M-Elec Blind Snake Manuale utente

For2.5mmcable,

removetheinsertin

thecentre,placethe

cableintothechannel

andpushitdownso

itʼscompletelyﬂat.

For1.5mmcable

placethecable¹into

thechanneland

pushitdownsoitʼs

completelyﬂat.

OPTIONAL

INSTALLATION GUIDE

Turn over for termination and unlocking guide

¹NOTE:forpolarity,ensurethe

Active/Lineconductorisaligned

withtheredmark.Thiscanbe

achievedbynickingasmallpart

oftheinsulationoﬀthecable

outersheath. N E L

TPS2C+E

ﬂatcable

Placethecoverontop

ofthemainbodyand

pressthepinsﬁrmly

intotheguides.

Slidethecover

backuntilyou

canremoveit

completely.

Slidethecover

closeduntilyou

hearaʻclickʼ

soundforasafe

andsecure

termination.

Strip15mmofthe

outercableinsulation

exposingtheinner

insulatedwires.

Insertactive,

earthandneutral

insulatedcables

intotheslotson

theterminator

block.

Cliptheterminator

blockinthetop

endofthechannel

ensuringthecable

issittingﬂatinthe

channel.

Please refer to M-Elec website (melec.com.au) for information on

the warranty period of each product. Each of our product

warranties is separate and subject to the following terms and

conditions:

• M-Elec products must be properly installed by a qualiﬁed

electrician and in accordance with any relevant guidelines, codes,

and standards. This includes wiring and connection to proper

approved components and product working environments.

• This warranty is void and does not apply to products that fail as a

result of neglect, mistake misuse, alteration, or that is

improperly installed and implemented. This includes but is not

limited to: improper wiring, installation under improper and

non-approved operating environments such as temperature,

humidity, corrosion or voltage conditions; improper installation

using components that are not approved or are not M-Elec

manufactured products.

• It is the responsibility of the purchaser to obtain all necessary

approvals and to understand the products intended use and all

relevant instructions, recommendations, and guidelines for the

proper installation and use of any M-Elec products and related

‘manufactured products’ used in conjunction with same.

• M-Elec is not liable for the accuracy and completeness of any

statements, technical information and recommendations in any

form of product literature or instructions are not guaranteed,

and are not part of this warranty, and does not in any way

constitute a warranty. The purchaser is solely responsible for

determining suitability of the M-Elec products for installation

and full implementation must determine potential applications

and installations independently.

• Warranty is void if products have been altered, opened/modiﬁed

in any way that is outside the bounds of normal electrical work.

• To make a claim on any of M-Elec’s products, you must do so

within 14 days from the day of receipt (from place of purchase)

please read our returns policy for further information

(melec.com.au/returns-policy) and deliver the transformer to

M-Elec (at your cost) to Head Oﬃce. M-Elec will assess the

warranty claim by conducting electrical tests, and visual and

microscopic inspection to make sure there is no visible physical

damage. If M-Elec grants the warranty claim, we will replace the

product or refund your money, at our election.

• M-Elec is not responsible or liable for any injuries, damages, or

death caused by the use, misuse or failure of products purchased

from us.

• This warranty is in addition to any other rights the consumer may

have under the Australian Consumer Law.

To the fullest extent permied by law, no warranties other than

those described above are given in respect of M-Elec products.

M-Elec’s liability is limited, to the fullest extent permied bylaw,

to the refund or replacement of the M-Elec products. We

expressly do not warrant that an M-Elec product will last any

particular length of time nor guarantee is made as to ﬁtness to a

particular application, since we have no control of the electrical

supply or circuits.

M-Elec goods come with guarantees that cannot be excluded

under the Australian Consumer Law. You are entitled to a

replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage. You are also

entitled to have the goods repaired or replaced if the goods fail to

be of acceptable quality and the failure does not amount to a

major failure.

ALL RETURNS MUST BE RETURNED TO:

M-ELEC HEAD OFFICE

10 Technology Drive, Warana Qld 4575

Please read our returns policy procedure for further information

on M-Elec website melec.com.au/returns-policy or request it via

phone (07) 5438 8535 from our customer care consultants.

Warranty Disclaimer

1 Year Warranty TERMINATION GUIDE - OPTIONAL

UNLOCKING GUIDE

Placethecoveron

topofthemain

bodyandpressthe

pinsﬁrmlyintothe

guides.

ML-BS-PB
