Life Span Traction II Manuale utente

Product may vary slightly from the item pictured due to model upgrades

Read all instructions carefully before using this product. Retain this owner’s manual for

future reference.

TRACTION II

OWNER’S MANUAL

TRACTION II

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS 3

2. IMPORTANT ELECTRICAL INFORMATION 4

3. IMPORTANT OPERATING INSTRUCTIONS 5

4. ASSEMBLY INSTRUCTIONS 6

5. FOLDING INSTRUCTIONS 9

6. INCLINE INSTRUCTIONS 10

7. GROUNDING METHODS 11

8. OPERATION GUIDE 12

9. EXERCISE GUIDE 18

10. MAINTENANCE GUIDE 20

11. EXPLODED DIAGRAM 24

12. PARTS LIST 25

13. TROUBLE SHOOTING GUIDE 27

14. WARRANTY 29

TRACTION II

1. IMPORTANT SAFETY INSTRUCTIONS

WARNING - Read all instructions before using this treadmill.

It is important your treadmill receives regular maintenance to prolong its useful life. Failing to

regularly maintain your treadmill may void your warranty.

Danger –To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to

cleaning and/or service work.

DO NOT USE AN EXTENSION CORD: DO NOT ATTEMPT TO DISABLE THE GROUNDED PLUG BY

USING IMPROPER ADAPTERS OR IN ANY WAY MODIFY THE CORD SET.

Install the treadmill on a flat level surface with access to a 220-240 volt (50/60Hz), grounded outlet.

Do not operate treadmill on deeply padded, plush or shag carpet. Damage to both carpet and

treadmill may result.

Do not block the rear of the treadmill. Provide a minimum of 1 metre clearance between the rear of

the treadmill and any fixed object.

Place your unit on a solid, level surface when in use

Never allow children on or near the treadmill.

When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should

you fall or move too far back on the treadmill.

Keep hands away from all moving parts.

Never operate the treadmill if it has a damaged cord or plug.

Keep the cord away from heated surfaces.

Do not operate where aerosol spray products are being used or where oxygen is being administered.

Sparks from the motor may ignite a highly gaseous environment.

Never drop or insert any object into any openings.

The treadmill is intended for in-home use only and not suitable for long time running.

TRACTION II

To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug

from the outlet.

The pulse sensors are not medical devices. Various factors, including the user’s movement, may

affect the accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in

determining heart rate trends in general.

Use the handrails provided; they are for your safety.

Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your

treadmill. Quality athletic shoes are recommended to avoid leg fatigue.

Allowed temperature: 5 to 40 degrees.

Remove the safety key after use to prevent unauthorized treadmill operation.

2. IMPORTANT ELECTRICAL INFORMATION

WARNING!

NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. Route the power

cord away from any moving part of the treadmill including the elevation mechanism and transport

wheels.

NEVER remove any cover without first disconnecting AC power.

NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors,

near a pool, or in any other high humidity environment.

TRACTION II

3. IMPORTANT OPERATING INSTRUCTIONS

Be sure to read the entire manual before operating your machine.

Understand that changes in speed and incline do not occur immediately. Set your desired speed on

the computer console and release the adjustment key. The computer will obey the command

gradually.

Use caution while participating in other activities while walking on your treadmill, such as watching

television, reading, etc. These distractions may cause you to lose balance or stray from walking in

the centre of the belt; which may result in serious injury.

In order to prevent losing balance and suffering unexpected injury, NEVER mount or dismount the

treadmill while the belt is moving. This unit starts with at a very low speed. Simply standing on the

belt during slow acceleration is proper after you have learned to operate this machine.

Always hold on to handrail while making control changes.

A safety key is provided with this machine. Remove the safety key will stop the walking belt

immediately; the treadmill will shut off automatically. Inserting the safety key will reset the display.

Do not use excessive pressure on console control keys. They are precision set to function properly

with little finger pressure.

TRACTION II

4. ASSEMBLY INSTRUCTIONS

22L/R

PART LIST

NO.

DESCRIPTION

REMARK

Q’Y

NO.

DESCRIPTION

REMARK

QTY

MAIN FRAME

BOLT

M8*15

８

SAFETY KEY

BOLT

M6*25

22L/R

FRONT COVER

INNER WASHER

∮8.4*∮14.5*

t0.8

８

FOOT PLATE

MP3 OUTPUT

WIRE

FOOT PLATE PLUG

BOLT

M4*15

ALLEN WRENCH

SCREW DRIVER

TRACTION II

STEP 1:

STEP 2:

1. Use the M8*15 bolt (62) and washer (84) to

lock the computer (18) to the upright

(4L/4R).

1. Open the box and put mainframe on the

floor;

2. With both hands holding the computer (18),

rotate the uprights (4L/4R) so it is aligned

with the arch pocket on mainframe (2) as

shown by the arrow

3. Use the M8*15 bolt (62) and washer (84) to

secure the uprights (4L/R) to the

mainframe (2)

4. Use the M4*15 bolt (91) to secure the

cover (22) to the mainframe (2)

5. Pull up (4L/4R), as shown by the arrow,

and rotate until it is aligned with the arch

pockets on uprights (4L/4R).

TRACTION II

STEP 3:

STEP 4:

ATTENTION

You must first confirm that you have performed a complete assembly as outlined above and

secured all nuts bolts before proceeding with the following.

1. Put on the safety key and MP3 output wire

1. Use the M6*25 bolt (63) to lock the foot

plate (23) to the running board (13) tightly

2. Attach the foot plate plug (33)

TRACTION II

5. FOLDING INSTRUCTIONS

Folding:

Unfolding:

Erect the base frame using position (A)

until you hear the click sound emitted by

the lock pin

Whilst supporting position (A) with your

hand, use your hand to pull the spring

pin (B) lightly and allow the machine to

descend but itself smoothly.

TRACTION II

6. INCLINE INSTRUCTIONS

PICTURE 1

PICTURE 2

“INCLINE+/-”and “+/-”on left handrail are incline add and subtract buttons.

When adjusting the incline whilst the treadmill is running, the increase is 1 level per press.

Holding the incline for button more than 2 seconds will quickly increase or decrease the incline.

There are also shortcut keys 3, 6, 9, 12 on the computer.

Picture 1 shows incline ”0”, Picture 2 shows incline “20”.
