MAGIMIX LE MINI Manuale utente
RECIPE BOOK
INSTRUCTIONS FOR USE
Le Mini
1
The Product 2
Standard accessories 3
Fitting the bowl 4
Fitting the accessories 5
Removing the bowls and accessories 7
Using the citrus press 8
Cleaning 9
How to work the MAGIMIX 10
Fundamental rules 11
Le Mini & Le Mini Plus 14
How to use the bowls: examples 15
How to use the discs: examples 16
Index to recipes 17
How to follow the recipes 20
Before using your appliance 80
ELECTRICAL INSTRUCTIONS
The warning regarding the fitting of a plug is applicable for UK only.
WARNING: Always replace the fuse cover of the fitted plug, never use the plug with the fuse
cover omitted. If a replacement fuse cover is required, ensure it is the same as the one visible
on the pin face of the plug (i.e. RED or ORANGE).
Fuse covers are available from: BBS Ltd
Po Box 110
Farnham Surrey GU104XL
Phone : 01252 727755
Use a 13A fuse approved by ASTA to BS1362, marked thus
For chromed models only:
WARNING: a plug with a bared flexible cord is hazardous if engaged in a live socket. If the
fitted plug has been cut from the power supply cord, it should be destroyed and replaced with
a three pin plug in accordance with the following code:
BLUE: neutral BROWN: live GREEN/YELLOW: earth
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked
with the letter “N” or coloured BLUE or BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is
marked with the letter “L” or coloured BROWN or RED.
The wire which is coloured GREEN/YELLOW should be connected to the
terminal marked with the letter “E”, or by the earth symbol or coloured
GREEN or GREEN/YELLOW.
T
ASA
•
CONTENTS
2
WARNING
BEFORE USING YOUR APPLIANCE
• Please ensure that the voltage indicated on the base of
the machine corresponds with the mains voltage in your
home.
• For Chromed Mini Plus, the machine must always be
connected to an earthed socket.
• Always use the mains cord supplied by the manufacturer.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Pusher
Lid
MINI - BOWL
(on the Mini Plus)
Handle
Control panel
Feed tube
Locking mechanism
Bowl
Motor spindle
Motor unit
3
Stainless steel double-
bladed knife.
4 mm grating disc and disc
support.
(optional extra in UK)
Mini-Bowl with stainless steel
double-bladed knife (Mini Plus only)
Egg whisk / Spatula
Citrus press with anti-splash arm
and 2 cones for small and large
fruit (1 cone fits inside the other)
Reversible stainless steel slicing /
grating disc and disc support.
STANDARD ACCESSORIES
4
1. Place the bowl on the motor unit with
the handle to the left hand side.
3. Place the chosen accessory in the
bowl (see details on following page)
5. Turn the lid in an anticlockwise direction
until the locking device clicks into position
at the top of the handle.
The safety rod is now depressed and
in contact with the motor.
4. Position the lid, completely flat, by
placing the feed tube to the left of the
handle.
2. Turn the bowl anti-clockwise as far
as it will go making sure it firmly locks
in position. The handle will now be at
the centre of the motor unit.
The Mini is now ready to use.
IMPORTANT
If the lid is not properly locked
into position or if it is opened
during preparation, the appliance
will cease to function, even if the
ON switch has been pressed.
FITTING THE BOWL
5
Stainless steel blade
Place the blade directly in the bowl,
over the motor spindle.
Put on the lid and lock into position.
To slice
Place the disc with its slicing edge
uppermost.
Lower the support, fitted with a disc,
onto the motor spindle in the centre of
the bowl. Put the lid on and lock into
position.
To grate
Place the disc with its grating edges
uppermost.
FITTING THE ACCESSORIES
Discs
Place the selected disc on the
support, turning it gently a little
way in an anticlockwise direction.
WARNING
Always handle the highly shar-
pened stainless steel blade and
discs with care.To mount or
separate the disc and support,
hold the disc at the hole at the
edge of the disc with the cut-
ting edge facing away from
your fingers.
6
FITTING THE ACCESSORIES
2.Mini-Bowl (on Mini-Plus model)
Fit over the central spindle inside
the large bowl.
Blade safe storage box
This compact box can hold a maxi-
mum of accessories in a minimum of
space and fits easily into a drawer.
Egg whisk
1. Place the egg whisk directly in the
bowl on the motor spindle.
Put the lid on and lock it into position.
3. The small metal blade also fits onto
the support and locks into place when
rotated slightly to the left/anticlockwise
direction.
4. Place the assembled accessories
on the motor spindle in the
Mini-bowl.
5. Put the lid on completely flat and
engage the locking mechanism at the
top of the handle.
7
REMOVING THE BOWLS AND ACCESSORIES
1. Stop the motor and remove the lid
by turning it clockwise.
3.Carefully remove the Mini-blade,
before putting the Mini-bowl down.
5.Next, remove the support by rotating it,
retaining a firm grasp on the disc. The disc
can also be left fixed to the support for
cleaning.
4.Carefully remove the blade, holding
the rim away from the blades.
2 You can then lift out the Mini-Bowl,
keeping the Mini-blade inside.
N.B. : Before removing the blade or the egg whisk, free the bowl, lift it up,
keeping the accessory in the middle, then remove the accessory.
Blade-safe storage box
The accessories are stored horizontally
and kept in place in individual spaces.
USING THE CITRUS PRESS
5. Switch on the machine and press
down gently on the arm untill all the
juice is extracted.
4. Place the fruit on the cone, pressing
down gently to position it, then lower
the arm.
6. Remove the citrus press by turning
it clockwise before lifting it off.
3. Lower the cone onto the motor
spindle. For lemons, use the small
cone. For oranges and grapefruits, fit
the large cone on top of the small one.
REMOVING THE ARM : RAISE THE ARM, THEN HOLD THE UPPER PART WITH ONE
HAND WHILE THE OTHER HAND PULLS THE BASE OF THE CLIP FREE AT THE BOT-
TOM OF THE BASKET. THE WHOLE ARM CAN THEN BE LIFTED OFF.
8
Citrus press
1. Place the hinged end of the anti-
splash arm on the rim of the filter basket
(to the right of the locking device), then
press firmly on the base of the clip at the
bottom of the basket, to fix it into position.
2. The citrus press fits on top of the bowl
and, like the lid, has a locking pin. Turn
the filter basket anti-clockwise until firmly
locked into position.
9
CLEANING
Use a soft sponge with hot water and
washing-up liquid to clean the attach-
ments. If using a dishwasher, select a
short, low temperature programme.
To clean the disc, carefully twist off the
disc support, keeping a firm hold of the
disc.
The blade, spindle and top should
then be re-assembled and stored
together in the storage box.
Clean the citrus press immediately
after use with hot water and washing-
up liquid to prevent drying pulp
sticking to it.
To clean the bases of the stainless
steel blade and the egg whisk, use the
short side of the spatula.
WARNING
Always handle the highly sharpened stainless steel blade and discs with care.
The whole egg whisk comes apart for
easy cleaning.
