Loxit IBank 10 Manuale utente
Loxit Limited, First Avenue, Poynton Industrial Estate, Poynton, Cheshire, UK. SK12 1YJ
www.loxit.com ꞁ [email protected]m ꞁ +44(0)1625 856 801
IBank 10 Instructions- 7715 and 7716
Wall Mounting
If you are not mounting your cabinet on a wall, please move on to the cabling instructions.
2. To access the fixing holes in the back
of the cabinet gently flex the dividers
and remove them.
1. Unscrew the bolts indicated on each side of
the IBank and remove the vanity panel.
3. Mark the holes for the fixings on the wall and drill the holes.
4. Mount the IBank to the wall using fixings appropriate for the wall.
Loxit Limited, First Avenue, Poynton Industrial Estate, Poynton, Cheshire, UK. SK12 1YJ
www.loxit.com ꞁ [email protected]m ꞁ +44(0)1625 856 801
5. Once the IBank has been
secured to the wall gently flex
the dividers to put them back
into place.
Cabling
1. If you have not already done so, Remove the
vanity panel by unscrewing the four bolts
indicated.
Loxit Limited, First Avenue, Poynton Industrial Estate, Poynton, Cheshire, UK. SK12 1YJ
www.loxit.com ꞁ [email protected]m ꞁ +44(0)1625 856 801
2. Insert a charger into the power strip or a USB lead into the Loxit USB
charger, depending on your IBank model.
3. Loop the charge cable through
the cable restraint cutout as
shown, then pass the cable
through the J-shaped cutout
and feed it through.
Cable restraint
J-Shaped cutout
4. Repeat steps 2 and 3 until all
the cables are in place.
5. Bolt the vanity panel back into
place using the four bolts.
The installation of your IBank 10 is now complete
