MW01 QUICKSTART
Follow Us - @masterdynamic
www.masterdynamic.com
FOR MORE INFORMATION
ON
The first time you power ON the MW01 it will automatically
enter pairing mode. To manually activate pairing mode,
leave the MW01 in the extended position for 5+ seconds
and look for the pairing indicator light. Once in pairing
mode, activate pairing mode on your earphones or
headphones and place them adjacent to your MW01.
PAIRING INDICATOR
• A pulsing white light indicates
the MW01 is in pairing mode.
• A solid white light indicates a
device is connected.
To Power ON, pull the MW01 into the extended position.
The MW01 will automatically connect to previously
connected headphones/earphones. Select the number
of prongs required to connect to your intended device.
If using a one-prong connection, use only the prong
marked "1".
USING THE DEVICE
Once prongs are selected, push down to retract the
MW01 and connect the prongs to your analog device.
HIGH MED LOW
BATTERY INDICATOR
Battery Indicator light is only
shown when powering ON/OFF
or charging the MW01.
OFF
To power OFF, tuck away the
prongs and retract the MW01.
If no headphones or earphones
are connected, the MW01 will
power OFF in 10 minutes.
Connect to your first earphone or headphone, then activate pairing mode again by putting the MW01
into the extended position and tucking away both prongs. Do not power OFF. Once the MW01 is in pairing
mode (indicated by a pulsing white light), activate pairing mode on your second pair of earphones or
headphones and place them adjacent to your MW01. A solid white light indicates you are connected.
Select the required prongs and use MW01 normally. The MW01 will automatically forget the second
earphone or headphone after powering OFF.
01 02
CONNECTING A SECOND PAIR OF EARPHONES OR HEADPHONES
Copyright 2014 New Audio LLC. All rights reserved.
Master & Dynamic, the Stylized M Logo and Sound Tools
for Creative Minds are trademarks of New Audio LLC.
Patents Pending.
