Magellan 800 Manuale utente

CMY

M-Nav 800_Quick Start Guide_P.pdf 1 11/3/11 3:59 PM

Navman Wireless.fm Page 2 Monday, November 7, 2011 11:18 AM

M-Nav 800 English

This Magellan receiver is a vehicle-navigation aid designed to

assist you in arriving to your selected destinations. When using

this Magellan product, these safety rules must be followed to

prevent accidents that can result in injury or death to yourself or

others:

• Please check with your state or local law enforcement for

applicable regulations regarding mounting to the windshield.

• When driving, the need to view the display is minimal. Voice

prompts will guide you to your destination. The driver should

enter data or program the Magellan receiver only when the

vehicle is stopped. Only a vehicle passenger should enter

data or program the receiver while the vehicle is moving.

• It is your responsibility to comply with all traffic laws.

• Every attempt is made to ensure that the database is

accurate. However, roadways, points of interest (POIs), and

business and service locations may change over time. The

database does not include, analyze, process, consider, or

reflect any of the following: legal restrictions (such as

vehicular type, weight, height, width, load and speed

restrictions); road slope or grade; bridge height, width,

weight, or other limits; population density; neighborhood

quality or safety; availability or proximity of law enforcement,

emergency rescue, medical, or other assistance;

construction work zones or hazards; road or lane closures;

road, traffic, or traffic facilities’ safety or condition; weather

conditions; pavement characteristics or conditions; special

events; traffic congestion. It is your responsibility to

disregard any unsafe, hazardous, or illegal route

suggestions.

Navman Wireless.fm Page 3 Monday, November 7, 2011 11:18 AM

• Keep the receiver safe from extreme temperature conditions.

For example, do not leave it exposed to direct sunlight for an

extended period of time. The maximum operating

temperature is 140°F (60°C).

• Take care when mounting the receiver in your vehicle,

whether using the windshield mount or other mount or

accessories, that it does not obstruct the driver's view of the

road, interfere with the operation of the vehicle's safety

devices such as air bags, or present a hazard to occupants

of the vehicle should the receiver be dislodged while driving.

You assume the risks associated with damage to your

vehicle or vehicle occupants as the result of your choices in

mounting the receiver.

• The battery is rechargeable and should not be removed.

Navman Wireless.fm Page 4 Monday, November 7, 2011 11:18 AM

Installation

Choose a Location. The Magellan RoadMate receiver needs a clear

view of the sky to receive signals from the GPS satellites so choose a

location with an unobstructed view of the sky, commonly on or near the

windshield.

Clean the Surface. Clean the area on the windshield and allow the

surface to dry before attaching the mount.

Attach the Car Cradle. Pivot the cradle up from the bottom of the

receiver. To permanently attached the receiver to the cradle use the two

small 5.5mm x 10mm screws to attach the cradle to the receiver. If you

want to be able remove the receiver for security purposes, do not use

the two screws to attach the cradle to the receiver. Use the four 7mm x

12mm screws to attach the pivot plate to the cradle.

Attach the Receiver Assembly to

the Mount. The ball end of the

mount snaps into the pivot plate that

was just attached. Use the tightening

ring to secure the receiver assembly

to the mount but do not tighten firmly

yet. After the entire assembly is

attached to the windshield you will

want to adjust the position of the

receiver for optimum viewing.

After the mount and the receiver are

assembled, place the suction cup of

the mount firmly against the area it is to be attached to and push the

mounting lever towards the base of the mount.

When the assembly is attached to the windshield, you can use the pivot

point on the arm of the mount or the pivot ring on the back of the cradle

to adjust the receiver for optimum viewing.

Navman Wireless.fm Page 5 Monday, November 7, 2011 11:18 AM

Attach the DB-9 Power Cable.

The DB-9 cable connects the receiver

to the Navman Wireless assembly.

Attach the DB-9 connector to the

receiver cradle and RJ45 to the

Navman Wireless Power/Serial

Module.

The additional connector is used

to connect to an external antenna

(not included) to receive traffic information.

Magellan RoadMate

Power On

Press and hold the power button 2 - 3 seconds to turn the receiver on or

off. Press and hold the power button for more then 5 seconds to reset

the receiver should you have a problem with the receiver and are

instructed to reset the receiver.

The first time you use the Magellan RoadMate it may take up to 4

minutes to compute your location under normal conditions. With

adverse conditions (not having a clear view of the sky) the time to

compute your location the first time can greatly increase.

A - Power Button

B - Micro-SD slot

(under protective

cover)

C - Mini USB for

optional power or

connecting to a PC

Navman Wireless.fm Page 6 Friday, November 18, 2011 9:38 AM

If you are not getting your current location, use these tips to improve

satellite signal reception.

Leave the garage or parking structure so the GPS receiver has a

clear view of the sky.

Satellite signals can be blocked by tall buildings, trees or

mountains. You may intermittently see a drop in signal strength

in these types of environments.

Pairing Bluetooth®

The instructions shown here are for pairing a phone during normal use.

The first time you use Bluetooth in your Magellan RoadMate receiver,

the receiver will automatically ask you if you want to pair a phone.

After selecting Yes the receiver is in pairing mode. Follow the

instructions in your phone manual to set it in pairing mode. After the

phone has searched for new devices, select “Magellan Roadmate” from

the list.

Your phone will ask for a passcode. Enter ‘1234’.

Tap Yes on the Magellan RoadMate.

A screen will confirm the successful pairing.

Navman Wireless.fm Page 7 Monday, November 7, 2011 11:18 AM

Battery

The Magellan RoadMate receiver has an internal battery that is charged

when it is being powered by the Navman Wireless device. It is

estimated that a receiver can operate for 2 hours from a fully charged

battery.

To view the battery strength indicator, access the Main menu. The

battery strength is shown below the signal strength indicator.

It can take up to 4 hours to fully charge the battery, depending on the

battery level. However, the battery does not need to be fully charged to

use the Magellan RoadMate receiver.

Traffic Notice

Traffic notifications are available as an optional service and require

connection to an FM antenna (not included).

Satellite Signal Strength

To view the satellite signal strength indicator, tap on the Menu button

while viewing the Map screen. The signal strength indicator can be

found in the upper right corner.

4 bars green:

Strong signal

Blank: No satellite

signals. Unable to

compute position.

Navman Wireless.fm Page 8 Monday, November 7, 2011 11:18 AM

Map Screen while Routing

ADisplays next turn instruction, distance until turn and street

for next maneuver. Tap to repeat last instruction.

BSpeed warning.

C(Optional Service) Traffic icon with the route delay time if

traffic warnings appear on route. (Requires FM antenna not

included.)

DDisplays ETA (estimated time of arrival). Tap to select

distance to destination, arrival time, speed or time

remaining in the route.

EZoom Out/In

FAccess Main Menu

GPress to display POIs found on next few highway exits.

(Displayed only while traveling on a highway.)

HAccess Volume/Mute and Brightness Controls

IAccess Bluetooth

JAccess OneTouch Menu

KCurrent Position Icon

Navman Wireless.fm Page 9 Monday, November 7, 2011 11:18 AM

Main Menu. Tap on the MENU button on the Map screen to access the

Main Menu.

Access your

Address Book.

Create a route

to an address.

Create a route to a

point of interest.

Access User Setting

options.

View Map

screen.

Create a route

to a street

intersection.

Vehicle Profile.

Create a route

to nearby

emergency

centers.

Additionally if

Routing:

Cancel Trip.

Detour. Turn List.

Edit the Trip.

Create a multileg

route.

Create a route

to a previous

destination.

Access

wireless

information

Navman Wireless.fm Page 10 Tuesday, November 8, 2011 9:37 AM
