not vacuum liquids with this appliance. Make sure that no water,

beverage or detergent gets inside the appliance or the charging

station.

• Do not allow the appliance to sweep up blades, thumb tacks,

sawdust, sharp objects, or hot or cold ashes.

• Do not allow children to use the appliance.

global_main.book.book Page 7 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

• Do not let children or pets get close to the appliance when using,

charging or storing.

• Do not insert the nozzle or tools in your mouth.

• Keep clothing and hair, fingers, or other parts of the body away from

openings and moving parts.

• Do not operate the appliance with the suction inlet or outlet blocked.

• Do not use the appliance without the dust bin and filters in place.

• Do not use in an enclosed space where vapors are present from paint

thinner, mothproofing substances, flammable dust or other

explosive or toxic materials.

• Do not touch the charging terminals on the appliance or the charging

station, or insert an electrified object inside the appliance or the

station.

• Always store the appliance on the floor standing or wall-mounted

charging station when it is not in use.

• Do not lean the appliance on walls, chairs or tables.

• If the earth leakage breaker is tripped when the product is put on the

charging station, immediately remove the appliance from the

charging station. Contact an LG Electronics customer service centre.

• Use extra care when cleaning on stairs.

• Do not use or store a heating device or flammable substance(ether,

benzene, alcohol, chemicals, combustible sprays, insecticide, air

freshener or cosmetics) in close proximity to the appliance.

• Do not attempt to clean up a liquid substance (water, beverage),

odourous substances (candy, chocolate, pet excrement), metallic

objects (blades, pins), flammable substances, burning/

smoking(cigarettes, matches, or hot ashes), surfactants, or glass

shards with this appliance.

• In the event of a gas leak(natural gas, propane gas, etc.), do not

operate this or any other appliance. Open a window or door to

ventilate the area immediately.

• Do not hold the charging station upside down with the battery in the

charging station.

global_main.book.book Page 8 Tuesday, August 31, 2021 2:29 PM

SAFETY INSTRUCTION

ENGLISH

• Do not expose the appliance, and the battery in particular, to heat, a

heating device or direct sunlight.

• Do not keep the appliance or its battery inside a vehicle which is

exposed to direct sunlight.

• Never allow any water, beverage or detergent to get inside the

battery.

• Do not apply physical impacts to the battery.

Maintenance

• Make sure to unplug the power cord when cleaning or maintaining

the charging station.

• Do not wash the inlet port or the dust bin with water or detergent.

• Do not use detergents, polishes or air fresheners to clean the dust

bin.

• Do not apply or spray a flammable substance (gasoline or thinner) or

surfactants (detergent or bath soap) on the appliance.

• Wash hands after handling nozzles. The nozzles contain carbon fiber,

and contact may cause minor skin irritation.

Disposal

• Keep packing materials out of the reach of children. Packaging

materials can pose a suffocation risk for children.

• Destroy the carton, plastic bag, and other packing materials after the

appliance is unpacked. Children might use them for play. Cartons

covered with rugs, bedspreads, or plastic sheets can become airtight

chambers.

• Dispose of this appliance according to local, state, and regional laws

and regulations.

• Contact your local city council or the related government authority

before disposing of this appliance.

global_main.book.book Page 9 Tuesday, August 31, 2021 2:29 PM

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente

Nobles

Nobles 608669 Manuale del prodotto
