Lorex VANTAGE LH110 ECO SERIES Manuale di istruzioni

1

www.lorextechnology.com

Copyright ©2011 Lorex Technology

LH110 Series DVR: Frequently Asked Questions

When connected to a VGA monitor, why can’t I see a mouse cursor, or

access the system menus by using the front panel controls of the DVR?

Solution 1

You may have accidently switched the system output by pressing the 0button on the

remote; or the DVR did not properly detect the VGA monitor.

To switch back to VGA mode:

1 Turn on the DVR. Wait for it to boot into the main window.

2 Press the 0(zero) button on the remote.

Pressing the 0(zero) button on the remote changes the DVR from SPOT OUT mode to VGA

mode. After the DVR is in VGA mode, you will be able to see your mouse, and have access

to the menu.

Solution 2

The DVR may not have correctly detected your VGA monitor because of a loose connection.

Perform the following:

1 Unpower the DVR.

2 Power down and re-connect the VGA monitor to the DVR. Ensure that the connection is firm.

3 Turn on the monitor.

4 Turn on the DVR. Wait for it to boot into the main window.

NOTE: After you re-connect the VGA cable between the monitor and DVR, ensure that you

first turn on the monitor, and then turn on the DVR last. This allows the DVR to

auto-detect the connected VGA monitor.

NOTE: If you still cannot see the mouse cursor, or access the menu, press the 0(zero) button

on the remote control.

2

Copyright ©2011 Lorex Technology

Manually setting the DVR output mode

You can set the DVR to always output to the VGA port by manually configuring the output

settings.

To manually adjust the output settings:

1 Right-click and click Main Menu.

2 Click Advanced>A/V Setup.

3 In the Output Device drop-down menu, select VGA.

NOTE: In the 16-channel model, select VGA in the Init DEV drop-down menu.

4 Click Apply to save your settings.

Select VGA

4/8 Channel

Select VGA

16 Channel

3

www.lorextechnology.com

Copyright ©2011 Lorex Technology

How do I change the DVR’s output resolution?

1 From live view, right-click, and click Main Menu>Advance >A/V Setup.

2 Under VGA Resolution:

• Select from the following resolutions: 800 x 600,1024 x 768, 1280 x 1024, 1440 x 900

3 Click Apply to save your settings.

4 Right-click to exit the A/V setup menu.

NOTE: The system will prompt you to restart the system. Click the OK button to restart.

4/8 channel A/V menu. 16 channel A/V menu.

VGA Resolution VGA Resolution
