Logitech G500 Manuale utente
User’s guide
TM
LogitechTM
Gaming Mouse G500
Contents 內容 ഺ 목차
English Configuration, 3 Mouse features, 4
繁體中文 設定，8滑鼠功能，9
଼ᄏᒦᆪ ᒙLj13 ၡܪถLj14
한국어 구성, 18 마우스 기능, 19
User’s Guide
English 3
Configuration
Your Gaming Mouse G500 is combat-
ready, right out of the box. For access
to more advanced features—such as
using onboard memory to store personal
settings—download Logitech™ SetPoint
for the G500 and use it to tune your
mouse for maximum performance.*
Start SetPoint from the taskbar or the1
Windows Start menu.
Upon launching, SetPoint asks you
to select a Logitech device.
Double-click the thumbnail image of2
the G500.
The Overview appears, providing
general information about your
G500.
Overview
Displays your current profile settings
Welcome screen
Double-click the image of your G500
mouse to view and modify settings
Download the latest version of SetPoint from
www.logitech.com/downloads
*
Gaming Mouse G500
4English
Mouse features
Gaming profiles to go
The G500 gives you onboard memory
for storing your gaming profile—personal
game preferences you can take with you
to LAN parties or competitions.
With settings-to-go, you can play your
favorite titles on computers other than
your own, without installing driver software
or recreating game preferences.
You can store settings such as button
assignments, keyboard macros, DPI
settings, and USB report rate in your
profile.
Use SetPoint software to create as many
profiles as you want and save them to
disk. Select any one of the saved profiles
to store on the G500, or use application
detection to automatically switch profiles
when you start a new game.
Profile Manager
Choose a profile to store in onboard memory
Macro Editor
Record keystrokes and other mouse actions as
macros you can save in profiles
User’s Guide
English 5
Adjustable DPI
Change your mouse DPI on the fly to
instantly adapt to different game
situations—without pausing the action.
Before software installation, you can toggle
between three preset levels of resolution:
400 dpi, 800 dpi, and 2000 dpi.
Use low DPI for pixel-precise targeting.
Shift to high DPI for lightning-fast
maneuvering.
Storing DPI settings in memory
Use SetPoint to create up to five custom
DPI settings you can store in onboard
memory and take with you to LAN parties
and competitions. Specify custom DPI
settings between 200 dpi and 5700 dpi
(in increments of 100). Your mouse
indicates current DPI with different
patterns of LED panel lights.
Panel lights
indicate current
DPI setting
Mouse features
Press (+) to raise DPI
Press (-) to lower DPI
DPI settings
#1 #2 #3 #4 #5
Gaming Mouse G500
6English
Dual-mode scroll wheel
Provides two scrolling modes, click-to-click
and hyper-fast, and three programmable
buttons—middle button, tilt left, and tilt
right.
Scroll wheel mode
shift button
Press to shift between
hyper-fast and click-to-
click scrolling
Dual-mode
scroll wheel
Hyper-fast scrolling
When you’re not gaming, the
near-frictionless wheel lets you
fly through long documents and
Web pages
Precision scrolling
Click-to-click scrolling mode is
perfect for selecting weapons
Mouse features
User’s Guide
English 7
Weight tuning system
Tune the weight and balance of your
G500 with an innovative weight tuning
system.
Mix and match up to 27 grams of weights
in 1.7-gram and 4.5-gram increments for
optimal customization of balance and heft.
A lighter mouse reduces fatigue and is
ideal for gamers who like to “skate.” Add
weight if you prefer a heavier mouse that’s
easier to control.
Mouse features
To add weights:
Press the cartridge release button on1
the base of the mouse to eject the
weight cartridge.
Snap the desired weights into the2
cartridge.
Slide the cartridge into the mouse.3
Cartridge
release
button
1
2
3
Mix and match weights
Snap up to six cylindrical
weights into the cartridge to
fine-tune your G500 for optimal
inertia and balance
8 繁體中文
遊戲滑鼠 G500
設定
您只需將遊戲滑鼠 G500 從包裝盒中取
出，即可加入戰鬥。如果要使用更多進
階功能，例如使用內建記憶體來儲存個
人設定等，請下載用於 G500 的Logitech™
SetPoint，然後使用該軟體將您的滑鼠調
整到最佳性能。*
從工作列或 Windows「開始」功能表啟1
動SetPoint。
在啟動期間，SetPoint 會要求您選擇
一種 Logitech 裝置。
連按兩下 G500 滑鼠的縮圖。2
即會顯示「總覽」，其中包含有關
G500 的一般資訊。
總覽
顯示您目前的設定檔設定。
歡迎螢幕
連按兩下 G500 滑鼠影像以檢視和修改
設定。
從www.logitech.com/downloads 下載最新
版本的 SetPoint
*
繁體中文 9
使用者指南
滑鼠功能
遊戲設定檔與您隨行
G500 提供內建記憶體供您儲存遊戲設定
檔，您可以帶著這些個人遊戲偏好設定
加入連線遊戲或競賽遊戲。
透過使用這些儲存的設定，您可以在他
人的電腦上用您最喜歡的設定玩遊戲，
而無需安裝驅動程式軟體或重新建立遊
戲偏好設定。
您可以將按鈕指派、鍵盤巨集指令、DPI
設定以及 USB 報告頻率等設定儲存在您
的設定檔中。
您可以使用 SetPoint 軟體建立多份設定
檔，並將其儲存到磁碟中。從儲存的設
定檔中任選一份儲存到 G500 上，或使用
應用程式檢測在啟動新遊戲時自動切換
設定檔。
設定檔管理器
選擇一份設定檔儲存到板載記憶體中
巨集指令編輯器
將按鍵動作和其他滑鼠動作記錄為可以儲存到
設定檔中的巨集指令
10 繁體中文
遊戲滑鼠 G500
可調整 DPI
在遊戲期間變更滑鼠 DPI 以即時適應不同
的遊戲狀況，而無需暫停遊戲動作。
安裝軟體之前，您可以在預設的解析度
等級 400 dpi、800 dpi 和2000 dpi 之間
切換。
對於像素精度瞄準，可使用低 DPI 設定。
對於快速操縱，可切換到高 DPI 設定。
將DPI 設定儲存到記憶體中
使用 SetPoint 建立多達五種自訂 DPI 設
定，您可以將其儲存到內建記憶體中，
並帶著這些設定參加連線遊戲和競賽遊
戲。在 200 dpi 到5700 dpi 之間指定自
訂DPI 設定（以 100 為增量）。您的滑
鼠可使用不同模式的 LED 面板燈來指示
目前的 DPI 設定。
LED指示燈
顯示目前的
DPI 設定
滑鼠功能
按(+) 可提高 DPI
按(-) 可降低 DPI
DPI 設定
#1 #2 #3 #4 #5
