Maytag MDG-120PVV Manuale utente

MDG120PVV

(Phase 7/Non-Coin with S.A.F.E.)

Installation Manual

WARNING: For your safety the information in

this manual must be followed to minimize the

risk of fire or explosion or to prevent property

damage, personal injury or death.

— Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any

other appliance.

— WHAT TO DO IFYOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not

use any phone in your building.

• Clear the room, building or area of all

occupants.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call

the fire department.

— Installation and service must be performed by a

qualified installer, service agency or the gas

supplier.

AVERTISSEMENT: Assurez-vous de bien

suivre les instructions données dans cette notice

pour réduire au minimum le risque d’incendie

ou d’explosion ou pour éviter tout dommage

matériel, toute blessure ou la mort.

— Ne pas entreposer ni utiliser d’essence ni

d’autres vapeurs ou liquides inflammables à

proximité de cet appareil ou de tout autre

appareil.

— QUE FAIRE SI VOUS SENTEZ UNE ODEUR

DE GAZ:

• Ne pas tenter d’allumer d’appareils.

• Ne touchez à aucun interrupteur. Ne pas

vous servir des téléphones se trouvant dans

le bâtiment.

• Évacuez la pièce, le bâtiment ou la zone.

• Appelez immédiatement votre fournisseur

de gaz depuis un voisin. Suivez les

instructions du fournisseur.

• Si vous ne pouvez rejoindre le fournisseur

de gaz, appelez le service des incendies.

— L’installation et l’entretien doivent être assurés par

un installateur ou un service d’entretien qualifié

ou par le fournisseur de gaz.

122302JEV/mcronan Part No. 113395

RETAIN THESE INSTRUCTIONS IN A SAFE

PLACE FOR FUTURE REFERENCE

Retain This Manual In ASafe Place For Future Reference

This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will

provide many years of safe, efficient, and trouble free operation.

ONLY qualified technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with

the dryer.

The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

“IMPORTANT NOTE TO PURCHASER”

Information must be obtained from your local gas supplier on the instructions

to be followed if the user smells gas. These instructions must be posted in a

prominent location near the dryer.

We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves the

right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to

change or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly.

Important

For your convenience, log the following information:

DATE OF PURCHASE ________________________________ MODEL NO. __________________________________________

DEALER’S NAME __________________________________________________________________________________________

Serial Number(s) ________________________________________________________________________________________

________________________________________________________________________________________

For replacement parts, contact the dealer from which the dryer was purchased or contact:

Maytag Co.

403 West Fourth Street North

Newton, Iowa 50208

(641) 787-7000

FOR YOUR SAFETY

Do not store or use gasoline or

other flammable vapors and

liquids in the vicinity of this or

any other appliance.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides

inflammables à proximité de cet

appareil ou de tout autre appareil.

MDG120

IMPORTANT

YOU MUST DISCONNECTAND LOCKOUTTHE ELECTRIC SUPPLYAND THE GAS

SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE

MACHINE TOALLOWACCESS FOR CLEANING,ADJUSTING, INSTALLATION, OR

TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health

Administration) STANDARDS.

WARNING

CHILDREN SHOULD NOT BE ALLOWED TO PLAY ON OR NEAR THE DRYER(S).

CHILDREN SHOULD BE SUPERVISED IF NEAR DRYERS IN OPERATION.

CAUTION

DRYERS SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.

FOR YOUR SAFETY

DO NOT DRY MOPHEADS IN THE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRYCLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the dryer door switch, lint drawer switch, or

the heat safety circuits ever be disabled.

“Caution: Label all wires prior to

disconnection when servicing controls. Wiring

errors can cause improper operation.”

«Attention: Au moment de l’entretien des

commandes, étiquetez tous les fils avant de

les débrancher. Des erreurs de câblage

peuvent entraîner un fonctionnement

inadéquat et dangereux.»

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service

panels removed. PERSONAL INJURY OR FIRE COULD RESULT.

IMPORTANT

PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or

specified in the installation manual included with the dryer.

WARNING

DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN

PLACE, EVEN IFAN EXTERNAL LINT COLLECTION SYSTEM IS USED.

Dryer must not be installed or stored in an area where it will be exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

IMPORTANT

Dryer must be installed in a location/environment, which the ambient temperature

remains between 40° F (4.44° C) and 130° F (54.44° C).

SECTION I

IMPORTANT INFORMATION ............................................................................... 3

A. Receiving and Handling ............................................................................................................... 3

B. Safety Precautions ...................................................................................................................... 4

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION..................................... 6

A. Specifications ............................................................................................................................. 6

B. Component Identification ............................................................................................................ 8

SECTION III

INSTALLATION PROCEDURES ......................................................................... 10

A. Location Requirements ............................................................................................................. 10

B. Unpacking/Setting Up ............................................................................................................... 11

C. Dryer Enclosure Requirements .................................................................................................. 14

D. FreshAir Supply Requirements ................................................................................................. 15

E. Exhaust Requirements ............................................................................................................... 16

F. Electrical Information ................................................................................................................ 22

G. Gas Information ........................................................................................................................ 26

H. Preparation For Operation ........................................................................................................ 30

I. Preoperational Tests ................................................................................................................. 31

J. Shutdown Instructions ............................................................................................................... 33

K. Operating Instructions ............................................................................................................... 34

SECTION IV

SERVICE/PARTS INFORMATION ...................................................................... 35

A. Service ..................................................................................................................................... 35

B. Parts ........................................................................................................................................ 35

SECTION V

WARRANTY INFORMATION............................................................................... 36

A. Returning Warranty Cards ......................................................................................................... 36

B. Warranty .................................................................................................................................. 36

SECTION VI

ROUTINE MAINTENANCE .................................................................................. 37

A. Cleaning ................................................................................................................................... 37

B. Adjustments ............................................................................................................................. 39

C. Lubrication ............................................................................................................................... 39

Table of Contents

SECTION VII

DATA LABEL INFORMATION ............................................................................. 40

A. Data Label ............................................................................................................................... 40

SECTION VIII

REVERSING TIMER SPIN/DWELL ADJUSTMENTS..................................... 42

SECTION IX

PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT

COMPONENTS........................................................................................................ 43

SECTION X

SENSOR ACTIVATED FIRE EXTINGUISHING (S.A.F.E.) SYSTEM ........... 45

Installation ...................................................................................................................................... 46

SensorActivated Fire Extinguishing (S.A.F.E.) System Theory of Operation .................................... 49

System Reset .................................................................................................................................. 49

Non-Coin S.A.F.E. System Check Procedure................................................................................. 49

SensorActivated Fire Extinguishing (S.A.F.E.) System Parts Break Down ....................................... 50

SECTION I

IMPORTANT INFORMATION

A. RECEIVING AND HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover

(or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and

wooden skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect

further before delivering carrier leaves.

Dryers damaged in shipment:

1. ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the trucker’s receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers, which were not damaged in a

damaged shipment, should be accepted, but the number received and the number refused must be noted

on the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the

delivering carrier’s freight terminal immediately and file a claim. The freight company considers this

concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult

when more than a day or two passes after the freight was delivered. It is your responsibility to file freight

claims. Dryer/parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.

Manufacturer assumes no responsibility for freight claims or damages.

IMPORTANT: The dryer must be transported and handled in an upright position at ALL times.

B. SAFETY PRECAUTIONS

WARNING: For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING: The dryer must never be operated with any of the back guards, outer tops,

or service panels removed. PERSONAL INJURY OR FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event

the user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS...

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALL occupants.

e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryer(s) must be exhausted to the outdoors.

6. Although Maytag produces a very versatile dryer, there are some articles that, due to fabric composition

or cleaning method, should not be dried in it.

WARNING: Dry only water washed fabrics. DO NOT dry articles spotted or washed in dry

cleaning solvents, a combustible detergent, or “all purpose” cleaner.

EXPLOSION COULD RESULT.

WARNING: DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,

or wax.

EXPLOSION COULD RESULT.

WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvents will create a

fire hazard.

WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubber materials. Drying in a heated basket (tumbler) may damage

plastics or rubber and may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the heating unit area, exhaust

ductwork, and inside the dryer. The frequency of inspection and cleaning can best be determined from

experience at each location.

WARNING: The collection of lint in the burner area and exhaust ductwork can create a potential

fire hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian

Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE: Failure to do so will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switch, lint drawer switch, or the heat safety

circuits ever be disabled.

WARNING: PERSONAL INJURY OR FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articles left in the dryer after the drying and cooling cycles have been completed can

create a fire hazard.

12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE

DRYER.

13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less

than sixty-six percent (66%), 85 lbs (38 kg) of its rated capacity.

WARNING: YOU MUST DISCONNECTAND LOCKOUT THE ELECTRIC SUPPLY

AND THE GAS SUPPLY BEFORE ANY COVERS OR GUARDS ARE

REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,

ADJUSTING, INSTALLATION, OR TESTING OFANY EQUIPMENT PER

OSHA (Occupational Safety and HealthAdministration) STANDARDS.

IMPORTANT: Dryer must be installed in a location/environment, which the ambient

temperature remains between 40° F (4.44° C) and 130° F (54.44° C).

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION

A. SPECIFICATIONS

NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or

obligation.

GAS

Shaded areas are stated in metric equivalents 9/4/03

MAXIMUM CAPACITY (DRY WEIGHT) 120 lbs 54.4 kg

BASKET (TUMBLER) DIAMETER 44-1/2” 113 cm

BASKET (TUMBLER) DEPTH 42-1/2” 107.9 cm

BASKET (TUMBLER) MOTOR 3/4 hp 0.560 kW

BLOWER MOTOR 3 hp 2.238 kW

DOOR OPENING (DIAMETER) 31-3/8” 79.7 cm

BASKET (TUMBLER) VOLUME 38.2 cu ft 1.08 cu m

AIRFLOW 2,150 cfm 60.88 cmm

S.A.F.E. WATER CONNECTION 3/4-11.5 NH

VOLTAGE AVAILABLE 208-575v 3ø 3, 4w 50/60 Hz

APPROX. WEIGHT (UNCRATED) 1,349 lbs 611.9 kg

APPROX. WEIGHT (CRATED) 1,489 lbs 675.4 kg

HEAT INPUT 375,000 Btu/hr 94,500 kcal/hr

INLET SIZE 1-1/4” F.N.P.T.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Maytag Asciugatrice

Maytag

Maytag MGDC400VW - Centennial 29" Gas Dryer Manuale utente

Maytag

Maytag MEDC500VW - Centennial Series 29 Inch Electric... Manuale utente

Maytag

Maytag MED5591TQ0 Manuale utente

Maytag

Maytag MGDE900V Istruzioni utente

Maytag

Maytag MEDX5SPAW0 Manuale utente

Maytag

Maytag Bravos Quiet 300 Series Manuale utente

Maytag

Maytag MDE17MNAZW0 Manuale utente

Maytag

Maytag Performa HY-2 Manuale utente

Maytag

Maytag MGDX600XW Manuale utente

Maytag

Maytag Bravos W10260037A Manuale utente

Maytag

Maytag MDG22PN Manuale utente

Maytag

Maytag Bravos MGDB200 Manuale utente

Maytag

Maytag Epic z W10112943A Manuale utente

Maytag

Maytag MEDC700VJ0 Manuale utente

Maytag

Maytag MGDC500VW Manuale utente

Maytag

Maytag MEDX500X Istruzioni utente

Maytag

Maytag MLG24PDAGW0 Manuale utente

Maytag

Maytag NDG6800AWW Manuale utente

Maytag

Maytag MDE17MNBGW Manuale utente

Maytag

Maytag 3RMED4905TW0 Manuale utente

Maytag

Maytag MDG16MN Manuale utente

Maytag

Maytag MCE8000AYW Manuale utente

Maytag

Maytag MED5600TQ0 Manuale utente

Maytag

Maytag W10099060 Manuale utente

Manuali Asciugatrice popolari di altre marche

Bosch

Bosch WTA79200GB Manuale utente

Amana

Amana W10233410A Manuale utente

Miele

Miele TWH 780 WP Manuale utente

Asko

Asko T760 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuale utente

Bosch

Bosch Logixx 10 WTB76556GB Scheda tecnica

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manuale di istruzioni

Electrolux

Electrolux EW2H328R2 Manuale utente

Beko

Beko DS8433RX1M Manuale utente

Dawlance

Dawlance Spinner DS 6000 C Manuale utente

Electrolux

Electrolux TP5080TW Manuale utente

AEG

AEG TR838P4OB Manuale utente

Indesit

Indesit IDV 75 Manuale utente

Infiniton

Infiniton SD-DG85C Manuale utente

BOMANN

BOMANN WT 5019 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuale utente

Asko

Asko T793C Manuale utente

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente
