1. TECHNICAL SPECIFICATIONS
Digital Audio System
System..................................................Solid State Recorder
Usable Media................CF memory cards, Microdrive cards
Recording and media methods
MP3....................................MPEG1 Layer III compression
WAV ..................................................16/24 bit linear PCM
Recording MP3 bit rate (selectable)
Mono.........................................160, 128, 96, 64, 32 kbps
Stereo....................................320, 256, 192, 128, 64 kbps
Sampling frequency .......................................44.1, 48 kHz
Number of channels ..............................2 (stereo), 1 (mono)
Audio Frequency response.............10 to 20,000Hz ± 1.0 dB
Signal-to-Noise Ratio IEC-A weighted......................... 91 dB
Total Harmonic Distortion at 0 VU (PCM)...................0.01 %
Dynamic Range...........................................................94 dB
Inputs
Balanced Input
Type ..................................XLR (1:GND, 2:HOT, 3:COLD)
Input Sensitivity.....................+4 dBu /–20 dBu /24 kohms
Unbalanced Input
Type ....................................................................RCA jack
Input Sensitivity..............................500 mVrms /22 kohms
UNBALANCED DIGITAL IN
Type ....................................................................RCA jack
Input impedance...................................................75 ohms
Standard input level .............................................0.5 Vp-p
Sampling frequency .......................................44.1 /48 kHz
Format....................AES/EBU or SPDIF (IEC 958 Type II)
Balanced Digital Input
Type ..................................XLR (1:GND, 2:HOT, 3:COLD)
Sampling frequency .......................................44.1 /48 kHz
Format....................AES/EBU or SPDIF (IEC 958 Type II)
Outputs
Balanced output
Type ..................................XLR (1:GND, 2:HOT, 3:COLD)
Level..................... +18 dBu (+4dBu reference) /600 ohms
Unbalanced output
Type ....................................................................RCA jack
Standard level.........2 Vrms (+4dBu reference) /10 kohms
Balanced Digital output
Type ..................................XLR (1:GND, 2:HOT, 3:COLD)
Output impedance..............................................110 ohms
Standard output level...........................................3.5 Vp-p
Format...AES/EBU or SPDIF (IEC 958 Type II) selectable
Unbalanced Digital output
Type ....................................................................RCA jack
Output impedance................................................75 ohms
Standard output level...........................................0.5 Vp-p
Sampling frequency ........................................44.1/48 kHz
Format....................AES/EBU or SPDIF (IEC 958 Type II)
LAN Interface
Format...........................................10Base-T/100Base-TX
Transmission rate..........................................10/100 Mbps
Connector......................................................... 8pin RJ-45
General
Power requirements
US model ..................................................AC120 V 60 Hz
European model..........................AC100 - 240 V 50/60 Hz
Japan model.........................................AC100 V 50/60 Hz
Power consumption (U/N) ............................................ 26 W
Power consumption (F) ................................................ 18 W
Environmental conditions
Operational temperature.................. 5 - 35 °C (41 - 95 °F)
Operational humidity..............25 - 85 %, no condensating
Storage temperature..................–20 - 60 °C (–4 - 140 °F)
Headphone Output power ............18 mW+18 mW /32 ohms
Dimensions
Width.........................................................483 mm (19.0")
Height............................................................52 mm (2.0")
Depth.........................................................344 mm (13.5")
Weight........................................................3.7 kg (8.2 lbs)
Included accessories
Power cord (for US) .........................................................1
Power cord (for Europe)...................................................2
Power cord (for Japan).....................................................1
USB cable........................................................................1
Audio cable ......................................................................2
CF door Screw. ................................................................2
Retainer............................................................................1
User Guide.......................................................................1
CD-ROM (U/N).................................................................1
Customer Registration Document (only for US)...............1
Adapter (for Japan)..........................................................1
• Specifications are subject to change without notice.
