OWNER’S MANUAL
WASHING MACHINE
F1495BDS(1~9)
P/No.:MFL67085069 www.lg.com
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the washer is installed
correctly and safely. Leave these instructions near the washer
after installation for future reference.
Contents
2
Contents....................................2
Product Features......................3
Important safety instructions
Important safety instructions .................4
Basic safety precautions .......................5
Save these instructions.........................6
Specifications...........................7
Installation
Removing packing ................................8
Removing transit olts ..........................8
Installation place requirements .............9
Connecting water supply hose............11
Installation of drain hose .....................13
Leveling...............................................14
How to use washer
Operating washing machine ...............16
Care efore washing...........................17
Washing program ta le.......................18
Extra options .......................................19
Operating data ....................................20
Control panel.......................................21
Additional program..............................22
- Time Delay........................................22
- Steam Wash .....................................22
- Favorite.............................................22
- Pre Wash ..........................................22
Options................................................23
- Option1 .............................................23
- Option2 .............................................23
- Rinse.................................................23
- Temp. ...............................................23
Other functions....................................23
- Rinse+Spin .......................................23
- Spin Only .........................................23
- Refresh Cycle ..................................23
Child Lock ...........................................24
Beep On/Off ........................................24
Tu Clean ...........................................25
Door Lock & Detecting ........................25
Thank you for uying a LG Fully
Automatic Washing Machine.
Please read your owner’s manual
carefully, it provides instruction on safe
installation, use and maintenance.
Retain it for future reference.
Record the model and serial num er of
your washing machine.
Model No.
Serial No.
Date of Purchase
Adding detergent
Adding detergent and fa ric softener..26
Maintenance
The water inlet filter.............................28
The drain pump filter ...........................29
Dispenser drawer................................30
The washing drum ..............................31
Cleaning your washer .........................31
Cold conditions ...................................31
Troubleshooting guide
Diagnosing pro lems ..........................32
Error messages...................................34
Using SMARTDIAGNOSIS™..............35
Terms of warranty ..................36
Product Features
3
Inverter Direct Drive system
The advanced Brushless DC motor directly drives the drum without
elt and pulley.
More economical with Intelligent Wash system
Intelligent Wash System detects the size of load and water temperature,
and then determines the optimum water level and washing time to
minimize energy and water consumption.
Built-in heater
Internal heater automatically heats the water to the est temperature
on selected cycles.
Protection against creases
With the alternating rotation of the drum, creasing is minimized.
6 Motion
Washer is a le to perform various drum actions or a com ination of
different actions depending on the wash program selected.
Com ined with a controlled spin speed and the a ility of the drum to
rotate oth left and right, the wash performance of the machine is greatly
improved, giving you perfect results every time.
추가선택 예약
Low noise speed control system
By sensing the amount of load and alance, it evenly distri utes load
to minimize the spinning noise level.
Child Lock
The Child Lock prevents children from pressing any utton to change
the settings during operation.
4
Important safety instructions
For your safety, the information in this manual must e followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, injury to persons, or death.
READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION
BEFORE USE.
WA NING
You can e killed or seriously injured if you don’t follow instructions.
Your Safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and o ey all safety messages.
This is the safety alert sym ol.
This sym ol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert sym ol and either the word DANGER,
WARNING or CAUTION.
These words mean:
WA NING
You may e slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
CAUTION
You will e killed or seriously injured if you don’t immediately follow instructions.
DANGE
5
Important safety instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
• Before installation, check exterior
damages. If it has, do not install.
• Do not install or store the washer
where it will be exposed to the
weather.
• Do not tamper with controls.
• Do not repair or replace any part of
the washer or attempt any servicing
unless specifically recommended in
the user-maintenance instructions or
published user-repair instructions
that you understand and have the
skills to carry out.
• Keep the area underneath and around
your appliances free of combustible
materials such as lint, paper, rags,
chemicals, etc.
• The appliance is not intended for use
by young children or infirm persons
without supervision. Do not allow
children to play on, with, or inside this
or any other appliance.
• Keep small animals away from the
appliance.
• Do not leave the washer door open.
An open door could entice children to hang
on the door or crawl inside the washer.
• Never reach into washer while it is
moving. Wait until the drum has
completely stopped.
• The laundry process can reduce the flame
retardant of fa rics. To avoid such a
result, carefully follow the garment
manufacturer’s wash and care
instructions.
• Do not wash or dry articles that have
been cleaned in, washed in, soaked
in, or spotted with combustible or
explosive substances (such as wax,
oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.)
which may ignite or explode. Oil may
remain in the tu after a whole cycle resulting
in fire during drying.
So, do not load oiled clothes.
• Do not slam the washer door closed
or try to force the door open when
locked. This could result in damage to the
washer.
• When the machine runs high
temperature, the front door may be
very hot. Don’t touch it.
• To minimize the possibility of electric
shock, unplug this appliance from the
power supply or disconnect the
washer at the household distribution
panel by removing the fuse or
switching off the circuit breaker
before attempting any maintenance or
cleaning.
• When unplugging power cord, do not
pull out by grasping the cord.
Otherwise, the power cord may e damaged.
• Never attempt to operate this
appliance if it is damaged,
malfunctioning, partially
disassembled, or has missing or
broken parts, including a damaged
cord or plug.
■Basic sa ety precautions
6
Important safety instructions
■Basic sa ety precautions
■Save these instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
Improper connection of the equipment-grounding conductor can result in electric shock.
Check with a qualified electrician or serviceman if you are in dou t as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance - if it does not fit the
outlet, have a proper outlet installed y a qualified electrician.
G OUNDING INST UCTIONS
This appliance must e grounded. In the event of malfunction or reakdown, grounding will
reduce the risk of electric shock y providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-grounding conductor and
grounding plug. The plug must e plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinance.
• Do not use an adapter this will defeat the grounding plug.
• If you don’t have the proper outlet, consult an electrician.
WA NING
• Before discarding an old machine
unplug it. ender the plug useless.
Cut off the cable directly behind the
appliance to prevent misuse.
• When a product was under water,
Please call service center. There is a
risk of electric shock and fire.
• Appliance connected to the water
mains using new hose-sets. Old hose-
sets should not be reused.
• To reduce the risk of personal injury,
adhere to all industry recommended
safety procedures including the use
of long sleeved gloves and safety
glasses. Failure to follow all of the safety
warnings in this manual could result in
property, personal injury or death.
• Do not push down the door
excessively, when washer door open.
This could topple over the washer.
7
■Name : Front loading washing machine
■Power supply : 220 - 240 V~, 50 z
■Size : 600 mm(W) ✕640 mm(D) ✕850 mm( )
■Weight : 70 kg
■Max.Watt : 2200 W (Wash) / 1100 W (Steam)
0.33 W (The off-mode, The left-on mode)
■Wash capacity : 12 kg
■Permissible water pressure : 100 - 1000 kPa (1.0 - 10.0 kgf / cm
2
)
The appearance and specifications may vary without notice to improve the quality of the unit.
Specifications
1%
RinseTemp.40°C3
1:15
TimeLeft
Washing
■
Accessories
(For detergent and
fabric softener)
Drawer
Drain hose
Transit bolts Power plug
Control panel
Drain pump filter
Lower cover cap
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its service agents
or a similarly qualified person in
order to avoid a hazard.
Drum
Door Drain plug
Adjustable feet
Inlet hose(1EA)
❈
Option : ot/Cold(2EA) Spanner
8
Installation
■Removing packing
1. Remove the card oard ox and
styrofoam packing.
2. Lift the washing machine and remove
the ase packing.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Unscrew the 3 olts with
the spanner supplied.
2. Take out the 3 olts along with the
ru er ungs y slightly twisting the
ung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 3 special olts are locked.
Before operating the washer, remove the olts along with the ru er ungs.
If they are not removed, it may cause heavy vi ration, noise and malfunction.
■Removing transit bolts
Transit bolt
WA NING
• Packaging material (e.g. Films, Styrofoam) can e dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
NOTE
• Keep the spanner provided for
future use.
NOTE
• Keep the transit olts for future use.
Spanner
Washer
Base Packing
9
• Level floor :
Allowa le slope under entire washer is 1˚
• Power outlet :
Must e within 1.5 meters of either side of location of washer.
Do not overload the outlet with more than one appliance.
• Additional Clearance :
For Wall, 10cm:rear / 2cm : right & left side
Do not place or store laundry products on top of washer at
any times.
They can damage the finish or controls.
■Installation place requirements
❿
Positioning
❿
Location
• Install the washer on a flat hard floor.
• Make sure that air circulation around the washer is not impeded y carpets, rugs, etc.
• Never try to correct any unevenness in the floor with pieces of wood, card oard or similar
materials under the washer.
• If it is impossi le to avoid positioning the washer next to a gas cooker or coal urning stove,an
insulating(85x60cm) covered with aluminum foil on the side facing the cooker or stove,must e
inserted etween the two appliance.
• The washer must not e installed in rooms where the temperature can drop elow 0°C.
• Please ensure that when the washer is installed, it is easily accessi le for the engineer in the
event of a reakdown.
• With the washer installed, adjust all four feet using the transit olt spanner provided ensuring
the appliance is sta le, and a clearance of approximately 20mm is left etween the top of the
washer and the underside of any work-top.
• This equipment is not designed for maritime use or for use in a mo ile installations such as
caravans, aircraft etc.
Installation
Washer
approx.
2cm
• Do not use an extension cord or dou le adapter.
• If the supply cord is damaged, it must e replaced y the manufacturer or its service agents or
similarly qualified person in order to avoid a hazard.
• Always unplug the machine and turn off the water supply after use.
• Connect the machine to an earthed socket in accordance with current wiring regulations.
• The appliance must e positioned so that the plug is easily accessi le.
• Repairs to the washing machine must only e carried out y qualified personnel.
Repairs carried out y inexperienced persons may cause injury or serious malfunctioning.
Contact your local service center
• Do not install your washing machine in rooms where temperature elow freezing may occur.
Frozen hoses may urst under pressure. The relia ility of the electronic control unit may e
impaired at temperatures elow freezing point.
• If the appliance is delivered in the winter months and temperatures are elow freezing : Place
the washing machine at room temperature for a few hours efore putting it into operation.
❿
Electrical connection
10
Installation
CAUTION
CAUTION concerning the Power cord
• Most appliances recommend they e placed upon a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or ranch
circuits. Check the specification page of this owner's manual to be certain.
• Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in an electric shock or fire.
• Periodically examine the cord of your appliance, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part y an authorized servicer.
• Protect the power cord from physical or mechanical abuse, such as eing twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the appliance.
If the appliance is supplied from a cord extension set or an electrical porta le outlet
device, the cord extension set on electrical porta le outlet device must e positioned
so that it is not su ject to splashing or ingress of moisture.
CAUTION
• The appliance is not intended for use y young children or infirm persons without
supervision.
• Young children should e supervised to ensure that they do not play with appliance.
❿
BS plug sa ety details ( or U.K. user)
Important
The wires in this mains lead are coloured in
accordance with the following code:
Green and yellow: Earth
Blue: Neutral
Brown: Live
This appliance must e earthed.
Green and
Yellow(Earth)
Brown(Live)
Blue(Neutral) Fuse
Cord grip
As the colours of the wires in the mains lead of this apparatus may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured Green and Yellow must e connected to the terminal in the plug which
is marked with the letter E or y the earth sym ol or coloured Green or Green and Yellow.
The wire which is coloured Blue must e connected to the terminal which is marked with the letter
N or coloured Black.
The wire which is coloured Brown must e connected to the terminal which is marked with the
letter L or coloured Red.
If a 13 amp (BS 1363) plug is used, fit a 13 amp BS 1362 fuse.
E
L
N
Altri manuali per F1495BDS
1
Questo manuale è adatto per i seguenti modelli
10
Indice
Altri manuali LG Rondella
LG
LG T1366NEHVF Manuale utente
LG
LG FV1450S2 Series Manuale utente
LG
LG F4J7JS Series Manuale utente
LG
LG WV5 Series Manuale utente
LG
LG WM2250CW Manuale utente
LG
LG T1369NEHTF Manuale utente
LG
LG F V509 Series Manuale utente
LG
LG WD14030D Manuale utente
LG
LG F1410SPRE Manuale utente
LG
LG WT1501C Series Manuale utente
LG
LG WM5500H A Series Manuale utente
LG
LG WFT6500 Manuale utente
LG
LG T8007TEFT0 Manuale utente
LG
LG FH U1 BS Series Manuale utente
LG
LG T2511VSA Manuale utente
LG
LG F14A8RDS Manuale utente
LG
LG F 255RDS2 Series Manuale utente
LG
LG P8237R3S Manuale utente
LG
LG F14WD85EH Series Manuale utente
LG
LG F4V910 TSE Series Manuale utente
