Lumin LSP Istruzioni per il montaggio
LUMINSMART.COM
Installer
FAQ
Guide
VOLUME 1.0
Table of Contents
LUMINSMART.COM
INSTALLER FAQ GUIDE
LSP Installation Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mounting the LSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Wiring the LSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
LSP Registration Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Lumin Installation Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
i
LUMINSMART.COM
Mounting the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
Where should I mount my
LSP?
The LSP can be mounted below, above, to the left or to the right of the
existing circuit breaker panel. Approximately 17”x24” of clear space is
required to accommodate a LSP above or below a circuit breaker panel
and approximately 17”x17” of clear space is required to accommodate a
LSP on either side of a circuit breaker panel (NOTE: modifications to the
LSP’s conduit will be required in order to accommodate mounting the LSP
to the left or right of the circuit breaker panel).
Can I utilize junction boxes
or combiner boxes to help
facilitate the installation of
my LSP?
Yes, you can use junction boxes, combiner boxes, or additional hardware
as needed to help accommodate your LSP installation so long as each
component is utilized/installed in accordance with national, state and local
code requirements.
Is my LSP compatible with
surface and flush-mounted
circuit breaker panels?
Yes, the LSP can be installed with both surface mounted or flush mounted
circuit breaker panels. Most surface mounted installation will require
extension brackets for mounting, which are provided with your LSP.
Can I utilize junction boxes
or combiner boxes to help
facilitate the installation of
my LSP?
Yes, you can use junction boxes, combiner boxes, or additional hardware
as needed to help accommodate your LSP installation so long as each
component is utilized/installed in accordance with national, state and local
code requirements.
What tools/equipment will I
need?
The LSP comes with mounting hardware and mounting brackets (surface-
mount installations) but installers will need the following tools to complete
the installation process (mounting and wiring):
• Drill
• Manual knockout
• Wire stripper
• Wire nuts (for 6 AWG & 10 AWG wires)
• Screwdriver
• Tape measure
• Level
• Drywall saw (flush-mount installations)
Additional tools/equipment may be needed depending on the exact
installation scenario.
1
LUMINSMART.COM
Wiring the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
How do I install the LSP’s
Power Cable Harness?
Install the LSP’s Power Cable Harness by connecting the LSP’s white wire
labeled “Neutral” to the existing neutral bar in the electrical panel; then
connect the black LSP wire labeled “Line A” to a breaker located on phase
A of the electrical panel; and then connect the red LSP wire labeled “Line
B” to a breaker located on phase B of the electrical panel.
The LSP wires “Line A” and “Line B” can be connected to their respective
breakers via double-tapping the breaker or via a three-way wire nut or via
a new, unpopulated breaker if needed.
How do I connect my LSP to
the circuits in my circuit
breaker panel?
Select a circuit to connect to the LSP, turn it offand disconnect the load
with a screwdriver. Then select a LSP wire labeled “Line # A” and connect it
to the now vacant circuit breaker with a wire stripper and screwdriver.
Next select the LSP wire with the corresponding line number and ending
with B (labeled “Line # B”) and connect it to the disconnected load with a
wire stripper and wire nut.
Ensure a tight connection is made between the two wires. Once the
connection between the circuit and the LSP is completed you can turn the
circuit breaker back on. Repeat these steps until all desired circuits are
connected to the LSP.
Which circuits should I
connect to my LSP?
Please refer installer to Lumin’s Circuit Selection Guide:
https://lumin.app.box.com/folder/78148559938
Or Lumin’s YouTube video:
www.youtube.com/watch?v=Q5v9833zbWo&t=1s
Is the LSP only compatible
with a certain brand/type of
circuit breaker?
The LSP is compatible with all circuit breakers rated up to 60 amps,
regardless of the manufacturer or brand.
2
LUMINSMART.COM
Wiring the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
How do I install the LSP’s Grid
Voltage Detector (GVD)?
Extend the LSP wires labeled “Grid Neutral” (white) and “Grid Line” (black)
and land them in the ATS (supply side) via the appropriate connection (lug,
wire nut, line side tap, etc.).
If installing your LSP on a sub panel, then land the “Grid Neutral” and “Grid
Line” wires into the main circuit breaker panel via the appropriate
connection.
NOTE: For most Tesla Powerwall installations, Lumin recommends landing
the “Grid Neutral” and “Grid Line” wires in the Tesla Gateway via a din rail
and fuse holder (not provided) and then performing a line side tap on the
supply side line above/before the ATS.
How do I install the LSP’s
Current Transformers (CTs)?
Lumin’s larger 200A CTs are designed to be installed on the existing circuit
breaker panel’s main supply lines. Do this by connecting the CT labeled
“Line A CT” to the corresponding LSP wire labeled “Line A CT.” Connect the
CT labeled “Line B CT” to the corresponding LSP wire labeled “Line B CT.”
Attach the CT labeled “Line A CT” to phase A of the main supply line and
attach the CT labeled “Line B CT” to phase B of the main supply line.
Lumin’s smaller 50A CTs are designed to be installed on the PV
generation/output line. Connect the CT labeled “Aux B CT” to the
corresponding LSP wire labeled “Aux B CT.” Attach the CT labeled “Aux A
CT” to phase A of the PV generation/output line and attach the CT labeled
“Aux B CT” to phase B of the PV generation/output line. If no PV/solar
generation line is present then you can attach the auxiliary CTs to an
alternative line that adheres to the CTs 50 amp rating.
NOTE: Make sure that the marking “K” on the CT is facing toward the grid
side.
Can I modify the LSP’s
wires?
While certainly possible, Lumin does not recommend modifying the LSP’s
wires as doing so will void the product’s warranty and introduces the risk
of damaging sensitive internal components.
3
LUMINSMART.COM
Registering the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
How do I register/setup my
LSP?
To register/setup your LSP, please follow these four steps:
Step 1. Download the Lumin app from the Android or Apple app stores
Android: play.google.com/store/apps/details?id=com.luminsmart.morse
Apple: apps.apple.com/us/app/lumin-smart/id1472704942
Step 2. Open the Lumin app and create an account
Step 3. Once you’ve created a Lumin account click the “get started” button
Step 4. Follow the on-screen instructions to set up your LSP
Alternatively, if you are unable to download the Lumin app, you may
register your LSP by following our manual setup steps:
Step 1. Once your LSP is properly installed and is powered on, connect to
the LSP’s WiFi network using your computer, laptop, tablet or smartphone:
LSP Network Name: Lumin-[Unique ID] (ex. Lumin-888E8E333D)
LSP Network Password: luminpass
Step 2. Once connected to the LSP’s WiFi network, open an internet
browser and go to: http://192.168.11.1
Step 3. Once you’ve reached http://192.168.11.1 click the “Start Setup”
button to continue the account setup process
Step 4. Connect your LSP to the home’s WiFi network by selecting the
name of the local WiFi network from the dropdown menu (or manually
type it in) and entering the local WiFi network password
Step 5. Once your LSP is connected to the home’s WiFi network, make sure
your connecting device is connected to the home’s local WiFi network
Step 6. Enter an e-mail address and password to create a Lumin account
Step 7. Log into your newly created Lumin account
4
LUMINSMART.COM
Registering the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
How do I label my LSP lines/
circuits?
To label your LSP’s lines/circuits, log into your Lumin account and follow
these three steps:
Step 1: Tap the user icon in the upper corner of the screen and select
“settings”
Step 2: Scroll down to find “Configure Circuit Preferences” and select it
Step 3: Select the line/circuit you want to configure and follow on-screen
prompts
NOTE: dual pole circuits require two LSP lines that should be paired with
one another during the labeling process
How do I setup and enable
“off-grid mode?”
To enable “Off-grid Mode” please follow these five steps:
Step 1: Select the hamburger menu button in your Lumin account to open
the side menu
Step 2: Select “Modes and Schedules”
Step 3: Select “Off-Grid Mode” to configure it
Step 4: Toggle the switch in the upper left corner to turn on “Off-Grid
Mode”
Step 5: Select the circuits that you want to protect in a power outage
NOTE: make sure circuits that you wish to remain on/powered during an
outage are marked “Protected.” Circuits that you want to be automatically
shed during an outage should be left un-protected.
5
LUMINSMART.COM
Registering the LSP
INSTALLATION QUESTIONS
QUESTION ANSWER
How do I invite new users to
my Lumin account?
To share your Lumin account with others, log into your Lumin account and
follow these three steps:
Step 1: Tap the user icon in the upper corner of the screen and select
“Settings”
Step 2: Scroll down to find “Invite Users” and select it
Step 3: Enter the email address of the user you would like to invite
How do I change my Lumin
account password?
To change/reset your Lumin account password, log into your Lumin
account and follow these three steps:
Step 1: Tap the user icon in the upper corner of the screen and select
“Settings”
Step 2: Scroll down to find “Security” and select it
Step 3: Enter the current password along with the new password you want
to change it to
6
LUMINSMART.COM
Lumin Installation Support
INSTALLATION QUESTIONS
If you have additional questions about installing your LSP or you are
experiencing any issues during the installation or registration process, please
contact Lumin’s Customer Support Team:
Phone: 1-888-421-0616 (North America)
