MARELUX 45 Degree Viewfinder Manuale utente
Package Contents
45 Degree Viewfinder
Diopter Adjustment Tool
Remover Tool
Product Specification:
Material: Optical Glass, Anodized Aluminum Alloy
Weight: 368g
Depth Rating：100m
Magnification: 1X (Underwater)
Installation
Align the Remover Tool (1) with the ring of the
Optical Viewfinder 0.66x (2) on the housing,
then insert it.
Then rotate the Remover Tool counterclockwise
to remove the ring (3) and the Optical Viewfinder
0.66x (4).
（1）
（2）
（4）
（3）
Installation
Insert the 45 Degree Viewfinder into the housing.
Then use the remover tool to tighten the ring clockwise.
Diopter Adjustment
Align the diopter adjustment tool (2) with
the slot of the 45 degree viewfinder (3).
Rotate counterclockwise to increase diopter
and clockwise to decrease diopter.
Remove the eyepiece hood first.
（1）
（2）
（3）
-
+
