Lucent Technologies SPIRIT 1224 Controller Manuale utente
Lucent Technologies
Bell Labs Innovations
SPIRIT
®
Communications System
SPIRIT
Attendant
User’s Guide
Lucent Technologies—
formerly the communications
systems and technology
units of AT&T
518-453-710
106449697
Issue 1
April, 1991
©
1991 AT&T
All Rights Reserved
Printed in U.S.A.
518-453-710
106449697
Issue 1
April, 1991
Trademarks
SPIRIT is a registered trademark of Lucent Technologies.
NOTICE
The information in this document is subject to change without notice. Lucent Technologies assumes
no responsibility for any errors that may appear in this document.
Intellectual property related to this product (including trademarks) and registered to AT&T
Corporation has been transferred to Lucent Technologies Incorporated.
Any references within this text to American Telephone and Telegraph Corporation or AT&T should
be interpreted as references to Lucent Technologies Incorporated. The exception is cross references
to books published prior to December 31, 1996, which retain their original AT&T titles.
Lucent Technologies – formed as a result of AT&T’s planned restructuring – designs, builds, and
delivers a wide range of public and private networks, communication systems and software,
consumer and business telephone systems, and microelectronic components. The world-renowned
Bell Laboratories is the research and development arm for the company.
Contents
Section 1: Overview
Introduction
1-1
The SPIRIT Attendant 1-2
Section 2: Changing the Current Settings
Changing the Current Settings
2-1
Section 3: Troubleshooting
Troubleshooting
3-1
Index
Index
IN-1
List of Tables
Table
1-1
SPIRIT Attendant Front Panel Lights
1-2
Setup Switches
1-3
Calls Per Hour Table
1-4
Incoming Lines Table
2-1
Reference Table for Changing Settings
2-2
Time Allocations for Recorded Announcements
2-3
Call Processing Options
Page
1-6
1-8
1-9
1-9
2-2
2-7
2-13
List of Figures
Figure
Page
Immediate and Backup CaIl Handling
Front View of the SPIRIT Attendant
Back View of the SPIRIT Attendant
1-1
1-4
1-2
1-6
1-3
1-7
Section 1: Overview
Introduction
This User’s Guide explains how the SPIRIT Attendant works and how to change
initial settings. To use the SPIRIT Attendant:
❑
❑
❑
❑
Consult the SPIRIT Attendant Planning Configurator Form that your
AT&T representative completed for your SPIRIT system.
Have the SPIRIT Attendant installed by an AT&T-authorized technician
who has administered a station port on the control unit for each
SPIRIT Attendant.
Have the SPIRIT Attendant administered by an AT&T-authorized
implementor who has completed these two procedures:
●
Programmed your business schedule and route plans
●
Recorded your announcements
Be sure you know your authorized caller code. See “Changing the
Authorized Caller Code” in Section 2, “Changing the Current Settings,”
for more information about this code.
The SPIRIT Attendant 1-1
The SPIRIT Attendant
The SPIRIT Attendant answers incoming calls on designated lines with a
prerecorded message and directs the calls to the appropriate extension in your
SPIRIT Communications System. The SPIRIT Attendant can help your business
by answering calls immediately or after a delay to assist a busy receptionist. It
can also answer calls when your company is closed for holidays and weekends,
and after normal business hours.
NOTE:
To avoid confusion between a human attendant and the
SPIRIT Attendant, this document refers to the human attendant as the
receptionist.
A prerecorded announcement can provide callers with information on how to
reach certain departments or people within your company. Generally, a list of
one-digit numbers, known as routes, is provided so that callers can dial the
department they need with the touch of a button. If appropriate, the
announcement can also give callers the option to enter extension numbers to
reach employees directly.
For example, during normal business hours a car dealership directs customer
calls to the SPIRIT Attendant so that callers hear the day announcement, which
offers the following options:
"Thank you for calling ABC Motors. If you are calling from a
rotary dial phone, please hold for assistance.
For Sales, dial 1...
For Service, dial 2...
For Parts, dial 3...
For the receptionist, dial 0...
For a specific employee, dial the extension number
or dial 0 for operator assistance."
NOTE:
In the above example, the numbers 1, 2, 3, and 0 are routes. To
minimize errors, you should provide no more than five routes.
After the car dealership closes, calls are answered immediately by the SPIRIT
Attendant and the night announcement plays:
“Thank you for calling ABC Motors.
Our sales hours are 10:00 a.m. to 6:00 p.m. Monday through Saturday.
If you are calling our Service Department, dial 1 now.
If you know the extension number of the person you are
calling, dial that number now.”
If a caller does not enter a route or extension number because he or she is calling
from a rotary phone or does not know the extension number, the call is
automatically directed to the receptionist after a specified number of seconds (2
to 5). You can select the number of seconds by using the “Call Processing
Options” described in Section 2, “Changing the Current Settings.”
Callers using Touch-Tone phones can also bypass the announcement by dialing
the route or extension they want at any time during the message. Their calls are
transferred immediately to the route or extension number they have selected.
1-2
The SPIRIT Attendant
Day and Night
Announcements
Call Handling
You can choose from two different announcements (day or night) to play to
callers when the SPIRIT Attendant answers incoming calls. Both the day
announcement and the night announcement can direct calls to up to nine
different routes (1 through 9, 0 is reserved for the receptionist). Additionally,
these announcements can offer callers the option to dial individual extension
numbers.
Depending on your business hours, you can allow callers to dial a route or an
extension number when your business is open (day announcement), then
provide information such as business hours when your business is closed (night
announcement). If your business operates 24 hours a day, you can use just the
day announcement. Here are two examples:
Using Both Day and Night Announcements
ABC Company office hours are 8:30 a.m. to 5:00 p.m. Monday through Friday.
Callers who dial the company’s toll free number hear the day announcement
when the SPIRIT Attendant answers. The day announcement instructs callers to
enter a route number (1 through 9) to reach a specific department or an extension
number to contact a particular individual. Callers who call after 5:00 p.m. or on
the weekends hear the night announcement when the SPIRIT Attendant answers.
The night announcement provides the regular office hours and allows callers to
dial extension numbers to connect with employees who are working after hours.
Using the Day Announcement Only
XYZ Company has 24-hour sales and customer service departments. Callers on
lines answered by the SPIRIT Attendant hear the day announcement no matter
what time they call. The day announcement offers callers a choice between
entering the route number for sales (1) or for customer service (2).
Three types of call handling are available with the SPIRIT Attendant:
●
Immediate Call Handling (See Figure 1-1)
Immediate call handling can be setup so that the SPIRIT Attendant answers
these kinds of calls
—
All
incoming calls on
all
lines. The receptionist is required to help callers
who have a rotary telephone, or who need assistance, and to act as a
backup for the SPIRIT Attendant to answer calls if the SPIRIT Attendant is
busy.
—
All
incoming calls on
specified
lines.
●
Backup Call Handling (See Figure 1-1)
Calls are answered by the SPIRIT Attendant only when the receptionist is
unable to answer within a specified number of rings (4 to 10). To set the
number of rings, see “Call Processing Options” in Section 2, “Changing the
Current Settings.”
● After-Hours Call Handling
You can set the clock on the SPIRIT Attendant so that the night
announcement plays whenever you indicate that your business is closed.
After-hours callers can be given the option to dial a route number, an
extension number, or leave a message on an answering machine.
The SPIRIT Attendant
1-3
lines
SPIRIT
System
control unit
Receptionist
SPIRIT
Attendant
Call Transfer
Another option is to have the night announcement simply provide your
company’s normal operating hours and disconnect without giving callers the
opportunity to dial a route. Customers can dial an extension number while
this announcement is playing.
Central
office
Central
Office
lines
SPIRIT
System
control unit Receptionist
SPIRIT Overflow
Attendant SPIRIT Attendant Is Immediate Call
Handler - Calls ring immediately
at the SPIRIT Attendant If not -
answered within a specified number of
rings, calls will ring
at the receptionist.
SPIRIT Attendant is backup Call
Handler - Calls ring Immediately
at the reoeptionist If the receptionist
does not answer within a preset number
of rings, the SPIRIT Attendant answers
the call.
FIGURE 1-1 Immediate and Backup Call Handling.
In the SPIRIT system, all calls handled by the SPIRIT Attendant are blind
transfers. In a blind transfer, the SPIRIT system
control unit
monitors the call
after the SPIRIT Attendant transfers the caller to the route or extension number
dialed. If the extension number is invalid, the call is transferred to the
receptionist. If the call is unanswered after a specified number of rings, the call
returns to the SPIRIT Attendant and the caller can choose another route or
extension, such as the receptionist.
1-4
The SPIRIT Attendant
