Maytag MGDZ400TQ2 Manuale utente
TOP AND CONSOLE PARTS
1
For Model: MGDZ400TQ2
(Designer White)
12−07 Printed in U.S.A. (LAN) Part No. W10180625 Rev. A
27" GAS DRYER
TOP AND CONSOLE PARTS
2
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10112943
Use & Care Guide
W10117403
Guide,
Quick Start
W10133923
Tech Sheet
2 8563730 Top
3
W10110973
Harness, Main
4
W10117384
Panel, Console
(Includes Illus.
19.)
5 3394427 Clip, Harness
6 8565237 Bracket, Console
7 353424 Connector, Sensor
8 94614 Terminal
9 3936144 Plug, Terminal
10 94613 Terminal
11 3390647 Screw, 8−18 x 1/2
12
W10112569
Badge Assembly
13 8574968 Channel, Water
14
W10117416
Assembly,
User Interface
15 3395683 Connector,
(Motor)
16 3400238 Screw, 2−28 x 1/2
17
W10117387
Lens Display
18
W10112899
Knob Assembly
3
CABINET PARTS
For Model: MGDZ400TQ2
(Designer White)
W10180625
CABINET PARTS
4
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 8317340 Cover,
Terminal Block
2 3390814 Screw, 8−18 x 3/8
3 8533974 Screw Ground
4 8565048 Panel, Side (R.H.)
5 3394881 Switch, Broken
Belt
6 8519459 Clip, Toe Panel
7 8565054 Panel, Side (L.H.)
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 697750 Plug, Multivent
13 3388672 Pulley Assembly
14 3978776 Bracket,
Gas Pipe
15 8066120 Lever, Snap
Switch
16 3394081 Wire, Belt Switch
17 343641 Screw, 8−18 x 1/2
18 233520 Washer, Thrust
19 8574875 Assembly,
Door Switch
20
W10121334
Washer
21 8066115 Cover−Plate
22 8565083 Ramp, Door
23 8565122 Strike, Door (1)
25 8565046 Base, Cabinet
26 8565059 Panel, Rear
27 8538263 Motor Assembly
60 HZ.
28 3398948 Wire, Jumper
(Broken Belt
Switch)
29 8578220 Pulley 60 HZ.
30
W10112954
Belt, Drive
31 8529757 Bracket, Burner
32 3387118 Bracket, Motor
33 3401401 Cord, Power
34 49026 4" − 90 Elbow
35 693995 Screw, 8−18 x 3/8
36 8563747 Exhaust Pipe
& Bracket
37 8563750 Exhaust Pipe
(Short)
38 8563749 Exhaust Pipe
(Long)
39 3388674 Idler Bracket
40 8540621 Toe Panel
41 8533971 Screw, 8−18 x 5/16
42 98129 Screw,
6−20 x 1 1/16
43 3390647 Screw, 8−18 x 1/2
44 3387242 Seal, Front Panel
45 3393008 Screw, 10−16 x 1/2
46
W10132445
Control Board
47 8563727 Control Bracket
48 8565043 Plug, Strip
Front Panel
49 3357011 Screw, 10−16 x 1/2
50
W10117421
Front Panel
(Includes
Illus. 44)
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
51 279818 White
BULKHEAD PARTS
5
For Model: MGDZ400TQ2
(Designer White)
W10180625
BULKHEAD PARTS
6
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 8575324 Shaft, R.H. Thread
2 3390647 Screw, 8−18 x 1/2
3
W10153413
Door, Lint
Screen
4 3392519 Thermal Fuse
(91 C)
5 3394346 Air Duct Assembly
6 697813 Seal, Outlet
Housing
7 697814 Seal, Drum Front
8 3934666 Nut,3/8 x 16(R.H.)
9
W10049370
Lint Screen
10 3402841 Lens,
Drum Light
11 359625 Screw, 8−18 x 1/2
12 8572105 Clip, Exhaust
Pipe
13 8533971 Screw, 8−18 x 5/16
15 693995 Screw, 8−18 x 3/8
16
W10001120
Nut, 3/8−16 (L.H.)
17
W10080170
Bulkhead, Rear
18 3387459 Washer, Support
19 8575325 Shaft, L.H. Thread
20 690997 Ring, Tri
21 8536973 Roller, Support
22 8563728 Exhaust Pipe
23
W10153423
Housing, Outlet
Assembly
24 489463 Screw, 8−18 x 5/8
25
W10153420
Complete Drum
Assembly
26
W10109200
Screw, 11−16 x 3/4
27 697694 Seal, Drum
28 8066208 Clip−Spring
29 90767 Screw, 8−18 x 3/8
32 3401707 Wire Jumper
33 3406124 Bulb, Light
34 3387223 Electrode, Sensor
35 8578825 Bracket,
Drum Light
36
W10136369
Socket Assembly
37 697772 Wheel, Blower
38 8573713 Thermal Cut−Off
39 3394986 Spring, Lint
Screen Door
40 697770 Seal,
Cover Plate
41 695240 Screw, 8−18 x 1/2
42 8577274 Thermistor
43 487909 Screw, 8−15 x 1/2
44 8544362 Housing, Blower
45 8066168 Lint Duct Assembly
46 8573824 Funnel, Burner
47 8573028 Thermostat,
High−Limit 205 F
(96 C)
48 338906 Sensor, Radiant
49 3387230 Screw, 10−16 x 1
50
W10153409
Baffle, Drum
51 8565061 Bulkhead, Front
52
W10153412
Grille, Outlet
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
8576353 BURNER ASSEMBLY
BA−153A
7
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION
BA−153A
8576353 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
1 8576353 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 7/8)
6 343641 Screw, 10−16 x 1/2
7 3389871 Base, Burner
8 3387057 Screw,
8−18 x 3/8
9 Orifice, Burner
15418 Type 1
15422 Type 4 (Butane)
234867 Type 4 (Propane)
10
W10118347
Valve, Gas
60 Hz. (Complete)
(Includes Pipe &
Illus. #7).
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak, Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
18 3390647 Screw, 8−18 x 1/2
20 239822 Plug, Pipe
25 3387561 Clamp, Pipe
26 3389889 Bracket, Support
Following Parts Not Illustrated
8576846 Conversion Kit
(Type (1)
to Type (4) LPG).
8
For Model: MGDZ400TQ2
(Designer White)
W10180625
DOOR PARTS
9
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 8565119 Plug Strip
(Inner Door)
2 8578887 Door Hinge
Assembly
3
W10119053
Assembly, Door
Intermediate
4 9742177 Screw, 8−18 x 5/8
5 3400618 Screw, 6−32 x 3/8
6 8579663 Seal, Window
7
W10117478
Handle, Door
(Includes Illus.
20.)
8
W10159996
Screw,
10−24 x 3/64
9 3393258 Screw
10 8578933 Door Assembly
(Inner)
(Includes
Illus. 1 & 14 )
11 355515 Screw,
8−18 x 11/16
12
W10112916
Door, Outer Ring
13 8565117 Window
14 690081 Door Catch
Assembly
15 8519354 Retainer−Lower
16 8580059 Door,
Intermediate
17 8534022 Screw
18 8519356 Retainer, Upper
19 Door Seal
(Not Serviceable)
20
W10112927
Pad, Door Handle
OPTIONAL PARTS (NOT INCLUDED)
10
For Model: MGDZ400TQ2
(Designer White)
W10180625
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
ACCESSORY PARTS
8529894 Hold Down Kit
8522199 Kit, Dryer
Vent Testing
80047 Kit,
Dryer Repair
8563738 Dry Rack
