Marmitek Split TS12 Manuale utente
Split TS12
3
11
19
27
35
43
User manual
Gebrauchsanleitung
Guide utilisateur
Modo de empleo
Manuale d’istruzioni
Gebruiksaanwijzing
ai15831496145_1_VZ__20598_20200226_UG_88x124mm_80g_Split_TS12_6_languages.pdf 1 2-3-2020 12:46:54
© MARMITEK
2
Split TS12TM
3
ENGLISH
1 Table of contents
1 Table of contents ........................................................3
2 Safety instructions.......................................................4
3 Introduction .................................................................5
4 Package contents: ......................................................5
5 Features......................................................................5
6 Connections................................................................5
6.1 Top .............................................................................5
6.2 Left..............................................................................6
6.3 Right ...........................................................................6
6.4 Back............................................................................6
7 Connection diagram ....................................................6
8 Technical specifications ..............................................7
9 Notification..................................................................8
9.1 Declaration of Conformity............................................8
9.2 Recycling ....................................................................9
9.3 Copyrights.................................................................10
© MARMITEK
4
2 Safety instructions
Please read these instructions thoroughly before you use
the device and keep them for future reference.
•To prevent short circuits, this product should only be
used inside and only in dry spaces. Do not expose the
components to rain or moisture. Do not use the product
close to a bath, swimming pool etc.
•Do not expose the components of your systems to
extremely high temperatures or bright light sources.
•In case of improper usage or if you have altered and
repaired the product yourself, all guarantees expire.
Marmitek does not accept responsibility in the case of
improper usage of the product or when the product is
used for purposes other than specified. Marmitek does
not accept responsibility for additional damage other than
covered by the legal product responsibility.
•This product is not a toy. Keep out of reach of children.
•Do not open the product: the device may contain live
parts. The product should only be repaired or serviced by
a qualified expert.
•Only connect the adapter to the mains after checking
whether the mains voltage is the same as the values on
the identification tags. Never connect an adapter or
power cord when it is damaged. In that case, contact
your supplier.
Split TS12TM
5
ENGLISH
3 Introduction
Congratulations on the purchase of your Split TS12™. The
Optical (Toslink) Digital Audio Splitter can split a single optical
digital input to two outputs without delay or loss of qualtiy.
4 Package contents:
1 x Digital Audio Splitter 1 x Power Adapter
1 x User Manual
5 Features
•Ideal for presentation or distribution to another room.
•With improved 192kHz sample rate for the best sound
reproduction
•Supports the S/PDIF and Toslink standard
•Supports uncompressed 2-channel LPCM (Linear Pulse
Code Modulation) audio signal
•Supports compressed 2-channel and multi-channel
Dolby Digital and DTS audio signals
6 Connections
6.1 Top
1. Power LED: This
LED lights up when
the audio splitter is
connected to a
power adapter.
1
1 x 2 O PTIC AL AU D IO SPL ITT ER
© MARMITEK
6
6.2 Left
1. Optical In: Connect your
audio source to these
inputs with an optical
(Toslink) digital audio cable
(not supplied).
6.3 Right
1. Optical Out: Connect your
audio amplifier or powered
speakers to these outputs
using an optical (Toslink)
digital audio cable (not
supplied).
6.4 Back
1. DC 5V: Connect the power
adapter (included) and plug
it into the mains.
7 Connection diagram
O PTIC ALIN
1
AOUT B
1
DC 5V
1
Split TS12TM
7
ENGLISH
8 Technical specifications
Audio Output 2x Optical (Toslink)
Audio Input 1x Optical (Toslink)
Supported Audio PCM2, Dolby Digital 5.1 & DTS 5.1
Sample rate up to 192kHz
Power 100-240VAC @ 50-60Hz
Dimensions 46 x 46 x 24mm
Weight 22 gr
Environment
Temperature +0 tot +40ºC
Humidity 10% tot 85%
Specifications may change before prior notice.
© MARMITEK
8
9 Notification
9.1 Declaration of Conformity
Hereby, Marmitek BV, declares that this
Split TS12™ is in compliance with the essential
requirements and other relevant provisions of the
following Directives:
Directive 2014/30/EU of the European Parliament and of the
Council of 26 February 2014 on the harmonisation of the laws
of the Member States relating to electromagnetic compatibility
(recast)
Directive 2014/35/EU of the European Parliament and of the
Council of 26 February 2014 on the harmonisation of the laws
of the Member States relating to the making available on the
market of electrical equipment designed for use within certain
voltage limits.
Directive (EU) 2017/2102 of the European Parliament and of
the Council of 15 November 2017 amending Directive
2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment.
Commission Regulation (EU) 2019/1782 of 1 October 2019
laying down Ecodesign requirements for external power
supplies pursuant to Directive 2009/125/EC of the European
Parliament and of the Council and repealing Commission
Regulation (EC) No 278/2009.
You can read the full Declaration of Conformity at
http://www.marmitek.com
Split TS12TM
9
ENGLISH
9.2 Recycling
Environmental Information for Customers in the
European Union and other European countries with
separate collection systems.
This symbol on the product or on its packaging indicates that
this product shall not be treated as household waste. Instead
it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. It is your
responsibility to dispose of this and other electric and
electronic equipment via designated collection facilities
appointed by the government or local authorities. Correct
disposal and recycling will help prevent potential negative
consequences to the environment and human health. For
more detailed information about the disposal of your old
equipment, please contact your local authorities, waste
disposal service, or the shop where you purchased the
product.
© MARMITEK
10
9.3 Copyrights
Marmitek is a trademark of Germatron B.V. Split TS12™ is a
trademark of Marmitek B.V. All rights reserved. Every effort
has been made to ensure that the information in this manual is
accurate. Marmitek is not responsible for printing or clerical
errors. Copyright and all other proprietary rights in the content
(including but not limited to model numbers, software, audio,
video, text and photographs) rests with Marmitek B.V. Any use
of the Content, but without limitation, distribution,
reproduction, modification, display or transmission without the
prior written consent of Marmitek is strictly prohibited. All
copyright and other proprietary notices shall be retained on all
reproductions. Other company and product names mentioned
herein may be trademarks of their respective companies.
Mention of third-party products is for informational purposes
only and constitutes neither an endorsement nor a
recommendation. Marmitek assumes no responsibility with
regard to the performance or use of these products.
Marmitek BV - PO Box 4257 - 5604 EG Eindhoven
The Netherlands
