USER MANUAL
Rechargeable LED Lantern
With Diffused Lens
LP1513
Operation Instructions
14725 S Porter Rockwell Blvd Ste C
Bluffdale,UT 84065
luxpro.com
866.553.8886
Charging Instructions
Dual battery design
Rugged-durable rubber design
Diused lens
360° LED technology
Power bank to charge other devices
Variable on/o brightness dial
IPX4 waterproof rating
Features
On/O: Turn the dial on the front of the lantern clockwise to turn
the light on. Turn the dial counterclockwise completely to turn the
light o. There will be an audible click when turned on or o.
Adjust Brightness: Rotate the dial clockwise to increase the
brightness, and counterclockwise to decrease the brightness.
High
High
ANSI/PLATO FL1 STANDARD
942 lm
878 lm
LUMENSMODES
3h 15m
1h 45m
RUN TIME
30m
30m
Low 62 lm 8m
BEAM
DISTANCE
Low 64 lm 155h 30m 6m
11h
10650, 3.7V 2000mAh Rechargeable Battery
Internal Battery & 3 C Cell Batteries*
USB
Rechargeable 3C
Batteries
Not Included
While the lantern is on, it will not charge other devices. If the
lantern is turned on while charging a device, it will stop charging
the device until the light is turned o.
ANSI/PLATO FL1 STANDARD
Charging Product:
The LP1513 uses a Li-poly: 3.7V
2000 mAh rechargeable battery.
To charge the lantern, locate the
USB dust cover below the power
dial. Lift the cover to expose the
two charging ports.
The lantern will turn on and can be used while charging.
The LP1513 has a charge time of approximately 3 hours.
A red LED light in the charge port will light up to indicate the
lantern is charging. The light is fully charged once the light turns
green.
Charging Other Devices:
The LP1513 can also be used as a power bank to charge other
devices.
To use as a power bank, plug the large end of your charging cable
into the larger USB port on the right, and plug the opposite end of
the cable into your electronic device.
3
Plug the supplied USB cable into the smaller USB port on the left.
Plug the opposite end of the cable into a USB power source.
