Lippert Components WiFi On-the-Go Manuale utente

Quick Start Guide

4G LTE

Wireless Hotspot

CCD-0001336

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

The WiFi On-the-Go™was designed and engineered

for the mobile lifestyle. The weatherproof, external

cellular antenna array increases your signal range

far beyond a simple “o󰀨-the-shelf” mobile hotspot.

WiFi On-the-Go™ utilizes Direct Link Technology specically

designed to go wherever you go. Direct Link Technology

provides the fastest 4G LTE connectivity available, up to

150Mbps per second, so you’re connected wherever the

road may take you.

Key Features:

• Direct Link Technology provides the fastest 4G LTE connectivity available,

up to 150Mbps

• Weatherproof externally mounted 4G antenna provides superior coverage

• Designed and engineered for the mobile lifestyle

• 2.4 GHz WiFi antennas designed to provide coverage at a longer range.

• More secure connection than open WiFi networks

• Dual power options; 120V AC/DC adapter or 12V DC/DC adapter

• Four additional Ethernet ports connecting additional devices

• MiMo technology for use with multiple devices

• Compatible with 4G LTE Bands 2, 4 and 12 (AT&T and T-Mobile)

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

4 5

Additional Information Sources

WiFi On-the-Go™ is compatible with AT&T®and T-Mobile®cellular

service using LTE bands 2,4 & 12. In order to activate your

WiFi On-the-Go™ hotspot, the owner will need to purchase their

own AT&T®or T-Mobile®nano Sim card and plan. The AT&T®and

T-Mobile®trade names and logos are registered trademarks of AT&T®

and T-Mobile®US, Inc. respectively.

Additional information about this product can be obtained from

lci1.com/support or by using the myLCI app. Replacement components

can be ordered from https://store.lci1.com/ or by using the myLCI app.

The myLCI app is available for free on iTunes®for iPhone®and iPad®

and also on Google Play™for Android™users. iTunes®, iPhone®and iPad®

are registered trademarks of Apple Inc. Google Play™and Android™are

trademarks of Google Inc.

Safety Information

Parts List

Letter Part# Description Qty

A 715645 Coax Cable, 10’ 2

B 722255 External Cellular Antenna 1

C 383635 #8 x 3/4” Stainless Steel Pan Head Screw 10

D 722251 2.4 GHz WiFi Antenna 2

E 722252 4.0G Cellular Antenna 2

F 716722 12V DC/DC In-line Power Supply 1

G 722250 Cellular Gateway 1

H 722253 120V AC/DC Adapter 1

Fig.1

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

6 7

Preparation

The WiFi On-the-Go is a portable device but can be fastened to a mounting

surface if desired. If the external cellular antenna is not a permanent mount

there are a number of methods of temporary mounting that can be utilized

at the retail customer’s discretion, i.e. hook and loop material, two sided tape,

etc. Use the method best suited for the temporary mounting surface.

If the external cellular antenna is not permanently attached with all weather

sealant, the antenna should not be exposed to water.

The 12V DC/DC power adapter (Fig.1F) can be used to ensure a smooth

power supply to the cellular router when connected to various 12V batteries

or systems such as vehicle, solar power bank, etc. The user will need

to determine which connection type they will need to add to the red/black

wires, such as a cigarette lighter adapter or banana clips, to suit their

specic application.

For immediate use of WiFi On-the-Go™:

1. Attach the two, 4.0G cellular antennae (Fig.1E) to the corresponding

ports of the cellular gateway (Fig.1G).

2. Attach the two 2.4GHz WiFi antennae (Fig.1D) to the corresponding

ports of the cellular gateway.

3. Plug the 120V AC/DC (Fig.1F) or 12V DC/DC (Fig.1H) adapter’s

power supply barrel connector into the back of the cellular gateway.

4. Plug the 120V AC/DC adapter into a wall outlet or connect the red

and black wires of the 12V DC/DC adapter to a 12V power source.

5. See Activation and Operation sections to complete the process.

Activation

Before visiting AT&T®or T-Mobile®, make sure to have the IMEI

(International Mobile Equipment Identity) number available.

The IMEI number is printed on the WiFi On-the-Go™label (Fig.2A).

The IMEI number is a unique 15-digit serial number given to every

device which can then be used to check information such as the device’s

Country of Origin, the Manufacturer and its Model Number.

Whether currently an AT&T®or T-Mobile®Wireless customer or not,

contact AT&T®or T-Mobile®customer service or visit the nearest AT&T®

or T-Mobile®Wireless corporate store to purchase a nano SIM card.

Fig.2

NOTE: For more comprehensive instructions and various options, visit

Lippert Components website at https://www.lci1.com/assets/content/support/manuals/

Electronics/WiFi_On_the_Go____Aftermarket_Manual.pdf

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

8 9

System Requirements

WiFi On-the-Go™parts needed to activate the system:

• Assembled WiFi On-the-Go™ cellular gateway with antennae

• AT&T®or T-Mobile®nano SIM card

• Android, iOS smart device or personal computer

Activation Using AT&T or T-Mobile SIM Card

1. Disconnect the 120V AC/DC adapter or the 12V DC/DC power source

from the cellular gateway (Fig.3A).

2. Locate the SIM card slot on the side of the cellular gateway (Fig.3B).

3. Gently push in on the edge of the nano SIM card adapter (Fig.3B)

and release, the SIM card adapter will pop out.

4. Position the SIM card adapter’s beveled edge on the top right hand

corner (Fig.4C), insert the nano SIM card (Fig.4B) purchased from AT&T

or T-Mobile at the same position, into the nano SIM card adapter (Fig.4A).

NOTE: Take caution when inserting the SIM card adapter into the SIM

card slot opening to ensure that the adapter is NOT inserted below the

SIM card slot opening.

Fig.3

Fig.4

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

10 11

5. Insert the nano SIM card adapter with the nano SIM card into

the SIM card slot (Fig.3B) until a “click” sound is heard.

NOTE: The “click” sound means the SIM card is now securely latched

into the SIM slot.

6. After making sure the SIM card is rmly seated, connect the 120V

AC/DC adapter or the 12V DC/DC adapter to the cellular gateway (Fig.3A).

7. Verify power and connectivity with the Wi On-The-Go™ LEDs

(Fig.3C). Lights will ash when connected.

Operation

After successful activation of Wi On-The-Go™, use a mobile device

to connect to the 4G LTE wireless hotspot.

Connecting to Wi On-The-Go™

1. From the device’s wi- settings, select Wi On_the_Go_9d84.

The password will be blank.

2. To rename the hotspot (ESSID) and set the security settings with

a login password:

A. Open a web browser.

B. Type 192.168.1.1 into the address bar.

C. When prompted, enter the following default username and password

(Fig.5A) and click Login (Fig.5B).

I. Username: root

II. Password: admin

Fig.5

Fig.6

3. After entering the default username and password, from the top menu

bar select the “Network” dropdown menu (Fig.6A).

4. Next, click on “Wi” (Fig.6B).

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

12 13

B. If preferred, rename the hotspot (ESSID) here (Fig.8A) and click Save

(Fig.9A).

Fig.7

Fig.8

A. Click on the Edit button under the “Wireless Overview” section

(Fig.7), then scroll to the bottom of the page.

II. Enter a new password in the “Key” eld (Fig.12A). The password

MUST be at least eight characters.

NOTE: For easy retrieval of a forgotten password, it is recommended to write

down and store the new password in a secure location or use a password

management encrypted database that may be located on your personal

computer or mobile device.

III. Click on “Save & Apply” button (Fig.12B).

NOTE: “Waiting for changes to be applied” may be visible until sign in is

completed.

5. Sign into the hotspot, again.

NOTE: This will be the default hotspot name or the new name given in

step 4B.

6. Select the hotspot from your mobile device’s Wi-Fi settings.

A. If the security password was not changed, no password will be

required to join the hotspot.

B. If the security password was changed (step 4CII), enter the new

password.

C. Click on the “Wireless Security” tab (Fig.10A) to ensure Wi-Fi security.

I. From the menu, select the desired level of security. LCI recommends

WPA2-PSK (Fig.11A).

Fig.9

Fig.10 A

Fig.12

Fig.11

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

14 15

Notes

FCC 15B statement:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment o󰀨 and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit di󰀨erent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Part 15 compliance statement:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

IC User manual notice:

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic

Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including interference that may cause undesired

operation of the device.

Non-modication Warning

Any changes or modications to this device not expressly approved by the party responsible for compliance could void

the user’s authority to operate this equipment.

RF Exposure Statement

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets

the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This

equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.

NOTE: Do not press “RESET” on the back of the cellular gateway unless

directed by Lippert Customer Service. Reset will take the device back to

factory settings and make the device inoperable.

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

Should you have any questions, please do not

hesitate to contact us at (574) 537-8900 or by

email at [email protected].Self-help

tips, technical documents, product videos and a

training class schedule are available at lci1.com

or by downloading the MyLCI app.

Contact

Lippert Components Incorporated

part no. 722050

CCD-0001336

NOT APPROVED FOR PUBLIC RELEASE

06/08/18

Altri manuali per WiFi On-the-Go

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Lippert Components Router wireless

Lippert Components

Lippert Components WiFi On-the-Go Guida rapida

Lippert Components

Lippert Components WiFi On-the-Go Manuale elenco delle parti

Manuali Router wireless popolari di altre marche

Milesight

Milesight UG67 Manuale utente

Airlogic

Airlogic AirSync Class 1 Manuale del proprietario

Samsung

Samsung WCH730B Manuale utente

TELEFONICA

TELEFONICA USB Adapter Manuale utente

NETGEAR

NETGEAR PowerLINE WiFi 1000 Series Manuale utente

Askey

Askey RAC2V1K Manuale utente

Alloy

Alloy WLF2454AP-S Manuale utente

TP-Link

TP-Link TL-WR542G Manuale utente

NETGEAR

NETGEAR WNR2000v4 Manuale utente

Hama

Hama 53120 Manuale utente

Intellinet

Intellinet 524582 Manuale utente

Asus

Asus RT-N10P Manuale utente

D-Link

D-Link DIR-506L Manuale utente

Sapido

Sapido GR297n Manuale utente

Asus

Asus DSL-N55U Manuale utente

AMTC

AMTC WR7502 Manuale utente

Compaq

Compaq CP-2W - iPAQ Connection Point Manuale utente

SMC Networks

SMC Networks WBR14-N2 FICHE Manuale utente
