Linksys Instant EtherFast EPSX3 Manuale utente

EtherFast® 10/100

PrintServers

The EtherFast 10/100 PrintServer is the easiest and

fastest way to add up to three printers to your net-

work. Because it is equipped with up to three high-

speed printer ports, the 10/100 PrintServer allows any

PC on the network to print to any combination of laser,

color,bubble jet,ink jet,and even dot matrix printers—

including the latest generation of bi-directional and bi-

tronic printers from HP, Lexmark, and others. The

EtherFast 10/100 PrintServer is the ideal choice for

both large corporations and small workgroups with

printer sharing needs. Plus, it attaches directly to your

network’s cabling, so no dedicated print server PC is

required. Each 3-Port or 1-Port PrintServer comes with

a full suite of management utilities and support for

multiple network protocols. Adding a PrintServer to

your 10/100 LAN will save money and increase your

network’s efficiency.

• Attach Up to Three Printers Directly to Your

Network Using Standard Ethernet Cabling

• Supports Multiple Operating Systems and

Protocols

• Configurable through Your Network PC’s Web

Browser

• Bi-Directional, DMA-Equipped Parallel Printer

Port(s) for Maximum Printer Efficiency

• 512 KB Flash ROM Memory

• Free Software Upgrades

EtherFast®10/100 3-Port PrintServer

Model No.: EPSX3 ver. 2

EtherFast®10/100 1-Port PrintServer

Model No.: PPSX1 ver. 2

• Stand-Alone Print Server—No Dedicated

PC Required

• Share Up to Three Printers on Your

Network

• Works with Virtually All Laser, Ink Jet,

Bubble Jet, Color, and Dot Matrix Printers

• Integrates Seamlessly with Your Ethernet

Network

• Free Technical Support—24 Hours a Day,

7 Days a Week, Toll-Free US Calls

• 3-Year Limited Warranty

Connect Up to Three Parallel or Bi-Directional

Printers to Your 10/100 Network

Features

Benefits

PPrriinntteerr--SShhaarriinngg

MMaaddeeEEaassyy

EtherFast 10/100 3-Port PrintServer

• One EtherFast 10/100 3-Port

PrintServer

• One Setup Utility CD-ROM

• One AC Power Adapter

• One User Guide

• One Registration Card

EtherFast 10/100 1-Port PrintServer

• One EtherFast 10/100 1-Port

PrintServer

• One Setup Utility CD-ROM

• One AC Power Adapter

• One User Guide

• One Registration Card

DS-EPSX3ver2PPSX1ver2-032702A JL

Package Contents

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

Japan (03) 5259-5137

Philippines (632) 638-5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 0870 7393939

*Visit our website for the most current contact information.

Specifications

Model Number EPSX3 ver. 2

PPSX1 ver. 2

Standards IEEE 802.3, IEEE 802.3u

Protocol CSMA/CD

Topology Star

Ports EPSX3 ver. 2: Two DMA-Equipped Bi-Directional Printer Ports,

One Parallel Printer Port,

OneAuto-Sensing RJ-45 10/100 Port

PPSX1 ver. 2: One DMA-Equipped Bi-Directional Printer Port,

OneAuto-Sensing RJ-45 10/100 Port

Speed Half Duplex: 10Mbps or 100Mbps

Full Duplex: 20Mbps or 200Mbps

LEDs EPSX3 ver. 2: Error,Status (per Printer)

Power,Link (LAN)

PPSX1 ver. 2: LAN,Act,Error,Power

Environmental

Dimensions EPSX3 ver. 2: 7.32" x 6.06" x 2.52"

LxWxH (186 mm x 154 mm x 64 mm)

PPSX1 ver. 2: 4.76" x 3.74" x 1.18"

(121 mm x 95 mm x 30 mm)

Unit Weight EPSX3 ver. 2: 15.2 oz. (0.43 kg)

PPSX1 ver. 2: 5.6 oz. (0.16 kg)

Power 12V DC,800 mA

Certifications FCC Class A, CE Mark, UL Listed

Operating Temp. 32ºF to 104F (0ºC to 40ºC)

Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing
