Linksys E9450 Manuale utente

Linksys E9450

WiFi 6 Dual-Band router

Training

&

Installation

CONFIDENTIAL: ALL MATERIALS APPEARING IN THIS PRESENTATION MAY NOT BE RELEASED OR REPRODUCED WITHOUT PRIOR EMAIL PERMISSION FROM ASUS DESIGN CENTER.

•Product Features

•Physical Set Up

•Setting up via Linksys GUI (Recommended)

•Set up mode for ONT (Singtel Profile) as RG

•Set up mode for ONR (Bridge Mode) as Bridge

•Set up mode for ONR with Bridge Mode (Manual)

•Manual Set up

•Adding additional nodes of E9450 (Mesh Parent mode)

•Adding additional nodes of E9450 (Mesh mode)

•Set as standalone mode (Non-mesh system)

•Parental Controls

•Factory Reset Router

•Management Tab (Access Control > Passwords)

•Router Light Behaviour

Overview

For support:

https://www.linksys.com/sg/support-article?articleNum=317469#wireless2

https://www.linksys.com/sg/support-product?pid=01t2T000004rSMRQA2

Product Features

•Dual-Band AX5400 at up to 5.4 Gbps

•802.11ax Wireless Technology

•1.5 GHz Tri-Core processor

•2x2 + 4x4 Spatial streams (6 streams)

•MU-MIMO technology

•Wi-Fi coverage of up to 2,500 sq ft

•Supports parent and child node

•Four gigabit ethernet ports and one gigabit internet port

•Parental Controls

•Wi-Fi Protected Setup™ (WPS)

•WPA2™ wireless security and WPA3 wireless security

•Buttons and Switch

•Wi-Fi Protected Setup (WPS) button

•Power switch

•Reset button

•Ports

•Power port

•Four gigabit ethernet ports

•One gigabit internet port

•One USB 3.0 port (for future use)

•Power

•Output: 12v, 2A

Physical Set Up (Without STB)

To ONT/ONR

To PC

•Recommended to connect RG’s Ethernet port to PC

via LAN cable (wired).

•Else setup wireless using default routers name,

“LinksysXXXXX-guest” with the passphrase printed on

the sticker label is required.

•Without STB, connect FTP to either ONR/ONT then to

Linksys.

Physical Set Up (With STB)

To ONT/ONR

To PC

To ONT/ONR

To PC

ONR ONT

Set up via Linksys GUI (Recommended)

Set up via Linksys GUI (Recommended)

1. Launch a web browser and enter Router’s GUI http://192.168.79.1

2. Enter default Username and Password

•Username: admin

•Password: admin

3. ‘Apply’

4. Set up E9450, Click ‘Next’

Set up via Linksys GUI (Recommended)

5. Create new router Password

•Include at least 10 characters in length.

•Include at least 1 uppercase letter.

•Include at least 1 lowercase letter.

•Include at least 1 number.

•Include at least 1 special character.

6. ‘Next’

Set up via Linksys GUI (Recommended)

7. Follow the Setup Wizard to change the default administration password, set up a parent node (unless

adding a child node to an existing Wi-Fi system), select a transmit region and Name your Wi-Fi.

* Only Linksys E9450 child nodes are supported.

Set up via Linksys GUI (Recommended)

8. Follow the Setup Wizard
