LOOP EV-Flex EVSE Manuale utente

v.20.9.4

User Manual

Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

2 Loop EV-FlexTM EVSE

Contents

Important Safety Instructions 4

1. Introduction 7

1.1 Product Overview 7

2. Product Specications 8

3. Installation & Conguration 9

3.1. Before Installation 9

3.1.A. Safety Check 9

3.1.B. Grounding Instructions 9

3.2. Tools & Parts Required for Installation 9

3.3. Assembly and Installation of the Charging Station 10

3.4. Install the Connector and Cable Holster 16

3.5. Install the SIM Card 19

3.6. Commissioning 22

3.6.A. Access the Built in Webportal 22

3.6.B. Login 23

3.7. Webportal Overview 24

3.7.A. Menu Overview 24

3.7.B. Conguration Menu 25

3.7.C. Maintenance Menu 26

3.7.D. EVSE Status 27

3.7.E. LLM Status Menu 28

3.7.F. Security Menu 29

3.8. Conguration 30

3.8.A. Factory Settings 30

3.8.B. Station Settings 32

3.8.C. OCPP Settings 35

3.8.D. Communication Settings 41

3.9. Maintenance 49

3.9.A. Reboot 50

3.9.B. Firmware Update 53

3.10. EVSE Status 54

3.11. LLM Status 55

3.11.A. LLM Information 55

3.11.B. Gateway/Client Group Table 56

2Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

3 Loop EV-FlexTM EVSE

Contents

3.12. Security 56

3.12.A. Change Password 56

4. Operations 57

4.1. Charging Status Indicators 57

4.2. Authorization 58

4.2.A. Online Authorization 58

4.2.B. Local Authorization 59

4.3. Charging an Electric Vehicle (EV) 60

4.3.A. Plug and Charge 60

4.3.B. RFID Card 60

4.4. Stop Charging 60

4.4.A. Interrupt Charging 60

4.4.B. Auto Restart 60

4.4.C. Power Outage Recovery 61

4.5. General Care 61

4.6. Customer Support 61

3Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

Important Safety Instructions

This document contains instructions and warnings that must be followed when installing and using the Electric Vehi-

cle Supply Equipment (EVSE). Before installing or using the EVSE, read this entire document as well as WARNING and

CAUTION markings in this document.

Safety Instructions

The symbols used have the following meaning:

WARNING: RISK OF PERSONAL INJURY

WARNING ELECTRIC: RISK OF SHOCK

WARNING: RISK OF FIRE

CAUTION: RISK OF DAMAGE TO THE EQUIPMENT

+ The Loop EV-Flex EVSE must be installed only by licensed electricians.

+ Make sure that the materials and installation procedures follow local building codes and safety standards.

+ The information provided in this manual in no way exempts the user of responsibility to follow all applicable

codes or safety standards.

+ This document provides instructions for the Loop EV-Flex EVSE and should not be used for any other product. Be-

fore installation or use of this product, review this manual carefully and consult with a licensed contractor, licensed

electrician, or trained installation expert to ensure compliance with local building codes and safety standards.

4 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

Repair and Maintenance Clause

+ Only licensed electricians can repair or maintain the Loop EV-Flex EVSE. It is forbidden for general users to repair or

maintain it.

+ Turn o input power before repair or maintenance the Loop EV-Flex EVSE.

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment o and on, the user

is encouraged to try to correct the interference by one of the following measures:

+ Reorient or relocate the receiving antenna.

+Increase the separation between the equipment and receiver.

+ Connect the equipment into an outlet on a circuit dierent from that

to which the receiver is connected.

+ Consult the dealer or an experienced radio/TV technician for help.

FCC Caution:

Any changes or modications not expressly approved by the party responsible for compliance could void the user’s

authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Radiation Exposure Statement:

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment

should be installed and operated with greater than 20cm between the radiator & your body

5 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

Save These Instructions

WARNING ELECTRIC: RISK OF SHOCK

Basic precautions should always be followed when using electrical products, including the following:

+ Read all the instructions before using this product.

+This device should be supervised when used around children.

+ Do not put ngers into the EV connector.

+ Do not uses this product if the exible power cord or EV cable is frayed, has broken insulation, or any

other signs of damage.

+ Do not use this product if the enclosure or the EV connector is broken, cracked, open, or shows any other

indication of damage.

WARNING: RISK OF ELECTRIC SHOCK

Improper connection of the equipment grounding conductor can result in a risk of electric shock. Check

with a qualied electrician or serviceman if you are in doubt as to whether the product is properly

grounded.

WARNING: RISK OF ELECTRIC SHOCK

+Do not touch live electrical parts.

+ Incorrect connections may cause electric shock.

WARNING:

This equipment is intended only for charging vehicles that do not require ventilation during charging.

Please refer to your vehicle’s owner’s manual to determine ventilation requirements.

WARNING:

Do not use extender cables to increase the length of the charging cable. Maximum length is limited to 25

feet by the National Fire Protection Agency.

WARNING: Do not drag the Loop EV-Flex EVSE by input power cord.

6 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

1. Introduction

This user manual applies to “32A Level 2 AC Charger for Plug-in Electric Vehicles (PEVs) and Battery Electric Vehicles

(BEVs)”.

!!! Any unauthorized modifications will void the manufacturer’s warranty !!!

1.1. Product Overview

Description Quantity Remark

1 Loop EV-Flex EVSE

+ SAE J1772 Connector

+ OLED Display

+ RFID Icon

2Mounting Bracket 1 Attached to the back of the Loop EV-Flex EVSE

3Holster 1 With Hook x1, Holster x1 & M4xL15 tapping screw x2

4Screw Bag 1With #12xL50 tapping screw x4

Figure 1-1 - Box Contents

Table 1-1 - Accessories in the box

7 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

2. Product Specications

Item Loop EV-Flex EVSE

Application Commercial

Voltage (Vac) 208/240VAC, Single Phase

Frequency (Hz) 60 Hz

Current (Rms) 32 A

Charging Connector SAE J1772 Type 1

Charging Cable Length 25 ft.

Metering Accuracy Embedded ± 1%

Real Time Clock Yes (7 days)

Indications

+ Green Steady: Ready

+ Green Flashing (Fast): Authorized, wait for EV Connect

+ Green Flashing (Slow): Suspend (Occupying)

+ Blue Flashing (Slow): Charging

+ Red Steady: Unrecoverable Fault

+ Red Flashing (Slow): Recoverable Fault

+ Yellow Steady: Out of Service

+ Yellow Flashing (Slow): Booting / Firmware Upgrading

Remark

+ Fast Flash: On Time 300ms, O Time 200ms, 2Hz

+ Slow Flash: On Time 1200ms, O Time 800ms, 0.5Hz

Wi-Fi 802.11 b/g/n

Cellular LTE Cat. 1 (AT&T or Verizon)

RFID

ISO 14443 A/B,

ISO 15693,

NFC,

NEMA interoperability protocol

Display 116(L)*8.5(W)*37(H)mm, 5.57mm CHARACTER HEIGHT, 5*8 DOT MATRIX,

OLED 20x2

Data Protocol OCPP 1.6

Operation Temperature -30 ~ 50 ℃/ -22 ~ 122 ℉

Storage Temperature -40 ~ 70 ℃/ -40 ~ 158 ℉

Mounting Type Wall mount / Pole mount (optional)

Wiring Type Hard-wired

IP Performance NEMA 4

Impact Resistance IK10

Dimension (H x W x D, inch) 11.14” x 7.56” x 3.11”

Weight (Net) 5.28 kg / 11.64 lbs

Web Portal Management Yes

Console Management Yes

Certication

Energy Star / UL 50/991/1449/1998/2231/2594 FCC Part 15B

FCC Part 15.225 (RFID 13.56MHz)

FCC Part 15.247 (WLAN 2.4GHz)

FCC Part 27 (AT&T) or

FCC Part 27 (Verizon)

8Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

3. Installation & Conguration

3.1. Before Installation

3.1.A. Safety Check

CAUTION: Disconnect the power supply before installing or repairing the Loop EV-Flex EVSE. Failure to

do so may result in physical injury or damage to the power supply system and the Loop EV-Flex EVSE.

The Loop EV-Flex EVSE must be installed only by a licensed electrician in accordance with the provisions of the local

electrical industry construction and should comply with national electrical codes and standards.

Before installing the Loop EV-Flex EVSE, make sure you have read all instructions in this manual and fully understand

its contents.

Proper protective equipment is required when connecting to a main switchboard. The tools and parts used as outlined

in the section “Tools & parts required for installation”.

3.1.B. Grounding Instructions

The Loop EV-Flex EVSE must be equipment grounded through an equipment grounding conductor. Use a wire with a

dedicated grounding wire and a ring terminal and connected to the equipment ground terminal block for grounding.

3.2. Tools and Parts Required for Installation

Tool Quantity Size Supplier Remark

Mounting Bracket 1194x109x9 mm Model Accessories Fasten Loop EV-Flex

EVSE to the wall

Holster Assembly 1 58x58x70 mm Model Accessories Hold EV charging

connector & cord

Screw 4Tapping: #12 Model Accessories Fasten Mounting

Bracket & Hook

Mechanical: M6 Commercially Available

Wire, Copper 38 AWG Commercially Available UL1015 (recommended)

Heat Shrink Tube 3For 8 AWG wire Commercially Available Protect wires &

terminals

Terminal 3 For 8 AWG wire Commercially Available Connect input wires to

the terminal block

Conduit 1 1 inch Commercially Available Protect power cable

Torx Screwdriver 1 T20 Commercially Available

Philips Screwdriver 1 PH3 Commercially Available

Hexagon Socket 15/16 Commercially Available Tighten #12 Tapping

screws

Torque Wrench 135 kgf-cm min Commercially Available

Table 3-1 Tools & parts required for installation

9 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io

3.3. Assembly and Installation of the Charging Station

1. Open the carton and remove the upper partition.

Figure 3-1 Opening the carton

2. Take out the Loop EV-Flex EVSE and upturn middle partition. The charging plug is in the bottom of the package.

Figure 3-2 Take out the Loop EV-Flex EVSE

3. Remove the holster assembly placed inside the right of the middle partition.

Figure 3-2 Accessories inside the middle partion

10 Loop EV-FlexTM EVSE

EVS-32A-L2-001 (R-Model)

v.20.9.4

www.evLoop.io
