Lorex U424AA Series Manuale utente

2K Wire-Free Camera

Quick Start Guide

U424AA Series

lorex.com

How to get started with your

2K Wire-Free Camera

Thank you for your purchase!

Disclaimers

• A regulated UL / CSA approved power supply is required for use with this camera (included).

Use of a non-regulated, non-conforming power supply can damage this product and voids the

warranty.

• Not intended for submersion in water. Installation in a sheltered location recommended.

• Audio recording without consent is illegal in certain jurisdictions. Lorex Corporation assumes

no liability for use of its products that does not conform with local laws.

• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes between

Day/Night

viewing modes, an audible clicking noise may be heard from the camera. This clicking is

normal and

indicates that the camera lter is working.

• Some channels on the 5GHz Wi-Fi band are restricted in Canada. This means certain Wi-Fi

networks may not be available to connect to during setup.

Safety Precautions

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use and handling of the product.

• Operate the camera within the specied temperature, humidity and voltage and use manufac-

turer approved accessories.

• Do not disassemble the camera.

• Do not point the camera directly at the sun or a source of intense light.

• Periodic cleaning may be required. Use a damp cloth only. Do not use any harsh, chemi-

cal-based cleaners.

Contents

Package Contents

Section

Overview

Before You Start

Setup

Pairing to the App

App Live View

Mounting

Package Contents

2K Wire-Free

Security Camera

(x1)

Re-chargeable

Battery Pack

(x1)

Charging

Adapter & Cable

(x1)

Camera

Antenna

(x1)

Mounting

Bracket

(x1)

Anchors (x4)

Screws (x4)

Security Screws (x2)

Allen Key (x1)

Drill Bit (x1)

Screwdriver (x1)

Overview

7. Fastener

8. Pairing

button

9. Adjustment

ring

10. Battery

release

tabs (x2)

11. Mounting

plate slots

(x2)

1. Detachable

antenna

2. Warning light

3. PIR sensor

4. Locking

screw

5. Power port

6. Battery

charging

indicator

SIDEFRONT

BOTTOM BACK MOUNTING PLATE

Dimensions

• Height: 4.8” (121mm)

• Width: 5.2” (131mm) • Length: 2.9” (73mm)

The camera battery comes partially charged (due to safety regulations). Please, fully

charge the battery before use and setup. You can charge the battery pack inside or

outside of the camera.

Before You Start

To charge the camera battery

pack:

1. Remove the protective lm on the

battery contacts and camera lens.

2. Using the provided battery

charging adapter and cable,

connect the camera to a nearby

outlet.

Camera Battery Charging Indicator Battery Charging Time

(solid) Fully charged

(solid) Charging

2-cell 2-4 hours

3-cell 3-5 hours

Setup

1. Turn the adjustment ring counter-

clockwise to loosen and angle the camera.

2. Screw in the antenna.

3. Insert the battery pack into the bottom of

the camera.

Note: You will hear a ‘beep’ when the

power pack is properly inserted. If you do

not hear this alert, remove the power pack

by pushing in on the battery release tabs

then re-insert.

Adjustment ring

Pairing to the App

Click the icon in an empty channel screen. After you press and hold the pairing

button on the back of your camera, you will have 30 seconds to pair the camera.

Optional: Pairing on the Recorder

1. Download the Lorex Cirrus app by scanning the QR code.

2. Open the Lorex Cirrus app and sign in or create an account.

3. From the Home screen, select your recorder from the list

of devices.

4. Tap any free channel marked with a icon.

5. Tap Pair.

6. Press and hold the pairing button on the back of the camera

until the red LED lights stop flashing, then release the

pairing button. A ‘Pairing success!’ message will appear on

screen. If you do not see this message, repeat steps 3-6.

App Live View

Settings

Device casting

Favorite group

Name display

Device name

Search / playback

video

Indice

Lingue:

Altri manuali Lorex Macchina fotografica digitale

Lorex

Lorex U471AA Series Manuale utente

Lorex

Lorex BB331AC1 Manuale utente

Lorex

Lorex ACH20-1B Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

Lorex

Lorex W452AS Series Manuale

Lorex

Lorex L8559 Series Manuale utente

Lorex

Lorex LW2101AC1 Series Manuale utente

Lorex

Lorex L8559 Series Manuale utente

Lorex

Lorex U855AA Series Manuale utente

Lorex

Lorex W881AA Series Manuale utente

Lorex

Lorex W462AQC Series Manuale utente

Lorex

Lorex L4248 Series Manuale utente

Lorex

Lorex Aurora Series Manuale utente

Lorex

Lorex CMD6129 Manuale utente

Lorex

Lorex L4248 Series Manuale utente

Lorex

Lorex W461AS Series Manuale utente

Lorex

Lorex U855AA Series Manuale utente

Lorex

Lorex LNC201 Manuale utente

Lorex

Lorex C884DA Series Manuale utente
