Lipper Sirio 2.0 PVC Manuale utente
Sirio 2.0 PVC Blinds
OWNER'S MANUAL
Rev: 07.07.22 Page 2 CCD-0006412
• Retractable blind to help regulate light filtration and protect privacy.
• Manual sliding system with spring-assist for easier operation.
• Clutched sliding mechanism allows opening to any position.
• Mesh screen keeps out insects and debris while allowing fresh airflow.
• Constructed with durable PVC frame and polyester fabric blinds.
• Integrated aluminum handle for easy operation.
• Compatible with all vehicles with flat walls.
Introduction
The Sirio 2.0 PVC blind assembly is a combination of a flyscreen and shade for windows that can be pulled
up or down by hand using the two different profiles. The integrated spring shaft tensions the fabric
permanently and gives optimum hold. Some key benefits are:
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may
cause death or serious personal injury if not performed safely and within the parameters set forth
in this manual.
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the Lippert limited warranty.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/windows.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
TABLE OF CONTENTS
Introduction 2
Safety 2
Operation 3
Maintenance 3
Rev: 07.07.22 Page 3 CCD-0006412
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Operation
There are two different window profiles: blind (Fig. 1A) and screen (Fig. 1B).
1. Place your hand in the middle of the lower profile (Fig. 1B) to slowly raise or lower the Sirio fly
screen (Fig. 2).
2. Place your hand on the middle top profile (Fig. 1A) to raise or lower the Sirio blind (Fig. 3) slowly.
3. Both profiles can be in use at the same time. Figure 4 depicts a half blind, half screen
window profile.
NOTE: Do NOT rapidly raise and lower the profiles of the assembly. Rapidly raising and lowering the
profiles may cause damage to the Sirio blind or wall of the unit.
Maintenance
Spot clean only the frame with a damp cloth and mild soap.
Fig. 1
Fig. 4
Fig. 2
Fig. 3
A
A
A
B
The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI).
LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an
authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty.
The information contained in this manual is subject to change without notice and at the sole discretion of LCI.
Revised editions are available for free download from lippert.com.
Please recycle all obsolete materials.
For all concerns or questions, please contact
Lippert Components, Inc.
