Lumens VC-A50P Manuale utente

VC-A50P

Camera Upgrade

Installation Guide

Quick Installation Guide .................................. 2

Complete Installation Guide............................. 3

Camera Upgrade Installation Guide

Quick Installation Guide

Please read all instructions prior to attempting your NDI®|HX camera upgrade. Be advised that a

current Microsoft Windows®computer or device is required to complete the upgrade process.

Thank you for purchasing the NDI®|HX upgrade for your camera.

This installation guide will walk you through the steps to make your camera

immediately available as an NDI®source for all compatible systems, devices, and

software on your network.

Three Easy Steps

Step 1

Download & install the NDI®|HX driver

http://new.tk/NDITools

Note: NDI|HX driver is part of NDI Tools, a free suite of applications designed to introduce you to

the world of IP. Learn More at https://www.newtek.com/ndi/tools/

Step 2

Download camera firmware & update

•Ensure that both your Windows®computer or device and camera are connected to the same

local network via standard Ethernet cable.

•From your computer or device, open NewTek NDI®Studio Monitor (installed with your NDI®|HX

driver) and select your camera model from the upper-left menu. Then click “Upgrade” in the

bottom-right corner.

•From the dialog box, select “Download latest firmware” and then “Update firmware on Camera”

when download is complete.

Step 3

Enter your NDI®|HX license key & click “Enable NDI®|HX”

Note: NDI®|HX license key is available for purchase on store.newtek.com

Install the latest

NDI

HX driver

Update your

Camera Firmware

Enter your

NDI

HX License

Camera Upgrade Installation Guide

Complete Installation Guide-Windows

Download & install the NDI®|HX driver

•Follow this link to download your NDI®|HX driver from the NewTek website.

http://new.tk/NDITools

•Install the driver on your Windows®device.

Note: This will also install NewTek NDI®Studio Monitor

Update Your Camera Firmware & Upgrade to NDI®|HX

•With the NDI®|HX driver installed on your Windows®device, ensure that both your Windows®

device and camera are powered and connected to the same local network via standard

Ethernet cable.

If you are using a switch (without a router), you may need to manually configure the network

settings on your Windows®computer or device.

•From your Windows®computer or device, open the NewTek NDI®Studio Monitor application

(installed with your NDI®|HX driver) to finish the process.

•Click the menu icon in the upper-left corner to view all the available NDI®sources, then locate

and select your camera.

IMPORTANT: Your camera must be connected to the same local network as the

Windows®computer or device with your NDI®|HX driver installed to proceed.

Camera Upgrade Installation Guide

•With your camera selected, click on the UPGRADE button in the bottom-right corner of the

NewTek NDI®Studio Monitor window.

•After the dialog box opens, click on the 1a. button to download the latest firmware for your

camera. You will be redirected to the camera manufacturer’s website. Locate the proper

firmware for your camera and download it, along with any instructions for the firmware update.

Camera Upgrade Installation Guide

•With the firmware downloaded on your computer, click on the 1b. button. This will take you to

the camera’s web control page where you can finish the firmware update process following the

instructions from the camera manufacturer.

If you have already purchased a NDI®|HX license for your camera please skip the

following step.

•Once the firmware has been updated, click on the 2. button to purchase an NDI®|HX license for

your camera. You will be redirected to the NewTek Store to complete the purchase. Once the

transaction is complete, you will receive a confirmation email with the NDI®|HX license key

within a few minutes.

IMPORTANT: Please have the order confirmation email available or otherwise copy

the license key number for reference before you proceed.

Camera Upgrade Installation Guide

•Enter the license key for your camera that was included with the confirmation email in the

number 3. text box.

•Click on the 4. button to enable NDI®|HX on your camera.

Camera Upgrade Installation Guide

•Configure and control your camera using the on-screen user interface.

Once registered, you can use your camera over the network with any other NDI®-

compatible system, device, or software, performing the standard functions for

locating an NDI®source and designating for video input.

If you have additional cameras to upgrade, please repeat the steps in this

installation guide as required to enable NDI®|HX. A separate NDI®|HX license key

is required for each camera.

Camera Upgrade Installation Guide

Complete Installation Guide-OS X

Download & install the NDI®|HX driver

•Follow this link to download your NDI®|HX driver from the NewTek website.

http://new.tk/NDIHX-Driver-OSX

•Install the driver on your OS X device.

Update Your Camera Firmware & Upgrade to NDI®|HX

•With the NDI®|HX driver installed on your OS X device, ensure that both your OS X device and

camera are powered and connected to the same local network via standard Ethernet cable.

If you are using a switch (without a router), you may need to manually configure the network

settings on your OS X computer or device.

•From your OS X computer or device, open the NewTek NDI®Video Monitor application (install

link for NDI Video Monitor http://new.tk/NDIHX-Driver-OSX) to finish the process.

•Select "Register Device" from the Settings menu, as shown.

Camera Upgrade Installation Guide

•After the dialog box opens, click on the 1a. button to download the latest firmware for your

camera. You will be redirected to the camera manufacturer’s website. Locate the proper

firmware for your camera and download it, along with any instructions for the firmware update.

•With the firmware downloaded on your computer, click on the 1b. button. This will take you

to the camera’s web control page where you can finish the firmware update process

following the instructions from the camera manufacturer.

•Once the firmware has been updated, click on the 2. button to purchase an NDI®|HX license

for your camera. You will be redirected to the NewTek Store to complete the purchase. Once

the transaction is complete, you will receive a confirmation email with the NDI®|HX license

key within a few minutes.

•Enter the license key for your camera that was included with the confirmation email in the

number 3. text box.

•Click on the 4. button to enable NDI®|HX on your camera.

•Once registered, you can use your camera over the network with any other NDI® -compatible

system, device, or software, performing the standard functions for locating an NDI® source and

designating for video input.

•If you have additional cameras to upgrade, please repeat the steps in this installation guide as

required to enable NDI®|HX. A separate NDI®|HX license key is required for each camera.

Lumens is the registered trademark of Lumens Digital Optics Inc. Changes in specification or

design may be done without notification.
