PRODUCT DATA

BUSINESS SERIES

4-Port SSL/IPSec VPN Router

Model: RVL200

Flexible and secure remote

connectivity for growing business

Protection of your network is a mission critical activity. At Linksys, we build

powerful security into every product, to keep your wired and wireless networks

safe. Linksys Small Business Series systems have advanced ﬁrewall, encryption,

and authentication features to protect you from network threats – threats that

can seriously disrupt or damage your business by stealing your valuable data,

slowing down your network and interfering with business-critical applications.

Our systems ensure maximum application availability that lets you meet

corporate governance and business continuance requirements.The Linksys Small

Business Series is the affordable, reliable, high quality networking solution that

helps you do business smarter. Secure and easy to install and maintain, it’s built to

grow with your business.

The RVL200 features a Virtual Private Network (VPN) security engine that creates

encrypted“SSL tunnels”through the Internet. The SSL VPN tunnels enable remote

users from at home, or on the road to easily, and securely connect to the ofﬁce

network through a typical wired or wireless broadband connection. When used with

the RV016 or other Linksys VPN router, an IPSec Gateway-to-Gateway connection can

be established allowing users in a remote ofﬁce to connect to the corporate network.

The RVL200 features a built-in 4-port full-duplex 10/100 Ethernet switch to connect

four PCs directly, or additional switches. As an essential element of your business, this

product provides security functions for authentication and encryption. Linksys’ proven

SPI Firewall is integrated into the gateway providing security from outside threats. The

QoS features provide consistent voice and video quality throughout your business.

SSL VPN gives users

ﬂexible access to your

network from anywhere

Integrated Stateful

Packet Inspection (SPI)

Firewall makes your

network secure

Web-based interface

gives simpliﬁed

conﬁguration while

SNMP provide

additional management

QoS provides quality

voice/video quality

RVL200

PRODUCT DATA

BUSINESS SERIES

Features

Supports 5 SSL tunnels for

remote user connectivity

and 1 IPSec Gateway-to-

Gateway tunnel

Stateful Packet Inspection

Firewall for maximum

security

4-Port 10/100 Switch

supports Auto-MDI/MDIX

and up to 200Mbps of

throughput per port

IP ﬁltering allows for

restricted access to the

Internet and other network

resources

Management via Web,

SNMP, and Setup Wizards

make setup easy for

Administrators

•

4-Port SSL/IPSec VPN Router

Speciﬁcations

Model RVL200

Standards IEEE802.3, IEEE802.3u, IEEE802.1q, IEEE802.1p, RFC791 (IP Protocol)

Ports Ethernet and Power

Buttons Reset

Cabling Type UTP CAT 5

LEDs Power, Diag, Internet, LAN 1-4

Operating System Linux

Performance

NAT Throughput Wirespeed - 100 Mb/s

SSL Throughput 16.99 Mb/s

Setup/Conﬁg

WebUI Built in Web UI for Easy browser-based conﬁguration (HTTP/HTTPS)

Management

SNMP Version SNMP Version 1, 2c

Event Logging Event Logging: Local, Syslog, Email

Web F/W upgrade Firmware Upgradable Through Web-Browser

Diags: Flash, etc. Diags: Flash, RAM

Security

Encryption DES, 3DES, AES

Access Control Access Rules based on IP and TCP/UDP Ports

Firewall SPI stateful packet inspection ﬁrewall

Content Filtering URL blocking, keyword blocking

DOS Denial-of-Service (DoS) prevention (Ping of Death, SYN Flood, IP Spooﬁng)

Secure Management HTTPS, Username/Password

QoS

Layer 2 prioritization based on DSCP, CoS (802.1p), or physical ports)

Bandwidth Management of WAN (upstream and downstream) based on

Services (TCP/UDP ports)

Network

VLAN Support 4 LAN ports can be mapped to up to 16 VLANs

802.1q VLAN tagging

DHCP DHCP Server, DHCP Client

DNS Relay, Proxy, Dynamic DNS

NAT PAT, NAPT, ALG support, NAT Traversal

DMZ Software conﬁgurable on any LAN port

VPN 5 SSL Tunnels for remote client access (requiring ActiveX-enabled

browsers, e.g. IE and Netscape)

1 IPSec Gateway-to-Gateway Tunnel for branch ofﬁce connectivity

DES/3DES/AES Encryption

MD5/SHA1 Authentication

IPSec NAT-T

VPN Passthrough of PPTP, L2TP, IPSec

Routing

Static and RIP v1,v2

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Ofﬁces throughout

the world.For a complete list of local

Linksys Sales and Technical Support

contacts, visit our Worldwide Web Site

at www.linksys.com.

Check the product package and contents for speciﬁc features supported.Speciﬁcations are subject to change without notice. Linksys is a registered trademark or

product names are trademarks or registered trademarks of their respective holders.

Model: RVL200

Environmental

Dimensions 6.69” x 1.67” x 6.69”

W x H x D (170 mm x 42.5 mm x 170 mm)

Unit Weight 0.86 lbs (0.39 kg)

Power 5V 2A

Certiﬁcation FCC class B, CE, ICES-003

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing

Package Contents

RVL200 SSL/IPSec VPN Router

User Guide on CD-ROM

Network Cable

Power Adapter

Stands

Registration Card

Quick Install Guide

Minimum Requirements

Internet Explorer 6.0 or higher, or Netscape Communicator 8.0 or higher for using the SSL VPN

Network Adapter with Ethernet Network Cable and TCP/IP Protocol installed per PC

Web-based conﬁguration via Java/SSL-enabled Web browser

•

RVL200-DS-60616-SW
