Model No.

Product Data

WIRED

AG241 (EU/UK)

The All-In-One Solution for Internet

Connectivity in Your Home

High-speed ADSL

Modem gives you a

fast, “Always On”

connection to the

Internet

Compatible with

both ADSL1 or ADSL2

standards

Connect your PCs via the built-

in Router and 4-port Switch to

jump start your Ethernet network

and share the Internet

throughout your household

Advanced firewall

and security

features protect

your PCs, your data,

and your family

The Linksys ADSL2 Gateway with 4-Port Switch is the all-in-one

solution for Internet connectivity in your home.

The built-in ADSL Modem function gives you a blazing fast

connection to the Internet, far faster than a dial-up, and

without tying up your phone line. Connect multiple

computers to the Gateway via the built-in 4-port 10/100

Ethernet Switch to jump start your home network. You can

share files, printers, hard drive space and other resources, or

play head-to-head PC games. Attach four PCs directly, or

connect more hubs and switches to create as big a

network as you need. The Gateway's Router function lets

your whole network share a single high-speed

Internet connection.

The ADSL2 Gateway protects your PCs from most known

Internet attacks with a powerful Stateful Packet Inspection

firewall. It can also serve as a DHCP Server, and supports up

to five VPN tunnel endpoints, so you can securely connect

to corporate networks. Safeguard your family with Parental

Control features like Internet Access Time Limits and Key

Word Blocking. And even with all this power, set up is a snap

with the web browser-based configuration utility.

With the Linksys ADSL2 Gateway with 4-Port switch at the

heart of your home network, you're connected to the future.

ADSL2 Gateway

with 4-Port Switch

Product Data

Model No.

Features

• Enhanced security

management functions: Port

Filtering, MAC and IP Address

Filtering, DMZ Hosting, and

NAT Technology

• Easily configurable through

your networked PC’s Web

browser

• Supports 4 10/100 Auto MDI-X

LAN switch ports and 1 ADSL

port

• Support for RFC1483, PPPoE

and PPPoA connections

• SPI firewall with Denial of

Service attack prevention

• Email and Web-based

Logging of Security Events

• Supports 5 VPN Tunnels for

IPSec and VPN Passthrough

for IPSec, PPTP, and L2TP

Protocols

• 2 years manufacturer

warranty

Linksys

Web: http://www.linksys.com/international

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete list

of local Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site at

www.linksys.com/international.

AG241 (EU/UK)

with 4-Port Switch

ADSL2 Gateway

Specifications

Model AG241

Standards IEEE 802.3u, IEEE 802.3, ITU G.992.1 (g.dmt),

ITU G.992.2 (g.lite), ITU G.992.3, ITU G.992.5,

ANSI T1.413i2

Ports Power, Line, Ethernet (1-4)

Buttons Reset, Power Switch

Cabling Type CAT 5 UTP (Ethernet), Standard Telephone (ADSL)

LEDs Power, Ethernet (1-4), DSL, Internet

UPnP able/cert Able

Security Features Stateful Packet Inspection (SPI) Firewall

Environmental

Dimensions 186 mm x 48 mm x 154 mm

(W x H x D ) (7,32" x 1,89" x 6,06")

Unit Weight 0,395 kg (13.93 oz.)

Power 12VDC 1A

Certifications FCC Part 15 Class B, FCC Part 68, UL 1950, CE,

CS03

Operating Temp. 32º~104º F (0º~40º C)

Storage Temp. -4º~158º F (-20º~70º C)

Operating Humidity 10~85% Non-condensing

Storage Humidity 5~90% Non-condensing

AG241-EU-UK-DS-41112NC JL

Package Contents

•ADSL2Gateway

• Power Adapter

•UserGuideonCD-ROM

• Network Cable (RJ45)

• Phone Cable (RJ11)

•QuickInstallation

Minimum Requirements

• PC with a Network Adapter and the TCP/IP

Protocol installed

• 64 MB of RAM

• CD-ROM Drive

• Internet Explorer 5.0 or Netscape Navigator 6

or Higher for Web-based Configuration

• Activated ADSL line

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or itsaffiliates in the U.S. and certain other countries. Copyright © 2004
