REED PREMIER

MOUNTING INSTRUCTIONS

12371.000.000 Rev M

CONTINUES ON BACK

SCREW MOUNT

1. Kit includes two (2) bracket clips, two (2) screws (Fig. 1).

2. Screw bracket clip to shelf in desired location (approximately 12”

spacing centered under the shelf), ensuring that both clips are

oriented in the same direction (Fig. 2).

3. Raise xture to clip, aligning the channel on the back of xture

with clip and snap in place (Fig. 3 and Fig. 4).

4. Plug DC cord to either end of xture and route to power supply.

5. If equipped with an occupancy sensor, connect the third screw

bracket clip in-line with the two already installed, and

approximately 2” from the end of the xture. Connect the sensor to

xture and snap into place (Fig. 12).

6. Place power supply on any horizontal surface, allowing the plug to

be inserted into 120V AC, 60Hz, grounded outlet (Fig. 11).

STANDARD MAGNETIC MOUNT

1. Magnetic clips attach by clamping to the back surface of the

xture housing, for direct mounting to metal shelving.

2. For all xtures: use 1 magnetic clip per end located at the distance

specied for the given xture length (Fig. 7) in the table below:

3. Locate xture to the desired position on metal shelf (Fig. 5) and set

in place (Fig. 6).

4. Plug DC cord to either end of xture and route to power supply.

5. If equipped with an occupancy sensor, connect the standard

magnetic clip to the OS body and install (Fig. 12).

6. Place power supply on any horizontal surface, allowing the plug to

be inserted into 120V AC, 60Hz, grounded outlet (Fig. 11).

MAGNETIC ANGLE MOUNT

1. Magnetic angle clips attach by clamping to the back surface of the

xture housing for direct mounting to metal shelving.

2. For all xtures: use 1 magnetic angle clip per end located at the

distance specied for the given xture length (Fig. 7) in the table below:

3. Place one side of the clip against the xture housing and press the

opposite side down until it snaps into place. Adjust clip positions

to the recommended position shown above, by sliding into place.

4. Locate xture to the desired position on metal shelf (Fig. 5) and set

in place (Fig. 6).

5. Adjust light output angle to desired direction by rotating the xture (Fig.

8). For best results, push on the edge of the xture to change angle.

6. If clip doesn’t hold position, remove xture and tighten with a T10

driver. To remove, pry off one edge gently with a at head screw driver.

7. Plug DC cord to either end of xture and route to power supply.

8. If equipped with an occupancy sensor, connect the standard

magnetic clip to the OS body and install using exible cord

provided per the instructions on the reverse side.

Fig. 1 Fig. 2

Fig. 3 Fig. 4

Fig. 5 Fig. 6

Caution: Magnetic eld present in magnet mount xture.

FIXTURE FAMILY

Approximate clip distance

“X” from end of xture

17”

1”

24”

3”

31”

3”

44”

6”

58”

9”

Fig. 7

Fig. 8

“X”

FIXTURE FAMILY

Approximate clip distance

“X” from end of xture

17”

1”

24”

3”

31”

3”

44”

6”

58”

9”

Fig. 9

MAGNETIC ANGLE MOUNT (CONT’D)

9. Place power supply on any horizontal surface, allowing the plug

to be inserted into 120V AC, 60Hz, grounded outlet (Fig. 11).

CONNECTING MULTIPLE FIXTURES

1. Route interconnect cord from one end of a xture to the end of

an adjacent xture (Figs. 9, 10). The maximum distance between

the interconnected xtures is determined by the length of the DC

cord provided, excluding the connectors.

2. Place power supply on any horizontal surface, allowing the plug

to be inserted into 120V AC, 60Hz, grounded outlet (Fig. 11).

3. Route the low power DC cord from power supply to either end of

one of the xtures.

NOTE: Route cords as to not kink or pinch, which may cause damage to

the cord. When connecting more than one xture, total wattage of

xtures must not exceed power supply rating, see components for

wattage rating. Cannot interconnect Reed Classic and Reed Premier.

REED OCCUPANCY SENSOR

Connection sequence: Power--> Sensor--> Connector--> Fixture

The optional Reed Integral Passive Infrared (PIR) occupancy sensor

automatically turns the xture off after 30 minutes of no detection.

Coverage: 360 degree lens view, 90 degree outward detection angle,

coverage of 36” diameter at 18” distance: 15 (i.e. Coverage

Diameter = 2 x Distance).

NOTE: Reed OS must be installed in-line between power supply and

xture (Fig. 12). Only one occupancy sensor is required per

interconnect line.

REED INTEGRATED OCCUPANCY SENSOR

Connection sequence: Power--> Fixture (Occ sensor input)

The Reed Integral Passive Infrared (PIR) occupancy sensor

automatically turns the xture off after 30 minutes of no detection.

Coverage: 360 degree lens view, 90 degree outward detection angle,

coverage of 36” diameter at 18” distance: 15 (i.e. Coverage

Diameter = 2 x Distance).

NOTE: Reed OS must have power supplied to the occupancy sensor side

of the xture to properly operate (Fig. 13).

DIMMING

Touch and hold your nger on the touch pad. The xture will

brighten and then dim. Release the touch pad when preferred level

of brightness is obtained. Each time the xture is turned on it will

return to the level of brightness that was set by the user. To reset

the brightness to a different light level simply touch and hold the

touch pad. This will need to be performed on each xture.

RECOMMENDED CORD CONNECTOR

Hubbell Brand Nylon Cord Connector: SHC1022CR UL/CSA Listed,

HUB Size: 1/2”, Diameter Range: .25” - .38”

REED PREMIER

MOUNTING INSTRUCTIONS

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or

relocate the receiving antenna, Increase the separation between the equipment and receiver, Connect the equipment into an output on a circuit different from that to which the receiver is connected, or

consult the dealer or an experienced radio/TV technician for help.

Fig. 10

Fig. 11

Fig. 12

Fig. 13
