LST SLR-E-IS Manuale utente

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27

[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED

SLR-E-IS_DBL_LST_EN_0804.PDF • PAGE 1

ABuilding Safety. Building Security.

IS Optical Smoke Detector

SLR-E-IS for Hazardous Areas

Description

• Conventional technology

• Optional connection of remote

indicator

• Extremely ﬂ at design

• Function testable with test gas

• ATEX certiﬁ ed

Speciﬁ cations

Ignition protection intrinsically safe

Ex classiﬁ cation EEx ia IIC T5

Current consumption at 24V typ. 50µA (quiescent)

Ambient temperature -10°C to +55°C

Relative humidity 10 – 95% (no condensation)

Dimensions ø × H (incl. base) 100 × 46 (mm)

Colour cream

Weight 115g

Approval BAS01ATEX1281

LPCB 164a

Order number 241090

Order name IS Optical Smoke Detector/Conv. SLR-E-IS

The Intrinsically Safe Optical Smoke Detector SLR-E-IS

uses the scattered light principle and was developed

for the detection of smoke particles in explosion-prone

rooms.

The modern design of the sensing chamber al-

lows to reliably evaluate the characteristics of ﬁ re.

Conventional technology is used for alarm transmission

to the ﬁ re detection control panel. In conjunction with the

Safety Barrier ES58-2, the detector reaches the given

Ex classiﬁ cation. The two LEDs with 360° visibility indi-

cate the activated condition of the detector. By means

of an auxiliary module, the connection to an ADM loop

is possible.

A detector function test can be conducted by using test

gas. The detector is attached to the IS Detector Base

YBN-R/4IS.

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27

[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED

SLR-E-IS_DBL_LST_EN_0804.PDF • PAGE 2

ABuilding Safety. Building Security.

Detector Base

Ambient temperature -10°C to +55°C (no condensation or icing)

Relative humidity 10 – 95% (no condensation)

Dimensions ø × H 100 × 15 (mm)

Colour white

Weight 45g

Order number 246090

Order name IS Detector Base/Conv. YBN-R/4IS
