Linksys USBBT100 Manuale utente

A Division of Cisco Systems, Inc.

Model No.

USB Adapter

Bluetooth

USBBT100

User Guide

WIRELESS

Bluetooth USB Adapter

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco

rights reserved. Other brands and product names are trademarks or registered trademarks of their respective

holders.

How to Use this User Guide

This User Guide to the Bluetooth USB Adapter has been designed to make understanding using the Adapter easier

than ever. Look for the following items when reading this Guide:

In addition to these symbols, there are definitions for technical terms that are presented like this:

Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like

this:

Figure numbers and descriptions can also be found in the "List of Figures" section in the “Table of Contents”.

This exclamation point means there is a Caution or

warning and is something that could damage your

property or the Adapter.

word: definition.

This checkmark means there is a Note of interest and

is something you should pay special attention to while

using the Adapter.

This question mark provides you with a reminder about

something you might need to do while using the Adapter.

Figure 0-1: Sample Figure Description

USBBT100-UG-50227 KL

WARNING: This product contains chemicals, including lead, known to the State of California to

cause cancer, and birth defects or other reproductive harm. Wash hands after handling.

Bluetooth USB Adapter

Chapter 1: Introduction 1

Welcome 1

What’s in this Guide? 2

Chapter 2: Installing the Bluetooth Software and Connecting the Adapter 3

Installing the Bluetooth Software 3

Connecting the Adapter 6

Chapter 3: Using the Bluetooth USB Adapter 7

Navigating from Your Desktop 7

The Bluetooth System Tray Icon 8

Explore My Bluetooth Places 8

The Bluetooth Setup Wizard 9

Advanced Cofiguration 13

Quick Connection 18

Appendix A: Troubleshooting 19

Common Problems and Solutions 19

Frequently Asked Questions 20

Appendix B: Bluetooth Applications and Services 21

Bluetooth Client Applications 21

Services 22

Appendix C: Specifications 23

Appendix D: Warranty Information 25

Appendix E: Regulatory Information 26

Appendix F: Contact Information 29

Dual-Band Wireless Access Point

Figure 1-1: The Bluetooth USB Adapter 1

Figure 2-1: The Setup Wizard’s Welcome Screen 3

Figure 2-2: The InstallShield Wizard’s Welcome Screen 3

Figure 2-3: The License Agreement Screen 4

Figure 2-4: The Destination Folder Screen 4

Figure 2-5: The Install Screen 4

Figure 2-6: The Driver Signature Notice 5

Figure 2-7: The Adapter’s Connection Screen 5

Figure 2-8: The Wizard Completed Screen 5

Figure 2-9: The Bluetooth Icon 6

Figure 2-10: Connecting the Adapter 6

Figure 3-1: The Bluetooth Icon 7

Figure 3-2: The Bluetooth System Tray Icon’s Menu 8

Figure 3-3: My Bluetooth Places 8

Figure 3-4: The Bluetooth Setup Wizard 9

Figure 3-5: The Bluetooth Service Selection Screen 10

Figure 3-6: The Bluetooth Device Selection Screen 10

Figure 3-7: The Setup Wizard Completion Screen 10

Figure 3-8: The Bluetooth Device Selection Screen 11

Figure 3-9: The Bluetooth Security Setup Screen 11

Figure 3-10: The Bluetooth Service Selection Screen 11

Figure 3-11: The Bluetooth Service Selection Screen 12

Figure 3-12: Change the Computer Name and Type 12

Figure 3-13: Bluetooth Configuration - General tab 13

Figure 3-14: Bluetooth Configuration - Accessibility tab 14

Figure 3-15: PIN code notification 14

Figure 3-16: Bluetooth Configuration - Discovery tab 15

Figure 3-17: Bluetooth Configuration - Local Services tab 16

Figure 3-18: Local Services Properties 16

Figure 3-19: Bluetooth Configuration - Client Applications tab 17

Figure 3-20: Client Applications Properties 17

Figure 3-21: Bluetooth Configuration - Hardware 18

Figure 3-22: Quick Connection 18

Chapter 1: Introduction

Welcome

Bluetooth USB Adapter

Chapter 1: Introduction

Welcome

Thank you for choosing the Bluetooth USB Adapter. This Adapter brings all the uses of Bluetooth directly to your

PC.

As you probably already know, Bluetooth technology provides consumer device connectivity, interfacing with your

cellular phone, allowing PDA synchronization, and so much more. With every new Bluetooth device, your PC will

now grant you access.

But what does all of this mean?

Bluetooth technology is always functioning, and can connect to other Bluetooth devices with Quick Connect.

Consider your Bluetooth cell-phone. When brought within range of the USB Adapter, connected to your PC, you

can upload phone directories onto your phone, dial out on your dial-up Internet connection on your cell-phone, or

grab photos if your phone has an integrated camera. Imagine synchronizing your PDA without cables, using a

Bluetooth mouse without line-of-sight Infrared lights, or printing to a Bluetooth printer.

PCs equipped with the Adapter can communicate without cumbersome cables and, since it’s USB, there’s no

need to open your PC or engage in complex configuration.

Use the instructions in this User Guide to help you connect the Adapter, set it up, and configure it to function with

your Bluetooth devices. These instructions should be all you need to get the most out of the Adapter.

Figure 1-1: The Bluetooth USB Adapter

Bluetooth: short-range wireless technology

used for replacing cables in many

consumer-electronics devices.

Chapter 1: Introduction

What’s in this Guide?

Bluetooth USB Adapter

What’s in this Guide?

This user guide covers the steps for setting up and using the Bluetooth USB Adapter.

• Chapter 1: Introduction

This chapter describes the Adapter’s applications and this User Guide.

• Chapter 2: Installing the Bluetooth Software and Connecting the Adapter

This chapter describes the Adapter’s basic setup and connection.

• Chapter 3: Using the Bluetooth USB Adapter

This chapter instructs you on the Adapter’s various tools and functions.

• Appendix A: Troubleshooting

This appendix describes some problems and solutions, as well as frequently asked questions, regarding

installation and use of the Adapter.

• Appendix B: Bluetooth Applications and Services

This appendix provides information on all the applications and services you may use with the Adapter

• Appendix C: Specifications

This appendix provides the technical specifications for the Adapter.

• Appendix D: Warranty Information

This appendix supplies the warranty information for the Adapter.

• Appendix E: Regulatory Information

This appendix supplies the regulatory information regarding the Adapter.

• Appendix F: Contact Information

This appendix provides contact information for a variety of Linksys resources, including Technical Support.

Chapter 2: Installing the Bluetooth Software and Connecting the Adapter

Installing the Bluetooth Software

Bluetooth USB Adapter

Chapter 2: Installing the Bluetooth Software and Connecting

the Adapter

Installing the Bluetooth Software

Before connecting the Adapter to your PC’s USB port, you must install the Bluetooth Software, which will install

everything your system needs to use the Adapter. Once the Bluetooth Software is installed, you will be able to

connect the Adapter to your PC.

1. Insert the Adapter’s Setup Wizard CD into your PC’s CD-ROM. It should start up automatically. If it does not,

click Start and choose Run. In the field that appears, enter D:\setup.exe (if “D” is the letter of your CD-ROM

drive). Once the CD starts, the Wizard’s Welcome screen should appear.

Click the Install button to install the Bluetooth Software. Clicking the User Guide button brought up this User

Guide. Clicking the Exit button will exit the Setup Wizard.

2. After clicking the Install button, the InstallShield Wizard’s Welcome screen will appear. Click the Next button

to continue.

IMPORTANT:

You must install the Bluetooth

Software from the CD included with the Adapter

before connecting the Adapter to your PC.

Figure 2-1: The Setup Wizard’s Welcome Screen

Figure 2-2: The InstallShield Wizard’s Welcome Screen

Chapter 2: Installing the Bluetooth Software and Connecting the Adapter

Installing the Bluetooth Software

Bluetooth USB Adapter

3. The next screen is the License Agreement screen. Read the License Agreement and click the radio button for

I accept the terms in the license agreement. Then, click the Next button. You may not click the Next

button unless you click the button showing that you accept the terms.

If you wish to move back through the Wizard, click the Back button. If you wish to close the Wizard, click

Cancel.

4. You will next be asked for a Destination folder. This is where the Bluetooth Software will be installed. A

default directory will be displayed but, if you wish to change that, you can click the Change button and select

a different folder. Then, click the Next button.

If you wish to move back through the Wizard, click the Back button. If you wish to close the Wizard, click

Cancel.

5. Now, the Bluetooth Software will be ready to begin installing all of the necessary files. Click the Install button

to begin.

If you wish to move back through the Wizard, click the Back button. If you wish to close the Wizard, click

Cancel.

The files will proceed to install.

Figure 2-3: The License Agreement Screen

Figure 2-4: The Destination Folder Screen

Figure 2-5: The Install Screen

Chapter 2: Installing the Bluetooth Software and Connecting the Adapter

Installing the Bluetooth Software

Bluetooth USB Adapter

6. During installation, you may see a Driver Signature Notice. This product has been tested for use with

Windows. Click the OK button to continue.

7. At this point, you should connect the Adapter to your PC’s USB port. (See the description on the next page for

details.) After connecting it, click the OK button. If you do now wish to connect it at this time, click the Cancel

button. The Adapter may be connected after the Bluetooth Software is installed.

8. The Wizard, along with all you need to install the Adapter, has been successfully installed. Click the Finish

button to close the final window.

9. If requested by Windows, restart your PC at this time.

Figure 2-6: The Driver Signature Notice

Figure 2-7: The Adapter’s Connection Screen

Figure 2-8: The Wizard Completed Screen

Chapter 2: Installing the Bluetooth Software and Connecting the Adapter

Connecting the Adapter

Bluetooth USB Adapter

Connecting the Adapter

After a moment, Windows will automatically detect the Adapter and a Bluetooth icon will appear in your system

tray.

To connect the Adapter to your PC, simply plug it into any unused USB port.

Figure 2-9: The Bluetooth Icon

Figure 2-10: Connecting the Adapter

NOTE: Before you can start using the Adapter, you must run the Bluetooth

Setup Wizard by right-clicking the Bluetooth icon and selecting the Wizard,

as described in Chapter 3: Using the Bluetooth USB Adapter.
