Linksys EFG20 Manuale utente

Instant EtherFast®Series

User Guide

EtherFast 10/100

Instant GigaDrive

Model No.: EFG20

Instant GigaDrive UserGuide.indd 10/6/99, 8:46 AM1

Linksys. Microsoft, Windows, and the Windows logo are registered trademarks of

Microsoft Corporation. All other trademarks and brand names are the property of their

respective proprietors.

LIMITED WARRANTY

Linksys guarantees that every EtherFast 10/100 Instant GigaDrive is free from physical

defects in material and workmanship under normal use for two (2) years from the date

of purchase. If the product proves defective during this two year warranty period, call

Linksys Customer Support in order to obtain a Return Authorization number. Warranty

is for repair or replacement only. Linksys does not issue any refunds. BE SURE TO

HAVE YOUR PROOF OF PURCHASE AND BAR CODE ON HAND WHEN CALLING.

RETURN REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF PURCHASE

AND BAR CODE. When returning a product, mark the Return Authorization number

clearly on the outside of the package and include your original proof of purchase and

bar code.

IN NO EVENT SHALL LINKSYS’LIABILITY EXCEED THE PRICE PAID FOR

THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR

CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, ITS

ACCOMPANYING SOFTWARE, OR ITS DOCUMENTATION.

Linksys makes no warranty or representation, expressed, implied, or statutory, with

respect to its products or the contents or use of this documentation and all accompany-

ing software, and specifically disclaims its quality, performance, merchantability, or

fitness for any particular purpose. Linksys reserves the right to revise or update its

products, software, or documentation without obligation to notify any individual or entity.

Please direct all inquiries to:

Linksys P.O. Box18558, Irvine, CA 92623.

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used according to the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio or television reception, which

is found by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna

•Increase the separation between the equipment or device

•Connect the equipment to an outlet other than the receiver’s

•Consult a dealer or an experienced radio/TVtechnician for assistance

Instant GigaDrive User Guide.indd 10/6/99, 8:46AM3

Linksys highly recommends that you regularly backup the ﬁles

on your InstantGigaDrive. In noinstance will Linksys preform

data recovery for lostdata or ﬁles.

Table of Contents

Introduction 1

Disclaimer 2

Getting Familiarwith the Instant GigaDrive 3

Basic Installation &Setup6

Connecting everything together and booting up 6

Conﬁguring yourInstant GigaDrive8

QuickSetup with theInstant GigaDriveUtility 9

Administration 13

Overview13

Theweb-based administrativeinterface 13

Theadministrativemenu —conﬁguration 15

Theadministrativemenu —storagemanagement 17

Managing shares,groupsand users 18

Nested shares 19

Common administrativetasks21

Windows Client Setup23

Introduction 23

TCP/IPsetup 23

Using theInstant GigaDrive’sprinter 28

Troubleshooting29

Appendix31

Speciﬁcations31

Buzzer 32

Customer support 33

Instant GigaDrive User Guide.indd 10/6/99, 8:46 AM4

Introduction

The Linksys EtherFast10/100 Instant GigaDrive

Congratulations on the purchase of a Linksys EtherFast 10/100 Instant Giga-

Drive. The Instant GigaDrive inserts twenty Gigabytes of storage space into

your network without the cost, space, and maintenance hassles of a full-ﬂedged

ﬁle server. The Instant GigaDrive provides solid data transfer performance for

multiple client connections. It is also equipped with a built-in PrintServer for

the quick and inexpensive addition of a network printer. And you can add as

many Instant GigaDrives to your network as you like.

The EtherFast 10/100 Instant GigaDrive automatically toggles between

10Mbps and 100Mbps speeds. Its comprehensive utility software—conve-

niently accessed from your web browser—offers a wide array of management

options. The Instant GigaDrive can also function as a stand-alone DHCP

(Dynamic Host Conﬁguration Protocol) server for easy installation.

The EtherFast 10/100 Instant GigaDrive can do just about anything a standard

PC can do on a network, but at a fraction of the size, a fraction of the hassle,

and a fraction of the cost.

Features

•Provides 20 instant Gigabytes of external hard disk space.

•Built-in printer server gives your network one extra location to attach a

fully shareable printer.

•Seamlessly and automatically adjusts to either 10Mbps or 100Mbps Ether-

net speed.

•WEB-based conﬁguration and diagnostic interface is accessible from any

PC on the network.

•Can act as a stand-alone DHCP server.

•Divert trafﬁc from your primary server to increase network productivity.

•Provided with a utility program for speedy conﬁguration.

•A built-in single-board 32bit Pentium-grade CPU.

•Automatically maintains itself to provide ﬁle system integrity.

•The LANAdministrator can limit the amount of available disk space.

•To reduce management efforts, access to shared data can be set by groups,

not individual users.

•Small footprint minimizes space usage.

•Additional Instant GigaDrives can be added to the network at any time.

Instant GigaDrive User Guide.indd 10/6/99, 8:46 AM1

Package Contents

The following items should be included in the Instant GigaDrive packaging.

If any of these items are damaged or missing, please contact your Linksys

dealer for replacements.

• One Linksys EtherFast 10/100 Instant GigaDrive.

• One AC power adapter and power cord.

• One LAN cable with RJ45 connectors.

• One CD-ROM, containing this User Guide and the Instant GigaDrive

program for Windows 95, 98, and NT 4.0.

• Printed User Manual.

SystemRequirements

• Windows 95, Windows 98, Windows NT 4.0, or later.

• Ethernet Network employing 10BaseT or 100BaseTX.

• TCP/IP protocol.

Disclaimer

Linksys highly recommends that you regularly backup the ﬁles

on your Instant GigaDrive. In no instance will Linksys perform

data recovery for lost data or ﬁles.

Instant GigaDrive User Guide.indd 10/6/99, 8:46 AM2

Getting Familiar with the

Instant GigaDrive

Rear Panel

All of the GigaDrive’s connections and switches are on the rear panel, as seen

below.

Power Switch The power switch is a spring-loaded soft switch

which powers on and powers off the GigaDrive.

If the GigaDrive is not powered on, pressing

the power switch will initiate the GigaDrive’s

start-up process. Pressing the power switch

while the GigaDrive is turned on will begin the

GigaDrive’s internal shut-down process. The

Instant GigaDrive must be powered-down this

way, or through its internal shutdown process.

Power InputThe power input port is where the adapter plugs

in.

Printer Port Youcan add a printer to your networkthrough

the Instant GigaDrive’s printer port.

Instant GigaDrive User Guide.indd 10/6/99, 8:46 AM3

Reset Button If the Instant GigaDrive’s IP Address or pass-

word is lost, press and release this button. The

GigaDrive will beep once to indicate that a new

IP Address (192.168.0.2, with a Network Mask

of 255.255.255.0) has

been provided. This

function will also

clear the GigaDrive’s

passwords and rights.

UplinkButton This button toggles the

GigaDrive’s Ethernet

Connector between an Uplink setting and a

standard setting. If the GigaDrive is connected

directlyto a PCwithout a hub, then this button

should be up. If connecting to a hub or switch,

depress this button.

10/100BaseTX connectorUse this port to connect the Instant GigaDrive

to your 10BaseT or 100BaseTXhub.

100BaseTX LED indicatorThis LED will glow amber if the

10/100BaseTXconnector is using 100BaseTX.

10BaseTLED indicatorThis LED will glow green if the 10/100BaseTX

connector is using 10BaseT.

Front Panel

The Instant GigaDrive’s front panel (shown below) displays the majorityof

the drive’s status lights.

Note: The Reset

Button should only be

used as a last resort.

Pressing this button

will reset the adminis-

trator password.

Instant GigaDrive User Guide.indd 10/6/99, 8:46 AM4

System Green. Normally on.

If this light shines asteady green, then the Instant

GigaDrive is working properly. It blinks during

Startup or Shutdown, and turns off after the shut-

down is completed. It will blink during asoftware

upgrade.

StatusRed. Normally off.

If this light is turned on, then there is ahardware

error. It will also be on during the power-on self

test. Once the self-test is completed, it should turn

off. It will blink during asoftware upgrade.

HD Green

Flashes when the GigaDrive’shard drive is being

accessed. Stays on during the self-test.

LAN Green

Flashes when data is transmitted or received via the

network.

IP Amber

If this light it turned on, the GigaDrive is acting

as aDHCP client and receiving an IPaddress from

aDHCP server on the network. If this LEDis

ﬂashing, no DHCP server responded to the client

request.

HD UsageThis series of LEDs runs from green to red, signify-

ing how much of the GigaDrive’shard drive is full.

Instant GigaDrive User Guide.indd 10/6/99, 8:47 AM5

Basic Installation

& Setup

The following section instructs you on how to physi-

cally connect the Instant GigaDrive to the network,

and how to conﬁgure the Instant GigaDrive for basic

operation in your Windows environment. Everything

you need to do to get your Instant GigaDrive up and

running is covered here.

This section also covers the hook-up of a printer on the GigaDrive’s printer

server port. Please note, however, that the GigaDrive will perform equally well

as a storage device with or without an attached printer. If you aren’t interested

in taking advantage of the Instant GigaDrive’s printer server function, skip any

steps that deal with printer installation. The GigaDrive’s installation process

will work ﬁne without them.

ConnectingEverythingTogetherandBootingUp

Requirements

The following conditions are required to begin the installation of the Instant

GigaDrive to your system.

•TCP/IP protocol.

•If connecting to a network, an available port on a hub or switch.

•If connecting to a PC, an installed and available Ethernet or Fast Ethernet

port.

Hardware Installation

If the above conditions are met, follow the steps below to begin the installation

of your Instant GigaDrive.

1. Connect the network cable to the Instant GigaDrive. Locate the RJ45

network cable that came packaged with your Instant GigaDrive. Plug it into

the RJ45 socket on the GigaDrive’s rear panel.

Note: If you are a

network administrator,

please follow these

Basic Installation &

Setup steps, then con-

tinue on to the Admin-

istration section which

follows. There you will

ﬁnd the full available

range of administrator

options.

Instant GigaDrive User Guide.indd 10/6/99, 8:47 AM6

2. Connect the Instant GigaDrive to your hub, switch, or PC. If you plan to

connect the GigaDrive to the network through ahub or switch, be sure that

the uplink button on the rear panel of the GigaDrive is depressed, then plug

the other end of the RJ45 cable into one of the ports on your hub or switch.

If you want to connect the GigaDrive directly to aPC, make sure that the

uplink button is in the up position, and connect the RJ45 cable directly into

the PC’s network card.

3. Connect a printer to the Instant GigaDrive. Connect astandard printer

cable to the GigaDrive’s rear-panel printer port. Connect the other end of

the cable to your printer.

4. Connect the power supply. Plug the supplied power adapter into the

GigaDrive’s power input port, located on the GigaDrive’s rear panel. Con-

nect the other end of the power adapter to apower outlet.

5. Power on. Locate the GigaDrive’s power switch on the upper left of the

GigaDrive’s rear panel. Press it once to power on the GigaDrive.

6. The GigaDrive’s self-test. Now that its power is on, the GigaDrive’s boot

process will begin. The GigaDrive will run abrief self-test (2 or 3seconds)

prior to actually booting up. During the self-test, all of the GigaDrive’s

LEDs will be illuminated or ﬂashing.

7. Booting up.When the self-test is complete, most of the LEDs will turn

off. The System LEDwill blink continuously, and the LANLEDwill blink

occassionally. This signiﬁes that the GigaDrive is in the actual process

of booting up. Boot up should take approximately 1-3minutes. It will

take longer on the ﬁrst bootup, and on any bootup following an improper

shutdown.

8. Boot upcompleted. When most of the LEDs turn off, leaving only the

System LEDilluminated (and not blinking),the GigaDrive’s boot up is

complete. If the Status LEDstays on, or if the GigaDrive repeatedly beeps,

there is ahardware problem. Consult this user guide’s Troubleshooting

section (page 29)or Appendixentry on the GigaDrive’s buzzer (page 32)

for possible solutions.

Instant GigaDrive User Guide.indd 10/6/99, 8:47 AM7

Altri manuali per EFG20

Altri manuali Linksys Hardware di rete

Linksys

Linksys SVR3000 - One Services Router Manuale utente

Linksys

Linksys EFG80 - EtherFast Instant GigaDrive NAS... Manuale utente

Linksys

Linksys EFG120 - EtherFast Network Attached Storage NAS... Manuale utente

Linksys

Linksys VELOP AX5300 Manuale utente

Linksys

Linksys WMB54G - Wireless-G Music Bridge Network Audio... Manuale utente

Linksys

Linksys EFG120 - EtherFast Network Attached Storage NAS... Manuale utente

Linksys

Linksys EFG80 - EtherFast Instant GigaDrive NAS... Istruzioni operative originali

Linksys

Linksys EFG40 Manuale utente

Linksys

Linksys EFG120 - EtherFast Network Attached Storage NAS... Manuale utente

Linksys

Linksys EFPC2SC Manuale utente

Linksys

Linksys LKG0F755E Manuale utente

Linksys

Linksys WET11 - Instant Wireless EN Bridge Network... Manuale utente

Linksys

Linksys WBP54G Istruzioni operative originali

Linksys

Linksys HPES03 Manuale utente

Linksys

Linksys MX4300 Manuale utente

Linksys

Linksys WET54G V3 Istruzioni operative originali

Linksys

Linksys EF31SC Manuale utente

Linksys

Linksys VGA2100 - One Analog Voice Gateway 3 Line Manuale di istruzioni

Linksys

Linksys VELOP MX5500 Series Manuale utente

Linksys

Linksys BEFN2PE Istruzioni operative originali

Linksys

Linksys EFG80 - EtherFast Instant GigaDrive NAS... Manuale utente

Linksys

Linksys MX5300 Manuale utente

Linksys

Linksys WET54G - Wireless-G EN Bridge Istruzioni operative originali

Linksys

Linksys WMB54G - Wireless-G Music Bridge Network Audio... Manuale utente

Manuali Hardware di rete popolari di altre marche

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuale utente

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuale utente

Yudor

Yudor YDS-16 Manuale utente

D-Link

D-Link ShareCenter DNS-320L Manuale utente

Samsung

Samsung ES1642dc Istruzioni per l’uso

Honeywell Home

Honeywell Home LTEM-PV Istruzioni per il montaggio

evertz

evertz 7700 Series Manuale utente

D-Link

D-Link ShareCenter DNS-343 Manuale utente

Asante

Asante AsanteBridge 1012 Manuale utente

FireBrick

FireBrick FB2700 Manuale utente

Audiovox Electronics

Audiovox Electronics ARWH2T Manuale utente

ADC

ADC DSX-1 Manuale

NetComm

NetComm NF2 Manuale utente

Alcatel-Lucent

Alcatel-Lucent 5620 Manuale utente

Dell EMC

Dell EMC XC6420 Series Manuale utente

Lanner

Lanner NCA-1020A Manuale utente

Allied Telesis

Allied Telesis AT-TN121-A Manuale utente

Arista

Arista CCA-ETM-Q12 Manuale utente
