Lily NEXT-GEN™

Camera. Drone. Reinvented™

Owner’s Manual V1.0.1

For updates please visit www.lily.camera

Legend............................................1

Reading Suggestions............................................................1

Downloading the App............................................................1

Overview.........................................2

Introduction...........................................................................2

Feature Highlights.................................................................2

LILY CAMERA NEXT-GEN DRONE App...............................2

Visual Positioning..................................................................2

High Denition Photo & Video Capture................................2

Electronic Image Stabilization (EIS)......................................2

Object Tracking and Follow Me.............................................2

Orbit (360º)............................................................................2

Intelligent Operation..............................................................3

One-Touch Sharing...............................................................3

Lily Next-Gen-At-A-Glance....................................................3

Features..........................................5

On/Off Switch and Power Indicator.......................................5

Drone Status Indicator..........................................................5

GPS Positioning....................................................................5

Optic Flow and Ultrasonic Positioning..................................6

Usage Conditions and Restrictions......................................6

Propellers..............................................................................6

Battery………………………………………………............…..8

Camera...............................................................................11

Signal Frequency.................................................................11

Micro-USB Port...................................................................11

Reset Button........................................................................11

LILY CAMERA NEXT-GEN DRONE App.............................12

App Overview......................................................................12

App Operation Interface.....................................................12

1.Back to main interface......................................................13

2.Wi-Fi Connection Status...................................................13

3.Current Flight Distance.....................................................13

4.Current Flight Height........................................................13

5.Aircraft Battery..................................................................13

6.Positioning Status............................................................14

7.Status Bar.....................................................................14

8.App Settings.....................................................................14

9.Object Tracking................................................................14

10. Obit (360º).....................................................................14

11.Photo/Video Switch........................................................14

12.Shutter............................................................................15

13.Camera Settings............................................................15

14. Media Library.................................................................15

15. Take-off / Landing / Stop................................................15

16. Return to Home.............................................................15

App Settings........................................................................15

Compass Calibration...........................................................15

Photograph Vibration..........................................................15

App Mute.............................................................................16

Control Method..................................................................16

CONTENTS

Change Wi-Fi Information..............................................16

Lily FC Update.................................................................16

Lily OS Update.................................................................16

Available Storage............................................................16

Personal Center Settings Quick Guide...........................16

Malfunction Report..........................................................17

Suggestions and Feedback............................................17

Change Password..........................................................17

Language.........................................................................17

About...............................................................................17

Media Library..................................................................17

Photo Thumbnails...........................................................17

Selecting Photos............................................................18

Deleting Photos...............................................................18

Downloading & Browsing.................................................18

Photo Sharing..................................................................18

Videos..............................................................................19

Flying/Shooting..........................20

Flight Environment Requirements..................................20

Outdoors.........................................................................20

Indoors.............................................................................20

Flight Restrictions...........................................................20

No-Fly Zones.................................................................21

Preight Checklist..........................................................21

Calibrating the Compass................................................21

Flight Protections.............................................................22

Connecting Your Lily to a Mobile Device.........................22

Take-off / Landing.............................................................23

Flight Control...................................................................23

Motion Sensing................................................................23

Free Sticks.......................................................................24

Safe Sticks.......................................................................26

Taking Photos/Video Recording.......................................26

Taking Photos..................................................................26

Electronic Image Stabilization.........................................26

Orbit (360º)......................................................................27

Object Tracking................................................................30

Return to Home................................................................31

Warranty Card............................33

Purchase Information.......................................................33

Maintenance Records......................................................33

Legend

Symbols

Warning Tips

Reading Suggestions

We have provided the following materials for Lily Next-Gen users. To learn how to get the

most use out of your Lily Next-Gen, we suggest you read them in this order:

1. Battery Safety Instructions / Disclaimer

2. Quick Start Guide

3. Owner’s Manual

Downloading the App

Before using this product, you need to download and install the Lily app. You can scan the

following QR code, or search for Lily in the App Store or Google Play, or login and download

from the Lily website.

Lily Next-Gen supports Android 4.3 and later versions, iOS 8.4 and later versions.

Overview

This section will introduce Lily’s features and the names of Lily’s principal components.

Introduction

Lily is a portable and easy-to-use drone for entertainment. It consists of the aircraft itself and

an accompanying app.

Through using the app, you can control Lily’s ight, take photos and record videos.

Feature Highlights

In order to give you a convenient and safe ying and photographing experience, Lily has

several great features:

LILY CAMERA NEXT-GEN DRONE App

The app is specically developed for Lily and is simple to use. It can be used as a remote

control for ight control and for photo & video shooting.

Visual Positioning

Lily uses both optic ow and ultrasonic positioning to support ight when there is no or a

weak GPS signal such as indoors. Please install the propeller guard when ying indoors.

High Denition Photo & Video Capture

Lily is equipped with a professional high-denition camera, the SONY IMX 214, 13MP. It

features 4K and

1920 x 1080 video shooting.

Electronic Image Stabilization (EIS)

Lily is equipped with electronic image stabilization (EIS), which reduces or eliminates

vibration in images. With EIS, photos are saved to the built-in memory with a resolution up to

2880 x 1620 at 96 dpi / 24 bit depth. Videos are stabilized at a resolution of 1920 x 1080p at

30 fps. EIS may be switched off.

Object Tracking and Follow Me

Using advanced image recognition technology, Lily can follow and record video on a moving

object you’ve chosen.

Orbit (360º)

Automatically y and record video around a stationary point at a specied altitude and radius.

Intelligent Operation

When ying outdoors, the LILY CAMERA NEXT-GEN DRONE app supports multiple one-

touch ight operations with just one tap on the screen., such as One-Touch Takeoff, One-

Touch Landing, and One-Touch Return.

One-Touch Sharing

Directly share your photos and videos with your friends on SNS.

Lily Next-Gen At-a-Glance

①Camera

②Propeller

③Arm

④Battery compartment

①

②

③

④

⑤Reset Button

⑥Power Button, Indicator Light

⑦Micro USB port

⑧Optic Flow and Ultrasonic Positioning Module

⑤

⑥

⑦

⑧

Features

Lily principally consists of ve systems: ight, positioning, communications, power supply

and the camera system. This section will explain the functions of each.

On/Off Switch and Power Indicator

The On/Off Switch has a built in Power Indicator.

Hold the On/Off Switch for 3 seconds. Wait until the Power Indicator shows solid green, then

remove your nger and Lily will switch on. After a few seconds, Lily will sound, alerting you

that the ESC has turned on.

After connecting to the app, the Power Indicator will ash green.

Hold the On/Off Switch for 3 seconds. Wait until the blue light of the Power Indicator goes

out, then remove your nger and Lily will switch off.

Drone Status Indicator

On the tail of the aircraft, there’s an RGB indicator that shows the status of Lily. The Status

Indicator’s colors and corresponding meanings are as follows:

GPS Positioning

Lily uses a GPS & GLONASS dual-mode satellite positioning system. The satellite

positioning.system is GPS based, with GLONASS acting as a supplementary system.

During outdoor ights, Lily uses GPS positioning when the number of identied satellites ≥8.

Normal Status

Assistant Prompts

Warming And Abnormal Status

INDICATOR COLOR MEANING

Slow Green Flashing

Green Double Flash

Solid Light Blue

Light Blue Double Flash

Solid Blue

Blue Double Flash

Red Double Flash

Slow Red Flashing

Solid Red

Light off

Red-Blue Alternate Flashing

Normal Status

Optical Flow and Ultrasonic Positioning

Horizontal Compass Calibration successful

Horizontal Compass Calibration not successful

Vertical Compass Calibration successful

Vertical Compass Calibration not successful

Critical Battery Warning

Low Battery Warnning

No-Fly Zone Warning

GPS Failure

Other Failure

Solid Blue for 3s Hold And Power Off

Optic Flow and Ultrasonic Positioning

Lily will use the optic ow and ultrasonic positioning during indoor ight. If the GPS signal

is weak (the number of identified satellites is <8) during outdoor flight, the drone will

automatically use optic ow and ultrasonic positioning as supplements.

Usage Conditions and Restrictions

The optic ow and ultrasonic positioning system are used for indoor ight. It is also used

for outdoor ight if the GPS signal is weak. The operating height range for optic ow and

ultrasonic positioning is 0.5-3m.

When using this positioning system, after the drone has taken off and ascended to 0.5m, it

will determine if the requirements for using this system have been met. If they have not, it

will initiate landing. If the requirements are not met for this system during ight, the drone will

initiate landing.

Requirements for the optic ow and ultrasonic positioning system: When using this system,

the area underneath the aircraft needs to have a clear textured surface.

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

The optic flow and ultrasonic positioning system may not work under these

circumstances, so please use with caution:

◎Above highly reective surfaces;

◎Above water or transparent objects;

◎Above people or moving objects;

◎In areas with rapidly changing/ashing lights;

◎Above very bright or very dark surfaces;

◎Above objects that easily absorb ultrasonic waves;

◎Above surfaces without clear textures or with too sparse or too dense textures;

◎During fast ight at low levels (0.5m or less)

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

◎Ensure that the lens of the optic ow camera is clear.

◎Because the ultrasonic positioning system may be affected by ultrasonic waves

emitted by other ultrasonic equipment, please do not y near other ultrasonic

equipment, including other drones.

◎The ultrasonic sensor will emit ultrasonic waves that are inaudible to humans but

may make some animals nervous. Please do not use the drone close to animals.

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Propellers

Lily has 4 sets of foldable propellers. The propellers are already mounted; users need only

to expand the arms before the ight. When you’re done with ying, fold the arms and the

blades to prevent damaging them.
