MasterChef G36401 Manuale utente

ELITE 2-BURNER

CONVERTIBLE BARBECUE

Assembly Manual

085-3136-8 / G36401

1 YEAR LIMITED WARRANTY

ANSI Z21.58-2015 / CSA 1.6-2015

ANSI Z21.58-2015 / CSA 1.6-2015 ANSI Z21.58-2015 / CSA 1.6-2015

ANSI Z21.58-2015 / CSA 1.6-2015

READ AND SAVE MANUAL FOR FUTURE REFERENCE.

Assemble your grill immediately.

Missing or damaged parts claims must be submitted within 30 days of purchase date.

For product inquiries, parts, warranty and troubleshooting support,

please call 1-855-453-2150.

DANGER

1. If you smell Gas:

a. Shut o gas to the appliance.

b. Extinguish any open ame.

c. Open lid.

d. If odor continues, keep away from

the appliance and immediately

call your gas supplier or your

re department.

2. Requires two people to complete the

assembly process.

3. Beware of sharp edges.

WARNING

Failure to follow all of the Manufacturer’s

instructions could result in hazardous res,

explosions, property damage, or serious

personal injury or even death.

Follow all leak check procedures carefully

prior to operation of barbecue, even if grill

was dealer assembled. Do not try to light

this barbecue without reading the Lighting

Instructions section of this manual.

THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES

CAUTION

Read and follow all safety statements,

assembly instructions, use and care

directions before attempting to assemble

and cook.

WARNING

1. Do not store or use gasoline or other

ammable liquids or vapours in the

vicinity of this or any other appliance.

2. An LP cylinder not connected for use shall

not be stored in the vicinity of this or any

other appliance.

WARNING

IN DIRECT SUNLIGHT, AND IN

OPERATION, YOUR BBQ’S STAINLESS

STEEL AND PAINTED STEEL PARTS CAN

BECOME VERY HOT.

CAUTION

Sharp edges. Wear gloves when assembling

your grill.

THIS BARBECUE IS FOR OUTDOOR USE ONLY.

CONTACT CALL CENTRE IF ANY PARTS ARE MISSING.

1-855-453-2150

INSTALLER OR ASSEMBLER/CONSUMER

This manual should be kept with the BBQ at

all times.

HEAVY ARTICLE NEEDS 2 TO LIFT

To ORDER non-warranty replacement parts or accessories, or to register your warranty,

please visit us on the web at

www.masterchefbbqs.com

HARDWARE PACK

1/4” - 20 UNC x 13 Screw

X 24

No. 10 - 24 UNC x 10 Screw

X 2

1/4” - 20 UNC Nut

X 4

1/4” - 20 UNC Screw

X 4

ST4.2 x 10 Tapping Screw

X 8

U Pin

X 1

1 3

4 5 6

KEY # DESCRIPTION PART NUMBER QUANTITY

1 1/4” - 20 UNC x 13 Screw 20120-13013-036 24

2 1/4” - 20 UNC Screw G361-0002-9091 4

3 No. 10 - 24 UNC x 10 Screw 20124-10010-036 2

4 1/4” - 20 UNC Nut 31220-13000-036 4

5 ST4.2 x 10 Tapping Screw 24200-42010-136 8

6 U Pin G350-0026-9000 1

TOOLS NEEDED FOR ASSEMBLY

• #2 Star-head screwdriver (long and short)

• ¼” Slotted screwdriver (long and short)

• Adjustable wrench

• Pliers

For correct hardware assembly, always position

the lock washer between the screw and the at

washer.

Caution:

Sheet metal can cause injury. Wear gloves when installing the grill.

Lock Washer

Flat Washer

Screw

BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.

Assemble the barbecue on a flat, clean surface. The grill is heavy, two people are

recommended to complete assembly.

PARTS LIST PROPANE FOR 08531368 / G36401

KEY # QUANTITY DESCRIPTION PART NO.

AA 1 Top Lid Assembly G364-2000-01

AB 1 Lid Handle G364-0002-01

AC 1 Thermometer and Bezel G364-0004-01

AD 2 Screw for Top Lid G309-0008-0

AE 2 Lid Bumper, Front G527-0002-02

AF 2 Lid Bumper, Rear G303-0038-01

BA 1 Burner Box Assembly G309-0D00-01

BB 2 Main Burners G432-8M00-01

BC 1 Carryover Assembly G309-0C02-01

BD 2 Flame Tamer G458-0018-01

BE 2 Cooking Grate G309-0019-01

BF 1 Warming Rack G309-0003-01

BG 1 Match Holder G608-0019-02

CA 1 Manifold Assembly G364-5000-01

CB 1 Regulator G364-0006-01

CC1 1 Electronic Ignition Assembly F401-0012-01

CC2 1 Ignition Battery Cover G432-0026-01

CD 1 Electrode Set, Main Burner G309-0M01-01

CE 2 Control Knob G364-0007-01

CF 2 Bezel, Control Knob G364-0008-01

CG 1 Control Panel G364-0200-01

CH 1 Door Support Rail G309-1N00-01

CI 1 Upper Back Brace G309-2701-01

CJ 1 Grease Cup Hook G305-0043-01

CK 1 Grease Cup G430-0033-02

CL 1 Heat Shield G309-5102-01

DA 2 Support Bracket A G309-0005-01

DB 2 Support Bracket B G309-0006-01

DC 2 Shelf Support A G361-1001-01

DD 2 Shelf Support B G361-1002-01

DE 2 Side Shelf G364-0009-01

EA 1 Cart Side Panel, Left G364-0012-01

EB 1 Cart Side Panel, Right G309-0025-01

EC 1 Grommet G501-0039-01

ED 1 Door Assembly G364-9000-01

EE 1 Door Handle G453-0053-01

EF 1 Bottom Shelf G364-0400-01

EG 2 Locking Castor G350-0023-01

EH 2 Castor G350-0024-01

EI 2 Door Magnet Assembly G213-0022-01

F1 1 Hardware Pack G364-B001-01

F2 1 Assembly Manual G364-M001-01

F3 1 Safe Use and Care Manual G453-M015-02

F4 1 Tank Screw G430-C001-01

EXPLODED DIAGRAM PROPANE FOR 08531368 / G36401

CC2

CC1

CF CE

HARDWARE

PACK

F2 F3

ASSEMBLY

MANUAL

SAFETY

AND CARE

MANUAL

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 1

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 4

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 4

BACK OF CART

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 4

FRONT OF CART

ASSEMBLY INSTRUCTIONS

YOU WILL NEED:

X 2
