Model No.

Product Data

Wireless

WUSB54GS

The easy way to connect your PC to a

high-speed wireless network.

Now with SpeedBooster Technology!

network performance increases by up to 35%! Unlike other

speed-enhancing technologies, SpeedBooster is 802.11

compliant, fully compatible with standard Wireless-G, and a

“good neighbor” to other wireless devices and technologies,

using a single 2.4GHz channel as specified by the official

wireless standard. And with SpeedBooster you'll see an overall

speed improvement even when running a mixed network of

SpeedBooster and regular Wireless-G devices.

To install, simply plug the Adapter into any available USB port.

(It's compatible with both USB 1.1 and 2.0 ports, but 2.0 will yield

the fastest speeds.) It gets its power through the USB

connection, so no power cord is necessary. The included Setup

Wizard walks you through configuring the Adapter to your

wireless network settings, step by step. The Adapter is also

compatible with the Wireless-B (802.11b) network standard, with

data rates up to 11Mbps. And your wireless communications

can be protected by industrial-strength Wi-Fi Protected Access

(WPA) encryption, so your data stays safe.

The high-gain antenna lets you put your computer almost

anywhere in the building, without the cost and hassle of running

cables. Now you don't have to drill holes in your walls and climb

through the attic or cellar to get connected to the network.

Once you're connected, you can keep in touch with your

e-mail, access the Internet, use instant messaging to chat with

friends, and share files and other resources such as printers and

hard disk storage space with other computers on the network.

So don't hassle with running cables through your house — get

connected to Wireless-B, Wireless-G, and SpeedBooster wireless

networks the easy way with the Wireless-G USB Network Adapter

with SpeedBooster.

USB Network Adapter

Wireless-G

with SpeedBooster

High-speed wireless

networking for your

desktop or notebook via

USB 2.0

Wireless

communications are

protected by WPA

encryption

New SpeedBooster

technology increases

Wireless-G performance

by up to 35%

Easy, no-tools setup on

any desktop or

notebook computer

with USB support

Connect your USB-equipped desktop or notebook computer to

a wireless network at incredible speeds with the Linksys Wireless-

G USB Network Adapter with SpeedBooster. Using your high-

speed USB 2.0 port, the Adapter delivers incredible data rates

without the trouble of opening up the case of your computer.

The Wireless-G USB Network Adapter with SpeedBooster

incorporates the next generation of Wireless-G. In standard

Wireless-G (802.11g) mode, the USB Adapter can connect to

wireless networks at up to an amazing 54Mbps. With our new

SpeedBooster technology enabled, your “real-world” wireless

Model No.

Product Data

Model No.

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete list of

local Linksys Sales and Technical Support contacts,

visit our Worldwide Web Site at www.linksys.com.

WUSB54GS

Package Contents

• Wireless-G USB Network Adapter with

SpeedBooster

•USBCable

• Setup Wizard CD-ROM

• User Guide on CD-ROM

• Quick Installation

• Registration Card

Wireless-G

Minimum Requirements

• PC with 400MHz or Faster Processor

• 128MB RAM Memory

• CD-ROM Drive

• Available USB Port

• Windows 2000 or XP with Service Pack 1

(or later)

Specifications

Model Number WUSB54GS

Standards IEEE 802.11b, 802.11g, USB 1.1, USB 2.0

Ports One USB

Channels 802.11b / 802.11g

11 Channels (US, Canada)

13 Channels (Europe)

14 Channels (Japan)

LEDs Power, Link

Transmitted Power 15-17dBm (Typical)@11Mbps CCK,

15-17dBm (Typical)@54Mbps OFDM

Receive Sensitivity -67dBm@54Mbps, -82dBm@11Mbps

Security features WEP Encryption and WPA Security

Warranty 3 Year

Environmental

Dimensions 3.58" x 0.91" x 2.80"

W x H x D (91 mm x 23 mm x 71 mm)

Unit Weight 0.18 lbs. (0.08 kg)

Certifications FCC, CE, Wi-Fi

Operating Temp. 0ºC to 55ºC (32ºF to 131ºF)

Storage Temp. -40ºC to 85ºC (-40ºF to 185ºF)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing

WUSB54GS_V2-DS-50810NC JL

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc.

respective holders.

USB Network Adapter with SpeedBooster

Features

• Compatible with 802.11g

and 802.11b (2.4GHz)

Standards

• SpeedBooster technology

increases wireless

performance by up to 35%

• Supports USB 2.0 with up to

54Mbps, High-Speed Data

Transfer Rate with Automatic

Fallback

• Plug-and-Play Operation

Provides Easy Setup

• Supports up to 128-bit WEP

Encryption and WPA Security
