Linksys WDT11 Manuale utente

Instant Wireless™

PCIAdapter

Whether you’re at your desk or in the boardroom,

the Linksys InstantWireless PCI Adapter (with the

Linksys Instant Wireless Network PC Card inserted)

allowsyou toshare printers,files,andmore withinyour

wireless LAN infrastructure, increasing your productiv-

ity and keeping you on the network.

The Instant Wireless PCI Adapter gives you the free-

dom to work your way, from wherever you want.

Just plug the Wireless Network PC Card into the

Wireless PCI Adapter and take full advantage of a wire-

less network. A high-powered built-in Diversity anten-

na means that you’re covered at distances of up to 500

meters.

Ready to run in any PCI-equipped desktop PC and

compatible with virtually all major operating sys-

tems, the Instant Wireless PCI Adapter from Linksys is

truly a “must-have” for all PC users.

When Combined with the Linksys Network PCCard:

• 11 Mbps High-Speed Transfer Rate

• Compatible with Windows 95, 98, 2000, NT

and Millennium

• Plug-and-Play Operation Provides Easy Setup

• Works with All Standard Internet Applications

• Utilizes Intersil HFA3841/HFA3842 Chipsets

• Interoperable with IEEE 802.11b (DSSS)

2.4GHz-Compliant Equipment

• Capable of up to 128-Bit WEP Encryption

• Free Software Driver Upgrades

• Free Technical Support—24 Hours a Day,

7 Days a Week for NorthAmerica Only

• 1-Year Limited Warranty

IInnssttaannttWWiirreelleessss™™PPCCIIAAddaapptteerr

((WWDDTT1111))

When Combined With the Instant Wireless

Network PC Card (WPC11), the Wireless PCI

Adapter Provides:

• Fully Compatibility with IEEE 802.11b Standard

• Supports a High Data Rate Up to 11 Mbps

• Assurance of Constant Connection Via Direct

Sequence Spread Spectrum (DSSS)

• Compatible with Virtually All PCI-Equipped

Desktop PCs

• Free Technical Support—24 Hours a Day,7 Days

a Week for North America Only

• 1-Year Limited Warranty

The Freedom to Work WhereYou Want,

The Flexibility to Work How You Want.

Features

Benefits

NNeettwwoorrkkYYoouurr

WWiirreelleessssPPCC

Instant Wireless™

PCI Adapter

• One Instant Wireless PCI Adapter

• One User Guide and Registration Card

DS-WDT11-10103A DG

• Pentium 90 or Faster

• Minimum 16MB of RAM

• PCI Local Bus 2.1 Compliance

• Windows 95, 98, NT, 2000 or Millennium

(for Instant Wireless PC Card)

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Information (800) 546-5797

Technical Support (800) 326-7114

(949) 261-1288

Fax (949) 261-8868

World Wide Web http://www.linksys.com

Email [email protected]

[email protected]

China

Tech Support (10) 6432 1920

Sales (10) 6432 1923

Fax (10) 6437 6891

Japan

Telephone (03) 5259-5139

Fax (03) 5259-5117

Philippines

Telephone (632) 638 5580

Fax (632) 635 6772

Singapore

Telephone 552-8998

Fax 552-1024

Thailand

Telephone 717-0770

Fax 717-0738

United Kingdom

Tech Support 0870 7393939

Sales 01245 352403

Fax 0870 7393938

Package Contents

System Requirements

Specifications

Model Number: WDT11

Standards: PC97/98/99 Support,

PCI Local Bus 2.1 Compliance,

PC Card-16 bit Standard Specification

Channels*: 11 Channels (US, Canada)

13 Channels (Europe)

14 Channels (Japan)

Operating Range*: Indoors: 30M (100 ft.) @ 11 Mbps

50M (165 ft.) @ 5.5 Mbps

70M (230 ft.) @ 2 Mbps

91M (300 ft.) @ 1 Mbps

Outdoors: 152M (500 ft.) @ 11 Mbps

270M (885 ft.) @ 5.5 Mbps

396M (1300 ft.) @ 2 Mbps

457M (1500 ft.) @ 1 Mbps

Card Type: 32-bit PCI

Environmental

Dimensions: 6”x 4.75”x 0.75” (152mm x 121mm x 19mm)

Unit Weight: 3 oz. (0.09 Kg)

Power: 5V DC

Certifications: FCC Class B, CE Mark Commercial

Operating Temp.: 32ºF to 131ºF (0ºC to 55ºC)

Storage Temp.: -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity: 0% to 70% Non-Condensing

Storage Humidity: 0% to 95% Non-Condensing

* Requires the Linksys Instant Wireless Network PC Card

(Model Number WPC11)
