luxvision HE-4000 Manuale utente
Notication
Dear Users,
Thank you for your purchase of HE 4000 Hand Edger Manual. Please take time to
read our user’s manual carefully before use.
This guarantees you to make full use of this unit and prolongs the operation life of
this unit.
Precautions
If you have detected abnormal heat, smoke, noise or smell, immediately stop using
the product.
In the event of an abnormality, turn off the power and disconnect the power plug from
the power socket. Continuing to use the product may result in electric shock or re.
Observe the instructions given below regarding the power cable:
• Be sure to use the supplied or specied power cable.
• Do not modify, forcibly bend, kink or pull the power cable.
• When disconnecting the power cable from the AC outlet, be sure to hold the cable
by the plug.
Pulling the cable may cause wire breakage or shot circuit, resulting in re or electric
shock.
• Do not connect or disconnect the plug of the power cable to/from the AC outlet
using wet hands.
Doing so may result in electric shock.
• Do not touch the product with wet hands while the power cable is connected
to the AC outlet.
Doing so may result in electric shock.
• If the product will not be used for a long period, disconnect the power cable
from the power source. Leaving the cable connected to the power socket for
a prolonged period will consume electricity and may result in heating.
1. Name of Parts
Diamond Wheel Protecting - cover
Motor Exhaust Net
Diamond Wheel
Water Tank Case
Switch and Safe Railing
Drawer Type Water Tank
Fixed button of safe railing Water - supply system - water pump
2. Operation
1. Pull out the xed button of
safe railing
2. Lift the safe railing
3
3. Remove the water tank case 4. Pull out the water tank
5. Remove the water pump
of the water - supply system,
pure into clean water to the
highest water level.
6. Close the water tank and
cover the water lank ease.
Put down the safe railing. It
can he used as soon as turn
on the power switch.
4
3. Specications
Specications
Dimensions (L x W x H) Net Weight
435 x 315 x 315 9kg
Power Requirement
100-120V/60Hz AC or
200-240V/50Hz AC 120W
5
LUXVISION is not responsible or liable for indirect, special or consequential damages arising out of or in
connection with the use or performance of the product or damages with respect to any economic loss,
loss of property, loss of revenues or prots, loss of enjoyment or use, costs of removal or installation or
other consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation
of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
Every effort has been made to ensure the accuracy of this manual. However, LUXVISION, makes no
warranties with respect to the documentation and disclaims any implied warranties of merchantability
and tness for a particular purpose. LUXVISION, Inc. shall not be liable for any errors or for incidental or
consequential damages in connection with the furnishing, performance, or use of this manual or the examples
herein. The information in this document is subject to change without notice.
6
