Matrix Nexa Manuale utente
▲Please read this manual carefully before riding
Nexa - Enclosed Mobility
Preface
• Thank you for choosing Matrix Nexa!
• Before driving, please read the User's Manual carefully and do not drive until you understand the characteristics of
this vehicle.
• If you want to transfer or give the vehicle to others, please attach this manual with the vehicle, because it is an
important part of the vehicle;
• Do not modify the vehicle without permission. The modification will affect the safety performance of the vehicle,
and will also violate the relevant national regulations. The performance degradation or failure of the vehicle caused by
the modification will not be covered by the warranty and will no longer enjoy the "after-sale service".
• Please understand if the vehicle structure, configuration, parts, etc. are not reflected in this manual!
• We reserves the right to make changes without any notice, and any data, illustrations and descriptions in this
manual will not be used as the basis for compensation,
If you have any questions to ask, this Electric Vehicle will serve you wholeheartedly.
• When you need to carry out regular maintenance or repair, please contact the authorized maintenance
departments or dealers around the company. They know how to service your car best, and can also ensure that your
car always maintains the best operating performance. If you have all kinds of mechanical technical knowledge and
maintenance tools, local authorized dealers can provide you with spare parts catalogue and official spare parts to help
you do all kinds of maintenance and repair work.
Reminder: For the sake of your family's happiness and driving safety, please obey the traffic rules, drive politely,
and prohibit drunk driving, speeding and overloading.
Our company reserves the right of final explanation. I wish you a pleasant driving and thank you for purchasing the
this electric vehicle!
Important considerations
* Vehicles are restricted to flat roads. If the technical specifications are changed, some pictures or contents of this Manual
may be related to.
We appreciate your understanding that there are differences in the actual situation of the vehicles. We reserve the right of
final explanation.
* Minors, patients with heart disease, patients with mental illness and special persons who are prohibited from driving vehicles
as stipulated by the State shall not use them.
* Before you drive an electric car, you must do a good job of checking the brakes, tires, power, etc. before you use it.
* Vehicles are non-operating vehicles and should not be used by passengers.
Please read this manual carefully. Pay special attention to any sentence or paragraph marked with the following
warning words.
Note: Note the section with“◆”
If you do not follow the instructions in the Manual of Use, you may injure people or damage parts.
Warning:
♦Electric vehicles and appliances are strictly forbidden to enter water parts, especially controllers. Users should pay attention when cleaning
vehicles. Speed up slowly when the vehicle starts.
♦Charge a 60V vehicle when its power level shows 53V (or a 72V vehicle when its power level shows 63V); Otherwise, it will do a lot of damage
to the accumulator. Car charging plug should not be touched by hand, otherwise it may cause injury to human body.
Catalogue
Ⅲ、Maintenance and repair
Maintenance method------- 21
Simple troubleshooting -------23
Suspension and steering system------- 24
Electronic control system -------25
Battery maintenance------- 26
Ⅳ、 Vehicle storage -------27
Ⅴ、 Vehicle identification------- 28
Ⅵ、 Electrical schematic diagram------- 29
Ⅶ、 After-sales service matters -------30
Ⅷ、 Warranty Card -------32
Ⅰ. Safe driving rules for
vehicles-------04
Ⅱ. Vehicle Local Map and Description
Tail luminaire bitmap------- 05
Multimedia Instrument Diagram and
Description -------08
Adjustable seat -------12
Ignition switch, USB -------13
Power off switch------ 15
Remote Control------- 15
Charging connector------- 16
Charger -------16
Door lock------- 17
Window glass lift -------18
Driving Operations------- 19
Parking Operations------- 20
Ⅰ、Safe driving rules for vehicles
Safe driving rules
1、♦ Electric vehicles are only suitable for those who hold a driver's license or have received training and training. If you operate electric
vehicles for the first time, please connect
Supervised by trained technicians to avoid accidents.
※ Avoid driving under the conditions of dazzling lights, dead angle of sight and no vigilance at night.
2、♦ Fatigue driving is strictly prohibited.
3、♦ It is forbidden to drive the vehicle with the outside rearview mirror folded.
4、♦ Mobile phones or mobile phones are strictly prohibited during driving.
5、♦ Please adjust the seat to a position convenient for correct driving before driving.
6、♦ Drive with special care at road intersections, entrance and exit positions of parking lots and traffic lanes.
7、♦ Speeding is easy to cause accidents, so you should obey the speed regulations and never exceed the specified speed.
8、♦ Avoid driving on uneven roads, which may cause manipulation failure or body structure damage due to uneven roads.
9、♦ Before driving an electric vehicle, make sure to check before driving.
10、♦ Do not get too close to other motor vehicles during driving, do not race for the road, and strictly comply with local traffic regulations.
（Nexa）
Dipped headlight
Side marker lamp
(driving lamp)
cornering lamp
Tigh beam light
Instrument diagram (Figure 1)
(1) Left and right turn indicators: When the turn signal button is turned, the left and
right turn indicators will flash.
(2) High and low beam indicator: When the dimmer switch is turned to the "0" position,
the high and low beam indicator will light up. When the dimmer switch is turned to the
"Multi D" position, the high and low beam indicators will not light up.
(3) Temperature display lamp.
(4) Volume adjustment indicator: adjust the volume.
(5) Multimedia display.
(6) Running speed display.
(7) Gear display.
Neutral indication: When the switch button is in the "N" position,
the gear indicator light "N" will be on.
Reverse indication: When the switch button is in the "R" position,
the reverse indicator light "R" will be on.
Forward indicator: When the switch button is in the "D" position, the
forward indicator light "D" will be on.
（Figure1）
10
(四轮车挡位)
NEXA
Selector
(8) Total mileage/(km): record the total mileage of the vehicle;
(9) Power meter: when the switch lock is opened, the battery power is displayed;
Operating system name
Inspection before driving:
Before each driving, the vehicle shall be subject to a routine inspection to ensure good
performance and safe driving.
Power display:
Turn the ignition switch and watch the power indicator position. When it is close to the red
mark position, the vehicle should be charged.
Driving precautions
When turning the steering wheel, it is not allowed to turn the steering wheel too hard or turn sharply. Do not
turn the steering wheel after the vehicle stops,
When driving on uneven roads, hold the steering wheel tightly with both hands; To prevent accidents due to
uncontrolled steering.
Foot brake pedal
accelerator pedal
Wiper
Spray
High and low beam
lamps
Cornering lamp
Fog lamp
Warning
light
Indice
