Envy Quick Start Guide

Revision 1.0

Envy Quick Start Guide

1. Introduction

Congratulations on the purchase of your madVR Envy! The Envy is the result of over elevent

years of extensive R&D. It is the first and only video processor to provide patent-pending AI and

other advanced algorithms for real-time video, delivering a picture quality unlike anything else.

We hope you find watching movies with it as incredibly addicting as we and many others do.

Although Envy works right out of the box, this guide will help you get the most out of it. For the

best experience, please review it in full, before getting started.

2. Initial Set Up

The following is an overview for getting up and running quickly.

2.1. Unpack and connect the Envy: Your shipment contains the Envy, remote control with

batteries, remote control RF antenna dongle and a power cord (USA shipments only).

Please save the original box and packing materials in case your Envy needs services or

upgrades in the future. Review the rear panel as shown in Appendix A. Connect your

HDMI in and out, and power cord. Turn Envy on by pressing the button on the front

panel and enjoy it right out of the box!

2.2. Proper ventilation: Caution: When performing upscaling such as 1080p60 to 4K60, or

with other advanced algorithms that may be added in the future, the Envy (particularly

the Extreme version) can get “hot to the touch” in the middle of the lid and expels hot

air from the rear and top vents. Please ensure proper ventilation before use. For

important information on ventilation, see Appendix C.

2.3. Remote control: Review Appendix B for an overview of the remote-control functions.

The remote supports both RF (default) and IR. Both the RF and IR dongles are pre-

installed, as shown in Appendix A.

To put the remote into RF mode (default): Press and hold the OK button, and

while still holding it, press and hold the top left button (Power) for 3 seconds,

until the LED light on the remote blinks 3 times. Your remote control is already

set to RF mode by default. For proper operation keep the RF dongle at 180

degrees (please do not set it in the 45 or 90-degree position).

To put the remote into IR mode: Press and hold the OK button, and while still

holding it, press and hold the top right button (Menu button) for 3 seconds, until

the LED light on the remote blinks 3 times. Note: After changing batteries it will

be necessary to set the remote back into IR mode.

You cannot use both RF and IR commands at the same time. For instance, you may want

to learn the Envy IR commands into a universal remote, while also keeping the Envy

remote around for greater convenience and range using RF. If learning the IR codes, first

put the remote control into IR mode and learn the codes to your other remote. Then

optionally you can switch it back to RF, and both your universal remote and the Envy

remote will continue to function with the Envy.

We recommend using the Envy remote control in RF mode, since it does not require line

of sight. If you use IR mode and need better line of sight, plug the IR dongle into a USB

extension cable and route it under the unit to the front, where it can be easily hidden.

To customize the functions of the remote buttons, click the top right button of the

remote and press the right arrow until you reach the Remote Configuration Menu.

If you do not plan to use IR with your Envy, we highly recommend that you leave the IR

dongle plugged into the Envy so that it does not get lose if needed in the future.

Likewise, we have plans to use this IR dongle for other purposes in the future.

3. General Operation

This section covers general setup and operation of the Envy.

3.1. Menus: The Envy menus consist of several menu pages grouped by function. The

menu pages are organized into “Configuration”, “Settings”and “Information”

menus. The Configuration menus is where you setup options which typically you

will not want to adjust on a regular basis. For example, your as your preferred

output resolution, peak luminance, and preferred color space is not something you

will regularly change.

The Settings menus, on the other hand, is typically where you will find options that

you may want to change occasionally, to suit your mood, viewing conditions or

tastes for a particular movie. Examples include your preferences for HDR

processing, upscaling, artifact reduction, sharpening and more.

The Information menu shows information about your incoming and outgoing signal,

the display device, and system information such as your model type and serial

number. For security purposes, never share your serial number, except with your

dealer or madVR Labs. There is also a Test Patterns menu and Profile menu.

Tip: The Envy menu system uses a very flexible and intuitive profile system that

makes it easy to save and apply different settings for different purposes (settings

management). A discussion of the profile system is beyond the scope of this guide.

An understanding of how profiles work is especially important prior to using your

Envy. Therefore, we highly recommend you read the Introduction to Profiles

document available at www.madvrenvy.com.

3.2. Front-panel: The front panel is as intuitive as the Envy itself. The LED lights blue when the

unit is on, lights red to indicate disk activity, slowly pulsates between blue and off when in

standby, and is off when the Envy is powered off. You can control the brightness of the LED

(or turn it off) using the wheel at the bottom edge of the front panel. To find the wheel,

place your finger on the LED and move it down to the bottom edge of the case. To turn the

unit on and off, press the power button (or use the remote). Should you ever wish to

unplug the Envy, first press the power button, and wait a few seconds until the LED turns

off. Never turn off your Envy by pulling the power plug while it is still on or by turning off

the power supply switch on the rear of the unit.

3.3. Check output resolution: Some projectors and displays do not report their native resolution

properly. For instance, JVC e-shift 4K projectors report a native resolution of 1080p instead

of 3840x2160. And some native 4096x2160 projectors may report 3840x2160. To override

this if necessary, press the top right button on the remote to quickly access the Display

Configuration menu, and change to the desired resolution.

3.4. Set your peak luminance: For optimal results, the Envy needs to know your peak

luminance. This is set in the Display Configuration menu. If using a scoped screen

with the lens zoom method (no A-lens) set the “Peak luminance (scoped)”value to

the peak nits when zoomed out for scoped movies. If you use lens zoom to change

between 16:9 and scoped zoom, please use profiles (see Section 3.1) to set the

different peak brightness for each setup. To get your peak luminance, use a

calibration software product to read your cd/m2 value off the screen when

displaying a full field 100% white pattern. Or measure your lux with a light meter

and convert to cd/m2. If unsure, please contact your dealer for assistance.

3.5. Anamorphic lens setup: If using an A-lens, press the top right button on the remote

and press the right arrow to reach the Screen Configuration Menu. Enter your

anamorphic stretch factor (e.g., 1.25x for a Panamorph DCR lens) if using an A-lens

and be sure to turn off anamorphic stretch if already enabled in your projector. If

not using an A-lens you can safely ignore this section.

3.6. Scope screen setup: Scoped screens are screens that have an aspect ratio wider

than 16:9. For instance 2.0:1 or 2.35:1. If you have a scoped screen and are not using

an anamorphic, you need to “teach”Envy about your screen so that it can manage

all black bars and place subtitles for you where you can see them (otherwise they

will be off the screen).

To enable black bar detection and management, set the Envy Screen Boundaries

menu item to Custom, display 2.40 content and adjust your projector lens so that

the image fits your screen perfectly side to side. Then display 16:9 content and

adjust the Top and Bottom values under Screen Boundaries so that the image fits

within the height of your screen –this will enable the Envy’s automatic black bar

detection. For users with scoped screens and no A-lens, this feature is very

convenient, as it will automatically fit 16:9 content to your screen without cropping,

while showing scoped content at full screen (especially great when switching back

and forth from movies and a 16:9 movie selection / poster wall screen). It will also

do some pretty amazing things for managing your subtitles (see the Black Bar

Configuration menu on your Envy for more).

3.7. Audio delay adjustment (if necessary): If your AVR/AVP is set up for auto lip sync

adjustment, Envy will automatically adjust the audio delay as needed. If you should

find that you still need small adjustment despite using auto lip sync, you can do so in

the Envy HDMI Configuration menu (Menu button, then right-arrow until you see

this menu). If you are not using auto-lip sync, you will need to adjust your AVR/AVP

accordingly. In which case note that the video processing in Envy adds roughly

175ms delay to the audio. Therefore, please adjust the audio delay in your audio

processor accordingly (only if not using auto lip sync). If you have an AVP that adds

its own processing delay, such as a Trinnov or Storm Audio, subtract its audio delay

from the 175ms (for instance if your AVP has an audio delay of 50ms, set you’re the

audio delay to 175 - 50 = 125ms). If you have the movie Ready Player One, a great

clip to adjust audio delay is the car race scene around the 10-minute mark of the

movie. A flare that is launched in an arch-like fashion, with a whistling sound as it

nears the ground, and then explodes like a firework. Likewise, many test discs have

lip sync patterns. You likely will have to adjust the source for each of your audio

processors HDMI inputs if not using auto lip-sync.

3.8. Pass-thru port: Envy features a near-zero latency pass-thru port perfect for gaming.

You can run an HDMI cable from this port directly to another input on your display.

Or alternatively if you wish to have just one cable run to your display - you can use a

device like the HD Fury Maestro and run a short cable from each Envy HDMI output

(regular and pass-thru) to the Maestro, and then run the single main HDMI cable

from your display to the Maestro. See Appendix A for the location of the pass-thru

port.

3.9. Popular Envy Tweaks: The default settings in the Envy deliver an outstanding

image. However, you may wish to change the settings to taste and to enable certain

features, like how you want subtitles handled. Please play around in Settings to see

what you like best. Note that the settings will be temporary until you save them to

your Base Settings or to a profile –for more information see the note about profiles

in Section 3.1. Popular tweaks include:

HDR Settings (first page in the Permanent and Temporary Settings menu):

Highlight Recovery (try at “Insane”), Contrast Recovery (try at High), Shadow

Detail Recovery (try various settings), Brightness Preference tweaks (raising this

means you want the overall picture to be brighter but leaves less room for HDR

highlights and lowering this means you want the overall picture to be darker but

leaves more room for HDR highlights).

Upscaling and Sharpening (also in the Permanent and Temporary Settings

menu): Did you know that the Envy can add very tasteful, artifact-free and

ringing-free sharpening, even to 4K sources? Try adding some Crisp Edges, Edge

Enhancement and Detail Enhancement and see what you think!

Subtitle and OSD handling: Subtitles and On-Screen Display (OSD) elements

from your source devices are problematic for users with scoped screens.

Especially since the black bar areas where subtitles and OSD elements are often

displayed is normally zoomed off the screen by your lens setting! Envy will bring

your black bars back, temporarily as needed, for you to see the subtitles and

OSD. There are lots of options such as how long you want the black bar area to

stick around after subtitles disappear, and more. See the Black Bar Configuration

menu in your Envy for more information.

3.10. Show off your Envy! What fun would the Envy be without the ability to show

yourself and others just why you bought the world’s most advance video processor

in the first place? We are so proud of the power of the Envy and the huge benefit it

provides that we added features exactly for this purpose. Here’s how to use a few

of them:

Dynamic Tone Mapping (green button): With HDR content, click the green

button on your remote to toggle the Envy’s DTM on and off. When toggled off,

the Envy will turn off its DTM and output the content as HDR to your display,

which will then turn on its own HDR tone mapping, so you can easily compare

the difference. Be prepared for what you are about to see –behold the magic

power of the Envy.

Highlight Recovery (blue button): With HDR content, click the blue button to

toggle Highlight Recovery on and off. This comparison is best done with content

paused on your screen. The differences will not be visible in all scenes and with

all content, so you may have to play around to find the right scene to do the

comparison with. Look for content that has bright highlights with texture detail

and view that with this feature on and off. One example of a great scene to

compare this is the bright yellow flower on the Spears and Munsil HDR

Benchmark 4K Blu-ray demo disc. Also try this after choosing a higher strength

Highlight Recovery setting in the Permanent and Temporary settings (have we

mentioned there is an “insane” mode?).

Contrast Recovery (yellow button): With HDR content, click the yellow button to

toggle Contrast Recovery on and off. You will find that with this feature on, the

content has a considerable amount of added depth and perceived contrast. And

with this feature off the image looks a bit murky, with a thin milky-like layer. Try

this with Contrast Recovery set to High as well.

3.11. Auto-updates: Your Envy makes it very easy to install new versions of the Envy

firmware with a simple click of your remote using the Firmware Configuration

menu. To access the auto-update options, click the top-right button on your remote

and press the left-arrow. The following describes the menu items in detail:

Current Firmware Version: This displays the firmware version currently in use.

This information can also be found on the System Information menu.

Built Type: This option sets the minimum type of firmware you wish to be

notified about. Options are: Stable Builds only, Release Candidates, Beta Builds,

and Test Builds. For instance, if you select Beta Builds you will be notified about

all firmware except Test Builds. With all the ongoing development we

recommend Beta Builds for most users. Test Builds should be considered highly

experimental. When deemed by madVR Labs to be more stable, they are

promoted to Beta Builds, and so forth up to Stable Builds.

Notification Type: When an update is available, a popup notification will be

displayed according to your preferences. Options are Always, If Menu Is Open,

and Never.

Install Firmware: To install a firmware version, move to the “Install Firmware”

line and use the left/right arrows to select ay version, then select OK, and Install.

You can select any version, including past versions. This makes it easy to

experiment with Test Builds or Beta Builds, for example, since you can always

rollback the update just as easily. All updates are self-contained, so for instance

if you are on 1.1.0.4 you can install 1.1.0.9 directly, without installing versions in

between. Some updates may require that your Envy be powered off and then

back on –if so, you will be prompted to do so.

Changelog: The changelog provides details about what new features, fixes and

enhancements are included in the update selected in the Install Firmware line.

You can browse through each versions changelog simply by highlight it in the

Install Firmware selection.

3.12. 3D LUT Calibration: The madVR Envy supports 3D LUT calibration with many

popular calibration software packages, including ColourSpace, Calman, and

DisplayCal. Calibration guides are available for download from

www.madvrenvy.com.

4. Troubleshooting

4.1. Remote does not work: Did you insert batteries? If wanting to use RF, make sure

the black RF antenna dongle is installed in the USB port as shown in Appendix A. If

RF is still not working, see Section 2.3 to ensure it is in RF mode. If so, try removing

the antenna for 2 seconds and plug it right back into the same spot. If using IR,

make sure the remote is in IR mode, and that the IR dongle in the rear of the unit

has line of sight to your remote, or use an extension cable as described in Section

2.3. If neither of these helps, see item 4.2 below.

4.2. Envy appears to be doing nothing: Make sure you inserted the HDMI input into the

bottom port as shown in Appendix A. If you installed it into the top port, that is the

pass-thru port, and Envy will not apply any processing and the remote will appear

not to work.

4.3. Envy is outputting 1080p instead of 4K: Make sure you are not inadvertently

pressing and holding the red button on the remote –doing so forces the Envy to

output 1080p, which is useful in the event you ask it to output a resolution which

your display does not support.

4.4. Envy does not power on: Check the power supply switch and make sure the “circle”

side of the switch is up in the air (“line” is pressed down), as pictured in Appendix A.

4.5. Green flashes: You may notice a full screen green flash or two during HDMI signal

changes / handshaking in some situations. In the Display Output mode use RGB if

using YUV. Or if using YUV, choose Slow and Clean Handshakes in the Envy HDMI

Configuration menu.

4.6. Audio delay: Envy adds audio delay as part of its processing. Please see Section 3.7

for information about setting the audio delay.

4.7. Something else? Please contact your authorized Envy dealer for assistance.

We hope you enjoy your Envy as much as we enjoyed making it for

you! Thank you.

Appendix A –Envy Rear Panel Connections

Altri manuali per Envy

Indice

Altri manuali madVR Convertitore multimediale

madVR

madVR Envy Manuale utente

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
