Marantz SR5002 Manuale utente

Where do we start? How about value? This Marantz makes the upgrade path easy. You don’t have to settle for “commodity-grade”

performance any longer.

Instead, you’ll nd advanced HDMI connectors and switching for your favorite A/V sources. Go on, take advantage of HDMI’s digital-quality

performance and the single-cable connection convenience! For conventional display devices, the SR5002 boasts two component video outputs

so you can still enjoy exceptional picture quality. And there’s an “upconverter” (or “transcoder”) that takes outputs from legacy video sources

and improves them for enjoyment on today’s monitors. A Lip Synch adjustment makes sure that you hear dialog exactly when your eyes say

you should – not with that unnatural delay you can experience with less-capable products.

There’s a second zone audio output that lets you hear a dierent source in another area. And you can enjoy that convenience in mono or

stereo, depending on the number of speakers you have in that bedroom, den, or kitchen.

Of course, there’s an infrared input and a DC trigger output so you can use the SR5002 in a custom-congured system.

And we haven’t forgotten space either. The new, shallow chassis goes almost anywhere. And makes this Marantz even easier to enjoy.

• 90 watts (into 8 ohms) x 7 ch Amps

• HDMI (V1.1) Repeating: 3-In / 1-Out

• HDMI (V1.3) Switching: 3-In / 1-Out

• All discrete amplier stages

• XM Ready with discrete IR commands

• 32bit DSP

• Dual Component Video outputs

• Dolby Digital EX, Pro Logic IIx (Movie/Music/Game),

• 192 kHz/24-bit D/A converters for all channels

• DTS 96/24, ES (Discrete 6.1/Matrix6.1), Neo:6 (Cinema/Music)

• SRS Circle surround II

• Multi channel stereo mode

• HDCD® Decoder

• Dolby Headphone

• Lip sync. control

• RS-232C terminal for system control

• Direct IR Flasher Input

• D-BUS (RC-5 In/Out) remote connection

• 2nd Zone audio output (Individual source) w/discrete commands

• DC Trigger output

• 50 AM/FM station presets

• x4 Optical / x2 Coaxial digital inputs (5 assignable)

• Large Heavy Duty Speaker Terminals

• Assignable HD compatible component

video switching (3 in / 2 out)

• On Screen Display

• Front panel A/V/Optical inputs

• 1 switched and 1 un-switched AC convenience outlets

• Learning Backlight system remote

• New shallow chassis < 16”

• Three year limited warranty

Compatible

SR5002

XM READY SURROUND SOUND MULTIZONE RECEIVER

Life Amplied TM

FEATURES

MULTICHANNEL/SURROUND

Number of Channels

THX

DTS (ES, Discrete 6.1/ Matrix 6,1, Neo-6)

Dolby Digital EX

Dolby Pro Logic IIx

Circle Surround II

SOUND ENHANCEMENTS

HDCD Decoder

Current Feedback Topology

Discrete Amplication

Power Transformer

D/A Conversion

Digital Signal Processing

Video O

Source Direct

Chassis

Variable X-over

Display O

Video Up-conversion

Auto Calibration

XM-Ready

AM/FM tuner

Bass management

Lip-sync (digital audio delay)

Software Upgradeable (RS232)

IN/OUTPUTS

VIDEO

HDMI In

Component In

S-Video In

Composite In

HDMI Out

Component Out

S-Video Out

Composite Out

AUDIO

Analog L&R In

Analog L&R Out

Digital Optical In

Digital Coaxial In

Digital Optical Out

Digital Coaxial Out

IEEE1394 connection

IN/OUTPUTS (continued)

OTHER

Pre-Amplier Out

Main Amplier In

Multi-Channel In

Multi-Room Audio Out

Multi-Room Video Out

Multi-Room Speaker Out

Speaker A/B

External control (RS232C)

DC Triggers

D-Bus Remote (RC-5) In/Out

External IR In/Out

Front Panel A/V Inputs

Headphone Out

AC Outlets (Switched/Unswitched)

SPECIFICATIONS

AUDIO SECTION

Power Output (8 Ohm)

S/N Ratio

Freq. Response (Analog In)

Freq. Response (Dig In)

TUNER SECTION FM

Frequency Range

S/N Ratio (Mono/Stereo)

TUNER SECTION AM

Frequency Range

S/N Ratio

VIDEO SECTION

Video Freq. Response (Component)

Video Freq. Response (Composite, S-Video)

Signal to Noise

GENERAL

Color

Front Panel

Remote Control

Power Requirement

Power Consumption

Dimensions W" x H" x D" (Inches)

Weight (lbs)

SR5002

•(+ 96/24)

•

•(All 7ch)

192kHz/24-Bit

Cirrus Logic© 32-Bit

•

Metal

•

(5 points)

•

Up to Component

•

*All specications, dimensions and weights are subject to change without notice.

D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors being made by retail

dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.

8ch

•

Surround Speaker “C”

•

1/1

•(+ Digital Opt.)

•(Dolby Headphone)

1/1

90W x 7

105db

8Hz - 100kHz (+/- 3 dB)

8Hz - 45kHz (+/- 3 dB)

87.5 - 108.0MHz

Mono/Stereo: 75/70 dB

520 - 1710kHz

50 dB

5Hz - 80MHz (- 1 dB)

5Hz - 8MHz (- 1 dB)

60dB

Black

Aluminum

Learning/Pre-coded with backlight RC5001SR

AC 120V/60Hz

500w

17 5/16" x 6 5/16" x 15 2/8"

27.1
