M&M E107C Manuale utente
Smart toilet seat
Instruction manual
Apply to E107C
Contents
Thank you for purchasing this intelligent seat, please use is carefully after reading this manual.
Cautions …………………………………………………………………………………… 2-5
Components name ………………………………………………………………………6-8
Product installation ……………………………………………………………………… 9-13
Confirmation before use ………………………………………………………………14-15
Operation method ………………………………………………………………………16-18
Cleaning steps …………………………………………………………………………… 18-19
Not used for a long time ……………………………………………………………… 20
Malfunction judgement and solution ………………………………………………21-22
Technical data ………………………………………………………………………………23
1
Cautions
To prevent harm to users or others and property damage,Please read
the [Cautions] carefully and follow them! In order to use this product
correctly.
Symbol Meaning
Indicates that if you ignore this flag while operating,
It may cause serious injury or death.
The content indicated by this fl ag is: Unprohibited
[Prohibited] content
The content indicated by this fl ag is: mandatory content
that must be executed
Warning
Prohibited
Compulsory
compliance
The content represented by this flag is：
High temperature and flammable objects are prohibited.
The content represented by this flag is：
Connected to ground.
The content represented by this flag is：
Do not touch with wet hands.
The content represented by this flag is：
Prohibition of immersion in water.
The content represented by this flag is：
Disassembly or unauthorized modification of the product is
prohibited.
The content represented by this flag is：
Unprohibited [Prohibited] content
The content represented by this flag is：
Content that must be enforced.
2
Please use a splash box,Do not pour water or
detergent on the product and power plug.
It may cause damage to the product or fire or
electric shock.
Do not use loose or faulty outlets.
It may cause fi re or electric shock.
Check that the power outlet is grounded.
This product must be well grounded. Only
connect a dedicated 220V, 50Hz, 10A
circuit with a ground fault circuit breaker or a
ground leakage protector.
If the power cord is damaged, it needs to be
replaced. To avoid danger, please observe the
following:
Please contact the retail store where you
purchased this product or the nearby customer
service center. Must be replaced by the
manufacturer’s service department or an
authorized professional.
When using in a bathroom, make sure that the
power outlet is waterproof. Failure to do maybe
result in electric
Failure to do maybe result in electric shock or fire.
Tips
Persons with disabilities and those with limited experience or common sense (including
children) are required to use this product under the supervision of a person.
Do not install the product in a room where frost may form. The indoor temperature must
not be lower than 0 °C，This product must be connected to the cold water supply (inlet
water temperature is approximately 4~35 °C), otherwise the machine will be burn or
caused trouble.
3
Do not plug or unplug the power plug with
wet hands.
It may cause an electric shock.
Do not pour urine on the body and nozzle.
Failure to do so may result in malfunction
or smudges such as pink and
brown.
Do not connect any wastewater, mixed
water, industrial water, sea water or other
untreated or semi-treated water.
May cause skin infection or malfunction.
Do not pull or damage the power plug/power
cord at will.
It may cause fire, short circuit, or electric shock.
Please turn off the power and pull out the
plug before removing or cleaning the product.
Otherwise, there is a danger of electric shock.
Do not disassemble and modify this product
for any purpose, for any purpose.
It may cause fire, short circuit, or electric shock.
Do not place high temperature and flammable
materials near the product. it may cause fire
Glowing cigarettes and other burning materials
must not be thrown into the toilet.
4
Do not bend or twist the water supply hose.
May cause water leakage.
Do not use the following items to clean the
product:
Gasoline, banana water, benzene, paint thinner,
decontamination powder and nylon brush.
When not in use for a long time, drain
the water from the water hose and unplug
the power cord.
Do not lean on the cover.
It may damage the seat cover and cause personal
injury.
Do not expose the productdirectly to water,
strong light or sunlight.
May cause fading and unstable race temperature.
Do not install the product in a room where frost
may form. The indoor temperature must not be
lower than 4 °C.
Prevent product freezeage and damage the
movement components.
5
6
Nightlight
Women wash
Quick release cover
Safety notes
Heating seat
Sensor zone
Handle
Operation panel
Rear wash
Components Name
Plug
7
Components Name
Bottom inlet model
Water inlet
Water inlet
Power cord outlet
Fixing plate
Fixing plate
Quick release putter
Interior atmosphere light
Power cord outlet
Quick release putter
Interior atmosphere light
Side inlet model
Accessories
Side inlet model
4、Waterway accessories
Water inlet
hose（1）
Water inlet
connector（1）
（To the T-cock）
Waterinletconnector（1）
（to the main body）
Water inlet T-cock
connector
Water inlet
hose（1）
Water inlet T-cock
connector
1、Main body
Bottom inlet model
Screw+
Pom nut(2)
Adjustment sheet(2)Flat washer(2)
3、Installation accessories
2、The printing
fixing plate（1） Positioning
cardboard（1）
Manual（1）
4、Waterway accessories
1、Main body
Screw+
Pom nut(2)
Adjustment sheet(2)Flat washer(2)
3、Installation accessories
2、The printing
fixing plate（1） Positioning
cardboard（1）
Manual（1）
Instruction manual
Instruction manual
8
