MAYTAG®COMMERCIAL

TOP-LOAD WASHER

CLP549

THE LONGEST-LASTING

TOP-LOAD WASHER

Maytag®top-load washers last longer

than other leading brands, thanks to a

simple design that reduces wear. It’s

another way you can depend on Maytag

to maximize your equipment investment.

MECHANICAL CONTROLS

Simple-to-operate manual controls make

it easy for anyone to select the appropriate

cycle for any machine-washable fabric.

LASTS LONGER

THAN OTHER

LEADING BRANDS.

THE BEST WARRANTY

IN THE BUSINESS —

5 YEARS ON ALL PARTS.

FOR YOUR OPERATION:

•Simple Controls Are Easy To Understand

•Bilingual English/Spanish Instructions

Available

•Cycle Stage Indicator Lights

•Extra-Large Lid And Tub Opening

•Front Access For Easy Self-Service

•Ball Lid Hinges™Allow Easy Removal

For Cleanup

BUILT-TO-LAST™FEATURES:

•Dependable Drive®Orbital Transmission

•Poly-Pump™Polypropylene Pump

Can’t Rust

•Premium Porcelain-Enamel Top

•Quad Coat™Cabinet Protection

•Heavy-Duty Leveling Legs

•The Best Warranty In The Business

MAT13MN

5YEARS—ALL PARTS

For a period from the date of original purchase

through the time listed above, the designated parts

that fail in normal commercial use will be repaired

or replaced free of charge for the part itself, with

the owner paying all other costs, including labor,

transportation and customs duty. Chemical

damage is excluded from all warranty coverage.

See complete warranty for details.

36"*

(91.4 cm)

253/4"*

(65.4 cm)

251/2"

(64.8 cm)

61/2"

(16.5 cm)

52"*

(132.1 cm)

431/4"*

(109.9 cm)

61/4"*

(15.9 cm)

11/4"

(3.2 cm)

263/4"

(67.9 cm)

www.maytagcommerciallaundry.com

Top-Load Washer — MECHANICAL CONTROL

*Dimensions will vary according to adjustment

of leveling legs; add 1⁄2" (1.3 cm) minimum.

10/03

Top-Load

Washer

WASHER SPECIFICATIONS

MODEL MAT13MN

MOTOR

Single-phase, reversible, thermoprotected •

HP (kw) 1⁄2(.37)

APPROXIMATE WATER USAGE — gal. (liters)

Hot 7.8 (29.5)

Overall 37 (140)*

ELECTRICAL RATING 120V, 60 Hz

Export models 240V, 50 Hz

FUSE REQUIREMENT

Amps 15

CYLINDER

Volume — cu. ft. (liters) 2.9 (82.1)

Diameter — in. (cm) 20

1/2

(52.1)

Depth — in. (cm) 13 (33)

DOOR OPENING

In. (cm) 16 (40.6)

EXTRACT SPEED

Maximum rpm 618

Maximum g-force 110

OPERATING PRESSURE

Psi (bar) 15 – 120 (1 – 8)

INLET HOSE LENGTH

Ft. (m) 4 (1.22)

DRAIN HOSE LENGTH

Ft. (m) 4 (1.22)

ADJUSTABLE LEVELING LEGS •

COLOR

White •

APPROXIMATE WEIGHT — lbs. (kg)

Crated 224 (102)

Uncrated 198 (90)

*Average based on testing with a 14-pound AHAM load.

Flush-to-wall installation is permitted by a 1

⁄

" (3.2 cm) back panel overhang.

See specific instructions for proper installation. Because of continuous product improvement, Maytag reserves the right to change

specifications without notice.

NEWYORK CITY

M.E.A.
