Manhattan 179195 Manuale utente

Model

179195

Connect a SATA drive to a USB port for quick

and easy data transfer, backup and storage.

The MANHATTAN®Hi-Speed USB to SATA/IDE Adapter with Power Supply connects SATA, SATA-

enhanced, IDE and enhanced-IDE hard disks to desktop and notebook computers using a USB port.

Transferring and sharing files between desktop and notebook computers, backing up files or storing

large file archives on external drives is faster and easier to accomplish. Serving as a bridge, the adapter

can transfer data between SATA and IDE external drives when both are simultaneously attached.

Compatibility with all types of drives up to 5.25” — including 2.5” notebook computer drives and

standard 3.5” hard drives — makes this a versatile tool for professional and home users.

Easily Connect IDE Devices Using a USB Port

Hard drives, Zip drives and other external drives can be quickly connected using the same standard USB connection

popular with computer peripherals and devices. The included power supply supports drives with higher usage

requirements.

Suitable for Professional and Home Use

With the need for data security and data recovery growing, the Hi-Speed USB to SATA/IDE Adapter with con-

venient one-touch backup function helps duplicate, copy or transfer large amounts of data from one drive to

another. Easy to install and use, its Plug and Play and hot-swap capabilities help provide a convenient method

to transfer, store data and test hard drives.

Lifetime Warranty

Strict manufacturing standards ensure the highest quality in all MANHATTAN products. All items carry a

full Lifetime Warranty — the strongest quality commitment anyone can make.

Hi-Speed

USB to SATA/IDE Adapter

3-in-1 with One-Touch Backup

Features

• Provides fast data access to IDE and SATA drives with one-touch

backup

• Transfers data between SATA and IDE external drives when both

are simultaneously attached

• Supports data transfer SATA speeds up to 1.5 Gbps and Hi-Speed

USB speeds up to 480 Mbps

• Supports 48-bit LBA (Logical Block Addressing)

• Fits external SATA and IDE hard drives up to 5.25”

• Plug and Play – Windows, Mac and Linux compatible and hot-

swappable

• Lifetime Warranty

Model

179195

MH-179195-DS-0609-08

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of

the contents herein, are prohibited unless speciﬁcally authorized.

For more information on MANHATTAN products, consult your

local dealer or visit

www.manhattan-products.com

Speciﬁcations

STANDARDS AND CERTIFICATIONS

• USB 2.0

• USB 1.1

• Complies with ATA/ATAOI-100 spec v1.0 standards

• SATA 1.0

• FCC

• CE

• EuP

• WEEE

GENERAL

• USB 2.0 Standard-A male; SATA L-type male; IDE 40-pin; IDE 44-pin ports

• Hi-Speed USB transfer interface

• 480 Mbps maximum transfer rate

• Supports SATA, enhanced-SATA, IDE and enhanced-IDE drives

POWER SUPPLY

• Input: 100 – 240 V AC; 50/60 Hz maximum 0.8 A

• Output: 12 V / 2 A

• Cable: 1.5 m (59 in.)

PHYSICAL

• 9.8 x 7 x 1.8 cm (3.8 x 2.75 x 0.7 in.)

• Cables: USB, 80 cm (31.5 in.); 4-pin power, 10 cm (4 in.)

• Weight: 270 g (9.5 oz.)

SYSTEM REQUIREMENTS

• Available USB type-A port

• Windows XP/Vista/7

PACKAGE CONTENTS

• Hi-Speed USB to SATA/IDE Adapter

• User manual and software CD
