Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt
in a safe and dry place for future reference. 19e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2019 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m a y not be i nc luded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 56267
IMPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic precautions should
always be followed including the following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS.
1. Do not use seasonal products outdoors
unless marked suitable for indoor
and outdoor use. When products are
used in outdoor applications, connect
the product to a Ground Fault Circuit
Interrupting (GFCI) outlet. If one
is not provided, contact a qualified
electrician for proper installation.
2. This seasonal use product is
not intended for permanent
installation or use.
3. Do not mount or place near gas or
electric heaters, fireplaces, candles
or other similar sources of heat.
4. Do not secure the wiring of the
product with staples or nails, or
place on sharp hooks or nails.
5. Do not let lamps rest on the
supply cord or on any wire.
6. Unplug the product when leaving
the house, when retiring for the
night, or if left unattended.
7. This is an electric product – not a
toy! To avoid risk of fire, burns,
personal injury and electric shock it
should not be played with or placed
where small children can reach it.
8. Do not use this product for
other than its intended use.
9. Do not hang ornaments or other
objects from cord, wire, or light string.
10. Do not close doors or windows on
the product or extension cords as this
may damage the wire insulation.
11. Do not cover the product with
cloth, paper or any material not
part of the product when in use.
12. This product is equipped with push-
in type lamps. Do not twist lamps.
13. This product employs overload
protection (fuse). A blown fuse indicates
an overload or short-circuit situation.
If the fuse blows, unplug the product
from the outlet. Also unplug any
additional strings or products that may
be attached to the product. Replace
the fuse as per the user servicing
instructions (follow product marking
for the proper fuse rating) and check
the product. If the replacement fuse
blows, a short-circuit may be present
and the product should be discarded.
14. Read and follow all instructions
that are on the product or
provided with the product.
CAUTION
1. To reduce the risk of electric shock,
use only with the power-supply
cord provided or with a cord set
intended for outdoor use.
2. Do not use a cracked, frayed,
or damaged cord. Inspect
the cord periodically.
3. Do not abuse cord. Do not carry
product by the cord or yank or pull
it to disconnect from the outlet.
Page 3For technical questions, please call 1-888-866-5797.Item 56267
4. Disconnect the product from
the outlet when not in use.
5. This seasonal product is not intended
for permanent installation. To reduce
the likelihood of excessive heat and
possible damage, use only decorative
lamp accessories packaged with this
product. Always unplug this product
before installing or replacing fuses.
6. To reduce the risk of fire
and electric shock:
a. Do not install on trees having
needles, leaves or branch
coverings of metal or materials
which look like metal.
b. Do not mount or support strings
in a manner that can cut or
damage wire insulation.
7. Risk of fire. This product does not
contain lamp shunts in order to allow the
product to operate if one lamp burns out.
Do not replace lamps with other than the
spare lamps provided with this product.
8. Do not operate with bulbs missing
from sockets, missing bulbs
should be replaced promptly.
SAVE THESE INSTRUCTIONS
Use and Care Instructions
1. When the product is placed on a
live tree, the tree should be well
maintained and fresh. Do not place
on live trees in which the needles
are brown or break off easily. Keep
the tree holder filled with water.
2. If the product is placed on a tree, the
tree should be well secured and stable.
3. Before using or reusing, inspect product
carefully. Discard any products that
have cut, damaged, or frayed wire
insulation or cords, cracks in the
lampholders or enclosures, loose
connections, or exposed copper wire.
4. When storing the product, carefully
remove the product from wherever it
is placed, including trees, branches,
or bushes, to avoid any undue
strain or stress on the product
conductors, connections, and wires.
5. When not in use, store neatly in a cool,
dry location protected from sunlight.
Page 4 For technical questions, please call 1-888-866-5797. Item 56267
User Servicing Instructions
Read the ENTIRE IMPORTANT SAFETY INSTRUCTIONS section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
Lamp Replacement
WARNING! REPLACE LAMPS ONLY WITH 12 VOLT, 0.96
WATT SPARE LAMPS PROVIDED WITH THIS PRODUCT. LIGHTING
STRING IS RATED 9.6 W (0.08 A) – DO NOT OVERLOAD. CONNECT OTHER
LIGHTING STRINGS OR DECORATIVE OUTFITS END-TO-END UP TO A
MAXIMUM OF 216 W (1.8 A) TOTAL. DO NOT TEST LIGHT SET WHILE IN
PACKAGING. THIS MAY BUILD UP EXCESS HEAT WHICH CAN CAUSE
A MELTDOWN OF THE PACKAGING MATERIAL AND CAUSE A FIRE.
1. Grasp plug and remove from the
receptacle or other outlet device.
Do not unplug by pulling on cord.
2. Remove the lampholder
from the decorative cover by
pulling it out of the cover.
3. Pull bulb and lamp base
straight out of lampholder.
4. Replace lamp with only 12 volt,
0.96 watt, regular brightness
lamp (provided with product).
5. Insert the lampholder back
into the decorative cover.
CAUTION! To reduce the risk of overheating
replace burned out lamps promptly.
Figure A below illustrates how to exchange
the lamp base on the new lamp with the
old one if the new lamp base does not fit.
Remove bulb
and base
from socket.
Push new
bulb and
base into
socket.
Straighten
bulb wires –
remove bulb
from base.
Insert wires on new bulb
into holes in base. Bend
wires up and to the sides.
Bulb
Bulb
Bulb
Wire
Bulb
Wire
Bulb
Wire
Base
Base Base
Socket
12 3 4
Bulb
Base
Socket
Figure A: Replacing Bulb in Lamp Base
Page 5For technical questions, please call 1-888-866-5797.Item 56267
Fuse Replacement
1. Grasp plug and remove from the
receptacle or other outlet device.
Do not unplug by pulling on cord.
2. Open fuse cover. Slide open
fuse access cover on top of
attachment plug towards blades.
3. Remove fuse carefully. Turn
fuseholder over to remove fuse.
4. Risk of fire. Replace fuse only with 3 A,
125 V fuse (provided with product).
5. Close fuse cover. Slide closed the fuse
access cover on top of attachment plug.
Caution: Risk of fire. Do not replace
attachment plug. Contains a safety device
(fuse) that should not be removed. Discard
product if the attachment plug is damaged.
Figure B: Safety Plug with Replaceable Fuse
Specifications
Electrical Rating 120 V, 60 Hz, 0.08 A, 9.6 W
Light Type 12 V, 0.96 W Push-In Lamp
Page 6 For technical questions, please call 1-888-866-5797. Item 56267
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS
LIST AND INSTALLATION DIAGRAM IN THIS DOCUMENT AS A REFERENCE
TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT
HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN
FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO
THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Parts List
Part Description Qty.
1 Light String 1
2 Spare Bulb 2
3 Spare Fuse 2
Note: Some parts are listed and shown
for illustration purposes only, and are not
available individually as replacement parts.
Page 7For technical questions, please call 1-888-866-5797.Item 56267
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high
quality and durability standards, and warrants to the original purchaser that this
product is free from defects in materials and workmanship for the period of 90 days
from the date of purchase. This warranty does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside
our facilities, criminal activity, improper installation, normal wear and tear, or to lack of
maintenance. We shall in no event be liable for death, injuries to persons or property,
or for incidental, contingent, special or consequential damages arising from the use
of our product. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation of exclusion may not apply to you. THIS
WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us
with transportation charges prepaid. Proof of purchase date and an explanation
of the complaint must accompany the merchandise. If our inspection verifies
the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you
with a replacement. We will return repaired products at our expense, but if we
determine there is no defect, or that the defect resulted from causes not within the
scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Indice
Altri manuali Luminar Outdoor Luce esterna
Luminar Outdoor
Luminar Outdoor 59266 Istruzioni per il montaggio
Luminar Outdoor
Luminar Outdoor 59810 Istruzioni per il montaggio
Luminar Outdoor
Luminar Outdoor 58219 Istruzioni per il montaggio
Luminar Outdoor
Luminar Outdoor 56521 Istruzioni per il montaggio
Luminar Outdoor
Luminar Outdoor 58225 Istruzioni per il montaggio
Luminar Outdoor
Luminar Outdoor 59268 Manuale utente
Luminar Outdoor
Luminar Outdoor 59269 Istruzioni per il montaggio
Manuali Luce esterna popolari di altre marche
Lindby
Lindby 9949029 Manuale utente
HEPER
HEPER DOGO Side LW6048.585-US Istruzioni per l'installazione e il funzionamento
HEPER
HEPER LW8034.003-US Istruzioni per l'installazione e il funzionamento
Maretti
Maretti VIBE S 14.6080.04.A Manuale utente
BEGA
BEGA 84 253 Manuale
HEPER
HEPER MINIMO Istruzioni per l'installazione e il funzionamento
LIGMAN
LIGMAN BAMBOO 3 Manuale utente
Maretti
Maretti TUBE CUBE WALL 14.4998.04 Manuale utente
Maxim Lighting
Maxim Lighting Carriage House VX 40428WGOB Manuale utente
urban ambiance
urban ambiance UQL1273 Manuale utente
TotalPond
TotalPond 52238 Manuale utente
Donner & Blitzen
Donner & Blitzen 0-02661479-2 Manuale utente
