Livoo DOC204 Manuale utente

Instruction manual

WWW.LIVOO.FR

Reference : DOC204

Version : 1.4

Language : Englis

Stand electrical

barbecue

Instruction manual

You ave purc ased a product LIVOO brand and we t ank you. We take great care in design,

ergonomics and ease of use of our products. We ope t at t is product will give you complete

satisfaction.

T is instruction manual is also available on our website www.livoo.fr

General Safety Instructions

PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE

USING THE APPLIANCE AND SAVE IT FOR ANY FURTHER

NEED.

Incorrect operation or usage is likely to cause damage to

t e appliance and injure t e user. Make sure t at you

follow all safety instructions. Only use t is appliance for

t e purpose for w ic it as been designed; we decline all

responsibility in t e event of damage due to incorrect use

or bad anding.

1. C eck t at your main voltage corresponds to t at

stated on t e appliance.

2. T e safety instructions do not by t emselves eliminate

any danger completely and proper accident prevention

measures must always be used.

3. Never leave t e appliance unsupervised w en in use.

4. Keep t e appliance and its cord out of reac of c ildren

less t an 8 years.

5. C ildren s all not play wit t e appliance.

Instruction manual

6. Cleaning and use maintenance s all not be made by

c ildren unless t ey are older t an 8 year and

supervised.

7. T is appliance can be used by c ildren aged from 8

years and above and persons wit reduced p ysical,

sensory or mental capabilities or lack of experience and

knowledge if t ey ave been given supervision or

instruction concerning use of t e appliance in a safe

way and understand t e azards involved

8. If t e supply cord is damaged, it must be replaced by

t e manufacturer, its service agent or similarly qualified

persons in order to avoid a azard (*).

9. Do not pass t e cord over objects wit s arp edges and

keep it at a distance from, ot objects and bare flames.

Always pull on t e plug to disconnect it from t e feed

source

10. Make sure t at t e cord or t e extension cable is not at

risk of being pulled inadvertently nor of being topped

over by anyone at t e time of use

11. W en you use an extension cable. make sure t at it is

adapted to t e appliance essential consumption.

Contrary to t is, t e extension cable and/ or t e plug

risks over eating.

12. Only use t e appliance for domestic purposes and in

t e way indicated in t e instructions.

Instruction manual

13. Never immerse t e base of your appliance in water or

any ot er liquid for any reason w atsoever. Never

place it into t e dis was er.

14. In case t e appliance accidentally falls into water

disconnect it immediately. Have it c ecked by an expert

before re-using, if you do not do t is you run t e risk of

electrocution.

15. Never try to open t e casing yourself

16. Do not use t e appliance if your ands are damp if t e

oil is wet, or if t e appliance itself is damp

17. Do not touc t e plug if your ands are damp or wet

18. Never use t e appliance near ot surfaces.

19. Never use accessories t at are not recommended by

t e producer. T ey could constitute a danger to t e

user and risk to damage t e appliance.

20. Never move t e appliance by pulling t e cord. Make

sure t e cord cannot get caug t in any way. Do not

wind t e cord around t e appliance and do not bend it.

21. Place t e device on a flat, stable, eat-resistant surface.

22. Unplug t e appliance w en not in use.

23. It is absolutely necessary to keep t is appliance clean at

all times as it comes into direct contact wit food.

24. Make sure t e appliance is unplugged before inserting,

removing or cleaning one of t e accessories.

25. It is absolutely necessary to remove t e accessories

before cleaning t em.

Instruction manual

26. T e appliance is not intended to be operated by means

of external timer or separate remote control system.

27. Keep t is manual wit t e appliance. If t e appliance is

to be used by a t ird party, t is instruction manual must

be supplied wit it.

28. Never carry t e appliance w ile still ot

29. T is appliance is intended to be used in ouse old and

similar applications suc as:

•staff kitc en areas in s ops, offices and ot er

working environments

•farm ouses

•by clients in otels, motels and ot er

residential type environments

•bed and breakfast type environments

30. Warning: Do not use c arcoal wit t is appliance.

31. Always fill t e grill pan wit water before you switc on

t e appliance. T e water elps to cool down t e grill

pan, reduces t e buildup of smoke, and also facilitates

cleaning.

32. Ensure t at t e water level is kept between t e ‘Min.’

and ‘Max.’ markings at all times during use.

← — —Max. water level indicator

← — —Min. water level indicator

T e water level indicator can be found inside t e tank.

33. T e appliance must not be used wit out water

Instruction manual

34. Regarding t e instructions for cleaning wit food,

t anks to refer to t e below paragrap of t e manual

surfaces in contact.

35. T e appliance is suitable for indoor use

(*)

Competent qualified electrician: after sales department of t e producer or importer or any

person w o is qualified, approved and competent to perform t is kind of repairs in order to avoid

all danger. In any case you s ould return t e appliance to t is electrician.

Special measures

Warning

Caution ot surface!

Surfaces are liable to get ot during use.

DO NOT OPERATE this pro uct near water sources or

flammable liqui s.

DO NOT CLEAN OR TOUCH the metals part of this pro uct when

it is still hot

DO NOT USE SHARP OBJECTS

•

Caution: do not, under any circumstances, cover t e grill rack wit aluminous foil, barbecue

dis es or ot er items, as t e resulting build-up of eat could cause irreparable damage to

t e grill.

•

W en grilling food wit a ig fat or moisture content, splas es are not always avoidable.

•

Remember t at t e food wit a ig fat or moisture content may tend to ignite or to splas .

•

Always ensure t at t e water level is kept above t e ‘Min.’ mark so add water during t e

eating to keep rig t level and ensure t at it does not come into contact wit t e eating

element.

Instruction manual

•

Before t e grill is used, always c eck t at t e eating element is correctly fitted in t e grill

pan and safely locked.

•

Do not connect t e grill to mains power until t e grill pan as been filled wit water. T e

tray salvage dealer of fat must be immersed and take care of not pour water on t e eating

element.

•

Use only t e supplied tray salvage dealer of fat .

•

Ensure t at t e grill is not stored outdoors. Or in any ot er location w ere it mig t be

subjected to extremes of temperature or ig umidity.

•

No responsibility will be accepted if damage results from improper use, or if t ese

instructions are not complied wit .

SPECIFICATIONS

AC 220-240V 50-60Hz 2000W

DESCRIPTION & BARBECUE ASSEMBLY

Before using for the first time

•

Remove any packaging materials from t e appliance.

•

Clean t e tank, tray salvage dealer of fat and t e grill pan

•

T e tank must be filled wit water up between MIN and MAX marking, never fill water on t e

•

Heating element, it will damage it. Plug t e appliance.

•Let t e grill eat up for a moment wit out any food, t is will reduce t e smell w en first switc ing on a

new grill (a slig t smell and a little smoke may be emitted-ensure sufficient

ventilation

Ensure t at t e grill is placed in a safe and stable position. T e power cord s ould be placed

suitably in order t at no one is likely to trip over it

•

Part no.1&2 are already fixed up

•Heating part No.3 needs to simply place into t e part above.(no screws or nut needed)

•Grill rack no.4 needs to place on t e above of all above unit.

Instruction manual

1. Plastic body

Tray salvage dealer

of fat

3. Plastic cover s eet

4. Heating element

5. Grill rack

Stan Assembly:

A1.short leg

A2.long leg

A3.short metal shelf

A4.long metal shelf

A5.butterfly nut

A6.M5 Screw

Step 1: Insert t e s ort leg into t e long leg, and ensure t e ole on s ort leg can meet wit ole on long

leg to make t e black screw inserting successfully.

Step 2: Put t e s ort metal s elf and long metal s elf on t e two sides of t e pipe’s ole (t e direction for

s ort line of bot metal s elf s all be always onward), and insert t e black screw into oles and finally fixed

wit t e butterflys aped nut, same as above diagram s ows.

Instruction manual

A7. Rubber sockets

A8. Lower grill

Step 3:

Get all four legs fixed as a complete stand, same as t e diagram above.

Step 4:

Insert t e 8pcs of rubber socket into t e ole of stand separately.

Step 5:

Put t e lower grill onto t e stand and put t e table BBQ onto t e stand.

Step 6:

Now you are ready to use t e Barbecue.

USE

1. T e tank must be filled wit water up between MIN and MAX marking, never fill water on

t e eating element, it will damage it. Plug t e appliance.

2. Set t e t ermostat control knob on t e temperature MAX and after 5-10 minutes, eating

element is ready. T e indicator lig t turns on and off during t e eating, t at’s normal.

3. T e water in t e tank will evaporate during use. So you must to fill up water from time to

time. Be careful not to pour water on t e eating element.

4. W en you grilling t e food stuffs, you ave to return t em sometimes wit adapted

accessories and you can c oose t e temperature you want.

5. T e grill can also be used to keep t e food warm: by turning t e t ermostat control knob

back to a lower position

6. W en grilling is finis ed, turn t e t ermostat to “0” (off position) and disconnect t e grill

from t e mains supply socket.

Instruction manual

CLEANING AND STORAGE

Caution:

Do not use wire brus or any abrasive items or liquids to clean t e appliance.

Always remove t e plug from t e socket before cleaning t e barbecue

Ensure t at t e appliance as completely cooled down

T en you s ould remove t ermostat control knob and eating element from t e tank,

never immerse t em in water. Never switc t e eating element on w en it is not placed

onto t e appliance.

Clean t e tank, tray salvage dealer of fat and t e grill pan wit warm soapy water and dry

afterwards.

Use damp clot to clean t e eating element.

Do not use dis was er

Storage

After cleaning, t e grill s ould be stored indoors in a dry location.
