Lindy C5 Pro 39393 Manuale utente

K M Extender C5 Pro

User Manual English

LINDY Art No. 39393

English Manual

LINDY KVM Extender C5 Pro Installation and Use page

About this manual

LINDY KVM Extender C5 Pro - Installation and Use www.lindy.co.uk

First edition (October 003)

assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the

use of the information contained herein. We reserve the right to change the specifications, functions and circuitry of

the product without notice.

Safety Information

• For use in dry, oil free indoor environments only.

• Warning - live parts contained within the power adapter.

• No user serviceable parts within power adapter - do not dismantle

• Plug the power adapter into a socket outlet close to the Extender C5 unit that it is powering.

• Replace the power adapter with a manufacturer approved type only.

• Do not use the power adapter if the power adapter case becomes damaged, cracked or broken or if you

suspect that it is not operating properly.

• If you use a power extension cord with the Extender C5, make sure the total ampere rating of the devices

plugged into the extension cord does not exceed the cord’s ampere rating. Also, make sure that the total

ampere rating of all the devices plugged into the wall outlet does not exceed the wall outlet’s ampere

rating.

Warranty information

LINDY warrants that this product shall be free from defects in workmanship and materials for a period of three

years from the date of original purchase. If the product should fail to operate correctly in normal use during the

warranty period, LINDY will replace or repair it free of charge. Any faulty items are to be returned to LINDY at the

owner’s expense. No liability can be accepted for damage due to misuse or circumstances outside LINDY’s control.

Also, LINDY will not be responsible for any loss, damage or injury arising directly or indirectly from the use of this

product. LINDY’s total liability under the terms of this warranty shall in all circumstances be limited to the

replacement value of this product. This warranty goes on top of any applicable legal regulation and does not limit

any customer rights compared to the legal regulations.

Trademarks

All trademarks mentioned in this manual are acknowledged to be the property of the respective trademark owners.

Compaq is a registered trademark of Compaq Computer Corporation.

Hewlett-Packard is a registered trademark of Hewlett-Packard.

IBM, PC/AT, PS/ , RS/6000 and ThinkPad are registered trademarks of International Business Machines

Corporation.

Microsoft and Windows are registered trademarks, and IntelliMouse is a trademark of Microsoft Corporation.

Logitech, MouseMan+ and Pilot Mouse+ are trademarks of Logitech Inc.

Velcro is a trademark of Velcro USA Inc.

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 3

Radio Frequency

A Category 5 (or better) twisted pair cable must be used to connect the LINDY Extender C5 units in order to

maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity

to electromagnetic disturbances.

All other interface cables used with this equipment must be shielded in order to maintain compliance with radio

frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic

disturbances.

European EMC directive 89/336/EEC

This equipment has been tested and found to comply with the limits for a class A computing device in accordance

with the specifications in the European standard EN550 . These limits are designed to provide reasonable

protection against harmful interference. This equipment generates, uses and can radiate radio frequency energy

and if not installed and used in accordance with the instructions may cause harmful interference to radio or

television reception. However, there is no guarantee that harmful interference will not occur in a particular

installation. If this equipment does cause interference to radio or television reception, which can be determined by

turning the equipment on and off, the user is encouraged to correct the interference with one or more of the

following measures: (a) Reorient or relocate the receiving antenna. (b) Increase the separation between the

equipment and the receiver. (c) Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected. (d) Consult the supplier or an experienced radio / TV technician for help.

FCC Compliance Statement (United States)

This equipment generates, uses and can radiate radio frequency energy and if not installed and used properly, that

is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has

been tested and found to comply with the limits for a class A computing device in accordance with the

specifications in Subpart J of part 15 of FCC rules, which are designed to provide reasonable protection against

such interference when the equipment is operated in a commercial environment. Operation of this equipment in a

residential area may cause interference, in which case the user at his own expense will be required to take

whatever measures may be necessary to correct the interference. Changes or modifications not expressly

approved by the manufacturer could void the user’s authority to operate the equipment.

Canadian Department of Communications RFI statement

This equipment does not exceed the class A limits for radio noise emissions from digital apparatus set out in the

radio interference regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux

appareils numériques de la classe A prescrites dans le règlement sur le brouillage radioélectriques publié par le

ministère des Communications du Canada.

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 4

Contents

1. Introduction........................................................................................................ 6

1.1 Supplied items............................................................................................................. 7

. Installation......................................................................................................... 9

.1 Extender C5 configuration switch settings.................................................................. 9

. Mounting the Extender C5 module............................................................................ 1

3. Connections.................................................................................................... 13

Connections at the LOCAL module.................................................................................. 13

3.1 KVM+A multi-cable connection................................................................................... 13

3. Serial cable connection................................................................................................ 14

3.3 Twisted pair connection.............................................................................................. 14

Connections at the REMOTE module............................................................................... 15

3.4 Keyboard, Video and Mouse connections................................................................... 15

3.5 Twisted pair, Power and Serial connections............................................................... 15

3.6 Audio connections....................................................................................................... 16

4. Operation........................................................................................................... 18

4.1 Power and activity indicators....................................................................................... 18

4. Locking and unlocking the system............................................................................... 19

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 5

5. Special Configuration....................................................................................... 0

5.1 Configuration.............................................................................................................. 0

5. What are hotkeys? ...................................................................................................... 0

5.3 Configuration mode.................................................................................................... 1

5.4 Password setting........................................................................................................

5.5 Password override......................................................................................................

5.6 Hot plugging and Mouse restoration.......................................................................... 3

5.7 Video compensation.................................................................................................. 5

5.8 Skew Compensator.................................................................................................... 7

5.9 Producing a Skew compensator report...................................................................... 8

5.10 Miscellaneous settings.............................................................................................. 9

6. Flash upgrade procedure.................................................................................. 30

6.1 Downloading the upgrade files.................................................................................... 30

6. Creating a startup disk................................................................................................ 31

6.3 Reconfiguring the LOCAL connections....................................................................... 3

6.4 Reconfiguring the REMOTE connections................................................................... 33

6.5 Returning all connections to their usual states........................................................... 33

7. Troubleshooting................................................................................................. 34

8. Extender C5 Accessories.................................................................................. 36

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 6

1. Introduction

Thank you for purchasing the LINDY Extender C5 Pro set which allows you to place the controlling keyboard,

video monitor, mouse, audio accessories (and also a serial device) up to 00 metres from a system. The LINDY

Extender C5 Pro set consists of two modules: a local module that attaches to your computer system and a

remote module to which the peripherals are connected. The long distance link between the two modules is

made via Category 5, or higher, twisted pair cabling.

Internal circuitry within the remote module ensures crisp video images by automatically compensating for the

length of the twisted pair cable run.

Throughout this document, the LINDY Extender C5 Pro is

commonly abbre iated to Extender C5

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 7

1.1 Supplied items

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 8

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 9

2. Installation

The installation of the Extender C5 set is straightforward and can best be achieved in most cases by

following these stages for each module:

• Check or set the configuration switch settings

• Mount the module

• Connect the cables

2.1 Configuration switch settings

The basic operations of the LOCAL and REMOTE modules are controlled by the banks of four switches located

on the side of each module. The switches are monitored at all times and may be changed when power is on or

off (the only exception to this rule is switch 1 of the LOCAL module which initiates slightly different functions

depending on the power state when it is switched).

LOCAL Switch 1

OFF: Normal operation

ON: (Before power is applied) Places the LOCAL module into flash upgrade mode so that the internal

software can be changed. (See section 6. Flash upgrade procedure)

ON: (Whilst power is applied) Places the REMOTE module into password override mode. This allows any

pre-configured passwords to be altered – particularly useful when they have been lost or forgotten. (See

section 5.5 Password override.)

Note: When shipped, all switches are set in the OFF positions and this will produce normal operation with

normal microphone input (at the REMOTE module.)

English Manual

LINDY KVM Extender C5 Pro Installation and Use page 10

LOCAL Switch 2

OFF: Normal operation.

ON: Set transparent mode. Use this setting if the Extender C5 modules are to be used with KVM switches

that are not manufactured by LINDY Electronics. Cascaded KVM switches often use special signals to

set or identify conditions. In transparent mode, the Extender C5 modules will pass the signals without

attempting to interpret them.

LOCAL Switch 3

OFF: Microphone input on REMOTE module. Use this setting if a standard mono-channel microphone is

connected to the microphone input on the REMOTE unit.

ON: Stereo line-in input on REMOTE module. Use this setting if a stereo input is applied to the microphone

input on the REMOTE unit.

LOCAL Switch 4

OFF: Normal operation.

ON: Suspend operation and reset the LOCAL module. Use this setting momentarily to produce the same

effect as removing and restoring power if incorrect operation has occurred. Return the switch to the OFF

position to allow normal operation to continue.
